  • Page 1 OWNER’S MANUAL PULSE CONTROL PANEL: DPM/DPC...
  • Page 2 KNOW YOUR EQUIPMENT READ THIS MANUAL FIRST. Your Pulse Control Panel should provide years of trouble-free service. This man- ual will help you understand the operation of your new panel. It will also help you understand how to maintain it in order to achieve top performance. For quick future reference, fill in the spaces below.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Page SAFETY PRECAUTIONS ....................ii 1. PULSE TIMER BOARD ..................1 1.1 Specifications ....................1 1.2 Range Adjustments ..................1 1.3 Operation ....................... 2 1.1.1 Continuous Clean Operation ..............2 1.1.2 Pressure Switch Operation..............2 1.1.3 Downtime Cleaning Operation ..............2 1.4 Connection Diagrams..................

  • Page 4: Safety Precautions

    SAFETY PRECAUTIONS We have provided many important safety messages in this manual. Always read and obey all safety messages. This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you and others. All safety messages will follow the safety alert symbol and the word “DANGER”, “WARNING”...

  • Page 5: Pulse Timer Board

    Pulse Control Panel Revised 10/10 DPM/DPC I M P O R TA N T 1. PULSE TIMER BOARD A separate motor starter auxiliary isolated dry contact Before making changes to the pulse timer board, please should be supplied with the blower/ motor starter and read this manual.

  • Page 6: Operation

    Pulse Control Panel Revised 10/10 DPM/DPC WA R N I N G Excessive downtime cleaning could pulse dust from 1.1.3 DOWNTIME CLEANING OPERATION unit out of incoming ducting. Upon motor/blower shutdown, downtime cleaning can be performed in either pressure switch mode or 1.3 OPERATION continuous clean mode.
  • Page 7 Pulse Control Panel Revised 10/10 DPM/DPC Figure 2 shows recommended interconnections between a separate combination motor starter with a 115VAC step-down transformer, either a DPC or a DPM, and a pulse timer board (20-3048). Figure 2 Standard Pulse Timer Board Connections...

  • Page 8: Troubleshooting Guide

    Pulse Control Panel Revised 10/10 DPM/DPC 1.5 TROUBLESHOOTING GUIDE Use the troubleshooting guide (below) to correct any problems that occur with your dust collection unit. If the problem or condition continues, contact UAS customer service at 1-800-252-4647. PROBLEM RECOMMENDED SOLUTIONS Timer board does not 1.

  • Page 9: Dpc-A3

    Pulse Control Panel Revised 10/10 DPM/DPC 2. DIGITAL PRESSURE GAUGES 2.1.3 INSTALLATION 2.1.3.1 MOUNTING 2.1 DPC-A3 Flush Mounting – For new applications, cut a 4-9/16" 2.1.1 MODEL NUMBER CONFIGURATION hole in the panel. Insert the control with the provided gasket through the hole and secure it to the panel with The DPC-A3 digital pressure controller provides control the provided mounting tabs and screws.

  • Page 10: Electrical Connections

    Pulse Control Panel Revised 10/10 DPM/DPC 2.1.3.3 ELECTRICAL CONNECTIONS 2.1.4 OPERATION 2.1.4.1 DISPLAY KEY FUNCTION NOTES: 1. Supply Voltage is universal The DPC-A3 has four buttons located on the face of the control used for programming an up arrow, down arrow, from 20-240 VAC or VDC.

  • Page 11: Programming

    Pulse Control Panel Revised 10/10 DPM/DPC 2.1.5 PROGRAMMING The main menu consists of Set Point 1 Low (SP 1 lo), Set Point 1 High (SP 1 hi), Set Point 2 Low (SP 2 lo), and Set Point 2 High (SP 2 hi). SP 1 lo and SP 1 hi is the pulse cleaning for the dust collection system with SP1 lo set at 2.5 and SP 1 hi set at 3.0.

  • Page 12: Installation

    Pulse Control Panel Revised 10/10 DPM/DPC 2.2.3 INSTALLATION 2.2.4.2 KEY FUNCTION 2.2.3.1 PRESSURE CONNECTION The DPM-A2 has four buttons located on the face of the gauge for set-up and calibration. There is a Span, Zero, Two 3/16" pressure connections are located on the back Units, and Lock button.
  • Page 13 Pulse Control Panel Revised 10/10 DPM/DPC need to apply 8” inwc of negative pressure to the LOW pressure port on the gauge. Nothing should be connected to the HIGH pressure port. You can reset the value by holding the Span key for three seconds. The 4-20 mA process output is set to give a linear output from 0 to the full scale pressure range of the product.
  • Page 14 Pulse Control Panel Revised 10/10 DPM/DPC This page intentionally left blank...
  • Page 15 Pulse Control Panel Revised 10/10 DPM/DPC This page intentionally left blank...
  • Page 16 UNITED AIR SPECIALISTS, INC. LIMITED WARRANTY UAS warrants to the original purchaser that all equipment will be free from defects in materials and workmanship for one year from the date of shipment from UAS (three years for Smokeeter® and VisionAir™ models other than CC and DC series) and that major structural components on SFC and MCB series will be free from defects in materials and workmanship for ten years from the date of shipment from UAS.
