Summary of Contents for AEM F820
- Page 1 Operation manual Please read this instruction manual carefully before operating safely. Please keep it in a safe place after reading AEM Ｃ Ｏ ． ， Ｌ Ｔ Ｄ The factory:1206-2 Nikoda Ueda City Nagano Prefecture Japan 〒 386-1544 TEL:+81(0)268-31-0155 FAX:+81(0)268-31-0160...
- Page 2 Pneumatic grab maintenance machine （ Pressurized type ） Ｍ ｏ ｄ ｅ ｌ ： Ｆ ８ ２ ０ Thank you for purchasing the AEM product. Please read this manual carefully before using it. ［ Safety Precautions ］ This instruction manual explains how to handle, use, and install the compressor for those who work and those who perform maintenance and inspection.
- Page 3 【 ２ 】 ： Structure and specifications 【 】 Construction ① ： Pressurized cylinder 80 φ -200 stroke Reference Pressure of about 280 kg/617lb at 0.6 MPa ② ： Cylinder operation valve AC100/110V operation ③ ： Pressurizing jig Resin push jig ④...
- Page 4 【 ３ 】 ： Control panel explanation After inserting the power switch 100 / 110V plug, turn it on and the power lamp of ② will light up. ① ： If you operate the foot switch in this state, the cylinder will descend and pressure will be applied to the grab. When the switches ①...
- Page 5 【 ４ 】 ： Description of air regulator ⑦ ： Air regulator body Air supply coupler (30PM) ⑧ ： ⑨ ： Adjust the air pressure adjustment knob by pulling it up. Tighten it to the right when viewed from above to increase the pressure.
- Page 6 【 ５ 】 ： Description of grab pressurizing jig ⑭ ： Pressurized jig flat Pressurized jig circle ( for pocket) ⑮ ： Prepared according to the purpose of kneading and molding the grab ( standard comes with one flat) ⑯ ： Jig mounting screw is a connection part between the grab pushing jig and the cylinder.
- Page 7 By doing so, you can work with peace of mind. ２ ） When the air regulator is maximized, a force of 450 kg/987lb or more is applied. Work with the appropriate pressure for the grab. F820 取 扱 説 明 E-2A - 7 -...
