3.837.5275.209
Electric Transducers Current to pressure ITV1030
Installation and Maintenance Instructions
Attention: additional instructions are required when a ATEX intrinsically safety
instrument ITV1030 is used in an explosion risk area
E X P E R T I S E
S O L U T I O N S
Manufactured for
S U S T A I N A B I L I T Y
EMM Issue 1 IT - 2018
1. General Safety Information
2. General Product Information
3. Installation
4. Wiring
5. How to Order
6. Outline Dimensions (mm)
7. Maintenance and Inspection
8. Limitations of Use
© Copyright 2018
Advertisement
Table of Contents
Summary of Contents for Spirax Sarco ITV1030
- Page 1 Electric Transducers Current to pressure ITV1030 Installation and Maintenance Instructions Manufactured for Attention: additional instructions are required when a ATEX intrinsically safety instrument ITV1030 is used in an explosion risk area 1. General Safety Information 2. General Product Information 3. Installation 4.
- Page 2 3.837.5275.209...
-
Page 3: General Safety Information
9. Tools and consumables Before starting work ensure that you have suitable tools and /or consumables available. Use only genuine Spirax Sarco replacement parts. Protective clothing Consider whether you and / or others in the vicinity require any protective clothing to protect against the hazards of, for example, chemicals, high / low temperature, radiation, noise, falling objects, and dangers to eyes and face. -
Page 4: Returning Products
Customers and stockists are reminded that under EC Health, Safety and Environment Law, when returning products to Spirax Sarco they must provide information on any hazards and the precautions to be taken due to contamination residues or mechanical damage which may present a health, safety or environmental risk. -
Page 5: General Product Information
2. General product information 2.1 Specifications Model ITV1030-01F1BN4-DIU00490 Min. supply pressure Set pressure + 15 psi Max. supply pressure 145 psi Set pressure range da 0.7 to 70 psi Supply voltage DC24 V±10% Current consumption DC2A or less Input signal... -
Page 6: Principio Di Funzionamento
Note 5: Value for the state with no over current included. If an allowance is provided for an over current circuit, the input impedance varies depending on the input current. This is 350Ω or less for an input current of 20 mA DC. Nota 6: Collegare l'elettrovalvola esterna alla stessa fonte di alimentazione del regolatore E/P. -
Page 7: Installation
3. Installation Installation • Do not install the product unless the safety instructions have been read and understood. • This product is pre-set at the factory and must not be dismantled by the user. Contact your local SMC office for advice. •... - Page 8 Thread Tightening Torque (Nm) 3 to 5 Lubrification • Do not use a lubricator on the supply side of this product, as this can cause malfunction. When lubrication of terminal equipment is necessary, connect a lubricator on the output side of this equipment.
- Page 9 Wiring diagram Current / Voltage type Brown Power supply 24 VDC Blue Power supply Input signal 4~20 mADC White Black Input signal Monitor output wiring diagram Analogue output - Voltage type Brown Blue White Monitor output voltage Only use equipment with minimum load impedance of Black 100 kΩ.
-
Page 10: How To Order
5. How to Order How to order Pressure Range Special order 3 : 0.7 to 70 psi Pressure Display Unit 4 : psi Power Supply Voltage Port Size 0 : DC24V ± 10% 1 : 1/8 Input Signal Cable Connector Type 0 : Current DC 4 to 20mA N : Without Cable Connector Thread Type... -
Page 11: Limitazioni D'impiego
7. Maintenance and inspection • Not following proper maintenance procedures could cause the product to malfunction and lead to equipment damage. • If handled improperly, compressed air can be dangerous. Maintenance of pneumatic systems should be performed only by qualified personnel. •... - Page 12 SERVICE For technical support, please contact our local Sales Engineer or our Head Office directly: Spirax Sarco S.r.l. - Technical Assistance Via per Cinisello, 18 - 20834 Nova Milanese (MB) - Italy Tel.: (+39) 0362 4917 257 - (+39) 0362 4917 211 - Fax: (+39) 0362 4917 315 E-mail: support@it.spiraxsarco.com...
