USER MANUAL
FX-SERIES & WX-SERIES FRONTLINERS
EN | Original RESQTEC user manual
WWW.RESQTEC.COM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FX Series and is the answer not in the manual?

Questions and answers

Summary of Contents for RESQTEC FX Series

  • Page 1 USER MANUAL FX-SERIES & WX-SERIES FRONTLINERS EN | Original RESQTEC user manual WWW.RESQTEC.COM...

  • Page 2: Table Of Contents

    Preparation before use 4.3. Operation 4.4. Optimized 350 bar 4.5. Quick action couplers 4.6. Connecting the Resqtec NEO1 coupler 4.7. Disconnecting the Resqtec NEO1 coupler 4.8. Connecting the Resqtec STD coupler 4.9. Disconnecting the Resqtec STD coupler 4.10. Using the pressure release 4.11.

  • Page 3: Introduction: Safety First

    1.2 GENERAL SAFETY INFORMATION The Resqtec equipment is designed to provide safe operation. All users should read and be thoroughly familiar with the operating instructions and safety precautions stated in this manual. Operator safety depends on users being properly trained by the Authority having jurisdiction and using the equipment for its intended purposes only.

  • Page 4: Safety Information

    Failing to do so may result in damage to the hose assembly and malfunction of your Resqtec system. • Make sure no one on site is in danger or might get, when using Resqtec equipment. Be aware of your surroundings, the situation you and the people around you are in, and what the consequences of the use of the Resqtec system are.

  • Page 5: Applicable Types

    USER MANUAL FX-SERIES & WX-SERIES FRONTLINERS 1.5 APPLICABLE TYPES This manual covers the following product types: Article number Item description 4220.0000.** 5245.0200.** FX4-Fj 5265.0200.** FX6-Fj 5243.0100.** G4WX RESQTEC Manual FRONTLINER FX-Series (DM003K14)

  • Page 6: Product Summary

    Read all the instructions before using the product to assure safe and optimal use of the product. These instructions contain aspects relevant to safe and optimal use of the product. The product has been manufactured by Resqtec Zumro. For addresses, please refer to the last page of this manual or to our internet site at www.resqtec.com.
  • Page 7 USER MANUAL FX-SERIES & WX-SERIES FRONTLINERS 2.3.2 FX4-FJ / FX6-FJ FRONTLINER CARRYING HANDLE CONTROL HANDLE PROTECTION COVERS NEO1 (MALE) COUPLER FIXED SPREADER JAW FRONTLINER BLADE PULLING JAW SLOT RESQTEC Manual FRONTLINER FX-Series (DM003K14)
  • Page 8 USER MANUAL FX-SERIES & WX-SERIES FRONTLINERS 2.3.2 G4WX FRONTLINER CARRYING HANDLE CONTROL HANDLE PROTECTION COVERS NEO1 (MALE) COUPLER FIXED SPREADER JAW FRONTLINER BLADE RESQTEC Manual FRONTLINER FX-Series (DM003K14)

  • Page 9: Product Range

    USER MANUAL FX-SERIES & WX-SERIES FRONTLINERS 3. PRODUCT RANGE 3.1 PRODUCTS & ACCESSORIES Article number Item description Picture Usage & Restrictions 4220.0000.** 5245.0200.** FX4-Fj 5265.0200.** FX6-Fj 5243.0100.XX G4wx RESQTEC Manual FRONTLINER FX-Series (DM003K14)
  • Page 10 SET OF 2 PULLING 2130.4280 JAWS FX2 NOT COMPATIBLE WITH FX4-FJ/FX6-FJ CHAIN & SHACKLE 2305.5000 SET FX2 NOT COMPATIBLE WITH FX2/FX6-FJ CHAIN & SHACKLE 2305.5100 SET FX4-Fj NOT COMPATIBLE WITH CHAIN & SHACKLE FX2/FX4-FJ 2305.5200 SET FX6-Fj RESQTEC Manual FRONTLINER FX-Series (DM003K14)

  • Page 11: General Operating Instructions

    CHECK THE EQUIPMENT FOR EXTERNAL DAMAGE. NOTIFY THE SUPPLIER IMMEDIATELY IF ANY DAMAGE IS FOUND. DO NOT USE DAMAGED EQUIPMENT UNDER ANY CIRCUMSTANCE! In general we distinguish a couple of different types of operations; • Connecting the Resqtec NEO1 coupler • Disconnecting the Resqtec NEO1 coupler • Connecting the Resqtec STD coupler •...

  • Page 12: Operation

    In this manual the Resqtec NEO1 couplers and the Resqtec STD couplers are described; follow the instructions of your current couplers only. RESQTEC Manual FRONTLINER FX-Series (DM003K14)

  • Page 13: Quick Action Couplers

    4.5 QUICK ACTION COUPLERS The Resqtec products are standard equipped with NEO1 quick action automatic by-pass couplers. This makes it possible to connect and disconnect both pressure and return in one simple motion. It also allows you to connect and disconnect under full pump free flow pressure. If your product is supplied with STD connectors, the connectors for pressure and return are separated.

  • Page 14: Disconnecting The Resqtec Neo1 Coupler

    USER MANUAL FX-SERIES & WX-SERIES FRONTLINERS 4.7 DISCONNECTING THE RESQTEC NEO1 COUPLER 4.7 DISCONNECTING THE RESQTEC NEO1 COUPLER Rotate the NEO1 female coupler unlock ring in the direction of the arrow and pull backwards. Make sure the control handle of the tool is not engaged when disconnecting (neutral position).

  • Page 15: Connecting The Resqtec Std Coupler

    USER MANUAL FX-SERIES & WX-SERIES FRONTLINERS 4.8 CONNECTING THE RESQTEC STD COUPLER 4.8 CONNECTING THE RESQTEC STD COUPLER Check whether the pump relief valve is in its neutral/release pressure relief position (with exception of NEO1). NEVER CONNECT THE COUPLERS IF THE PUMP IS SWITCHED TO OPERATION.

  • Page 16: Using The Pressure Release

    NOTE THAT A SLIGHT AMOUNT OF HYDRAULIC FLUID WILL EJECT AT THIS POINT! MAKE SURE TO WEAR PROTECTIVE CLOTHING. For STD couplers a separate pressure release tool is available. Contact your distributor/supplier for details. RESQTEC Manual FRONTLINER FX-Series (DM003K14)

  • Page 17: Operating The Product

    Keep the handle to the right. BEFORE STORING THE PRODUCT IT IS RECOMMENDED TO DEPRESSURIZE THE CYLINDER. TO DO THIS, OPEN THE BLADES TO THE POINT WHERE ONLY THE TIPS TOUCH EACH OTHER. RESQTEC Manual FRONTLINER FX-Series (DM003K14)

  • Page 18: Removing & Placing The Fx2 Spreading Jaws

    4.12 REMOVING & PLACING THE FX2 SPREADING JAWS REMOVING THE TIPS Push/pull the pin out. Remove the spreader tip/jaw. PLACING THE TIPS Place the spreader tip/jaw on the blades. Push the pin back in its slot to secure the jaw. RESQTEC Manual FRONTLINER FX-Series (DM003K14)

  • Page 19: Attaching & Detaching Pulling Jaws & Chains And Shackles

    4.12. Attach the dedicated pulling jaws. Push the pin into its slot to secure the pulling jaws. Attach the chain shortners from the chain and shackle set to the pulling jaws with the supplied pins. RESQTEC Manual FRONTLINER FX-Series (DM003K14)

  • Page 20: Fx4-Fj / Fx6-Fj / G4Wx

    Before aligning the pulling jaw with the pulling jaw slot, make sure the direction indicator is aimed towards the fixed spreader jaw. Align the pulling jaw with the pulling jaw slot. Push the pin into its slot to secure the pulling jaw. RESQTEC Manual FRONTLINER FX-Series (DM003K14)
  • Page 21 USER MANUAL FX-SERIES & WX-SERIES FRONTLINERS The pulling jaw is now attached. Push the knob to unlock, and align and fixate the chain in the pulling jaw’s chain recess. RESQTEC Manual FRONTLINER FX-Series (DM003K14)
  • Page 22 Pull the pin from the pulling jaw slot to release the pulling jaw. Remove the pulling jaw and push the pin back, to prevent losing it. The chain doesn’t have to be removed. The pulling jaw is now detached. RESQTEC Manual FRONTLINER FX-Series (DM003K14)

  • Page 23: Specifications

    59.4 - 70.7 kN / 6.0 - 7.2 ton Squeezing force 25mm from tips 43.3 - 48.7 kN / 4.4 - 5.0 ton NFPA HPF 43.9 kN – 4.5 ton NFPA LPF 39.0 kN – 4.0 ton EN 13204 classification CK36.3-352I-11.4 CK36.3-352I-12.6 RESQTEC Manual FRONTLINER FX-Series (DM003K14)
  • Page 24 Pulling force (in pulling eyes) Squeezing force 25mm from tips 41.4 - 47.5 kN / 4.2 - 4.8 ton NFPA HPF 42.8 kN – 4.4 ton NFPA LPF 36.2 kN – 3.7 ton EN 13204 classification BK33.8-367F-11.3 BK33.8-367F-12.5 RESQTEC Manual FRONTLINER FX-Series (DM003K14)

  • Page 25: Imperial System Data

    59.4 - 70.7 kN / 13,354 – 15,894 lbf Squeezing force 25mm from tips 43.3 - 48.7 kN / 9,734 – 10,948 lbf NFPA HPF 43.9 kN – 9,869 lbf NFPA LPF 39.0 kN – 8,767 lbf EN 13204 classification CK36.3-352I-11.4 CK36.3-352I-12.6 RESQTEC Manual FRONTLINER FX-Series (DM003K14)
  • Page 26 Pulling force (in pulling eyes) Squeezing force 25mm from tips 41.4 - 47.5 kN / 944 – 1,079 lbf NFPA HPF 42.8 kN – 989 lbf NFPA LPF 36.2 kN – 832 lbf EN 13204 classification BK33.8-367F-11.3 BK33.8-367F-12.5 RESQTEC Manual FRONTLINER FX-Series (DM003K14)

  • Page 27: Cutting Capabilities

    USER MANUAL FX-SERIES & WX-SERIES FRONTLINERS 5.2 CUTTING CAPABILITIES Resqtec cutting tools are designed and manufactured in accordance with EN- and NFPA-certifications and classifications. The following tables represent the EN- and NFPA-classification system: Categorizing according to EN 13204 – Metric system...

  • Page 28: Technical Drawings

    USER MANUAL FX-SERIES & WX-SERIES FRONTLINERS 5.3 TECHNICAL DRAWINGS The technical drawings in this chapter only present actual product dimensions. Coupler dimensions are excluded from these drawings. 5.3.1 SI-SYSTEM DATA FX4-Fj FX6-Fj G4WX RESQTEC Manual FRONTLINER FX-Series (DM003K14)

  • Page 29: Imperial System Data

    USER MANUAL FX-SERIES & WX-SERIES FRONTLINERS 5.3.2 IMPERIAL SYSTEM DATA FX4-Fj FX6-Fj G4WX RESQTEC Manual FRONTLINER FX-Series (DM003K14)

  • Page 30: Maintenance & Storage

    • Mild soapy water can be used if necessary. Dry thoroughly after using water. Do NOT use any oil. Check the couplers and dust caps for • Use dry, paper cloth. dirt. Clean if necessary. RESQTEC Manual FRONTLINER FX-Series (DM003K14)
  • Page 31 PURPOSES, ONLY USE CRC SP 400. OTHER PRODUCTS ARE KNOWN TO HAVE NEGATIVE EFFECTS ON THE LUBRICANT USED IN YOUR EQUIPMENT. OTHER PRODUCTS ALSO DO NOT HAVE THE HIGH PROTECTION GRADE THAT CRC SP 400 PROVIDES. RESQTEC Manual FRONTLINER FX-Series (DM003K14)

  • Page 32: Regular Maintenance

    Connect all components and test all functions. • All products should make at least two complete cycles. DO NOT TAKE UNNECESSARY RISK BY UTILIZING FAULTY HOSES. WORN OR DAMAGED HOSES CAN CAUSE SERIOUS INJURY AND/OR DAMAGE TO THE RESQTEC SYSTEM AND OTHER PROPERTY. RESQTEC Manual FRONTLINER FX-Series (DM003K14)

  • Page 33: Annual Maintenance

    Many years of safe use is guaranteed if the product is properly cared for and maintained. To this end the product must be inspected at least once a year. This must be carried out by a service technician trained by Resqtec who possesses the necessary tools and testing equipment.

  • Page 34: Warnings & Limitations

    BEFORE USING THE PRODUCT, BE AWARE OF THE FOLLOWING: • Resqtec equipment is designed for rescue/salvage operations only and may not be used for industrial purposes. • Do not try to perform tasks that exceed the specifications of the particular product. The specifications clearly define the product capabilities.

  • Page 35: Troubleshooting

    • Make sure there is enough hydraulic oil and gasoline in the power unit. IF YOU CANNOT FIND THE PROBLEM THAT OCCURRED, OR IF THE PROVIDED SOLUTION DID NOT RESOLVE THE PROBLEM, STOP USING THE PRODUCT IMMEDIATELY AND CONTACT A CERTIFIED DISTRIBUTOR/SUPPLIER OR ONE OF THE RESQTEC OFFICES. RESQTEC Manual FRONTLINER FX-Series (DM003K14)

  • Page 36: Warranty

    USER MANUAL FX-SERIES & WX-SERIES FRONTLINERS 9. WARRANTY Resqtec offers two years warranty upon the purchase of this product. For extending your warranty or information about the Resqtec service program, please contact your Resqtec distributor/supplier. WARRANTY IS ONLY VALID IF THE REGULATIONS AND RESTRICTIONS, AS DESCRIBED IN THE USER MANUAL APPLICABLE ON THE USED PRODUCT(S), ARE UNDERSTOOD AND FOLLOWED, AND IF THE MAINTENANCE AS ADVISED IN THE USER MANUAL IS DONE BY AN AUTHORIZED RESQTEC TECHNICIAN.

  • Page 37: Disclosure

    Subang Hi-Tech Industrial Park T +31 (0)252 419002 T: +1 973 627 4646 47 500 Selangor, Malaysia F +31 (0)252 411794 F: +1 973 627 4622 T +603 5621 5298 F +603 5621 2895 info@resqtec.com www.resqtec.com RESQTEC Manual FRONTLINER FX-Series (DM003K14)
  • Page 38 RESQTEC Zumro B.V. Meer en Duin 82 2163 HC Lisse, the Netherlands +31 (0)252 419002 +31 (0)252 411794 info@resqtec.com...
