ImproX (DBv) Vertical Mount Drop Box
SPECIFICATIONS
Read/Write Capability ..................
Working Environment
XDB902-1-0-GB-XX ...............
XDB903-1-0-GB-XX ...............
Input Voltage ................................
Power Requirements
Input Voltage 12 V DC
Solenoid OFF .........................
Input Voltage 12 V DC
Solenoid ON ...........................
Solenoid
Input Voltage ..........................
Type .......................................
Relays
Relay Output ..........................
Relay Allocation
Relay 1 ...........................
Relay 2 ...........................
I
MPRO
INSTALLATION MANUAL
MODEL NUMBER: XDB902-1-0-GB-XX
X DB
Impro Tags: All standard ImproX Credit Card
Tags, with or without the slot and clip.
Third-party Tags: Read only capabilities on
selected third-party Credit Card Tags.
Mounted in a suitably rated, user supplied
cabinet; the Drop Box is designed to work in
an indoor or outdoor environment similar to
IP54.
The Drop Box is designed to work in an indoor
or outdoor environment similar to IP66.
12 V DC, polarity sensitive.
Current (mA)
45
800
12 V DC.
Push, pull action.
2 Relays each with NO, COM and NC
contacts.
Factory configured to drive the Solenoid when
a Tag is inserted and read inside the Drop
Box.
User configured to control hardware at the exit
point (typically a boom, vehicle gate or
turnstile).
XDB903-1-0-GB-XX
V
Power (W)
0.54
9.60
Advertisement
Summary of Contents for impro IMPROX DBV
- Page 1 ImproX (DBv) Vertical Mount Drop Box INSTALLATION MANUAL SPECIFICATIONS Read/Write Capability ....Impro Tags: All standard ImproX Credit Card Tags, with or without the slot and clip. Third-party Tags: Read only capabilities on selected third-party Credit Card Tags. Working Environment XDB902-1-0-GB-XX ....
- Page 2 Relays (Continued) Relay Contact Ratings ... 3 A at 24 V DC or 125 V AC. 1.5 A at 220 V AC. Digital Inputs Type ........4 Dry-contact inputs. Protection Range ....+50 V to -50 V continuous, +80 V to -80 V surge. LED “Diagnostic Indicators”...
-
Page 3: Installation Information
Find the following when unpacking the ImproX DBv: NOTE: The ImproX TD included in the construction of the ImproX DBv uses the standard ImproX TT Hardware, with modified Firmware. The ImproX TD will NOT, however, operate as an ImproX TT. - Page 4 Drop Box Connection Distance between Drop Boxes To avoid mutual interference, install the Drop Boxes alongside each other at least 500 mm (20 in) apart. Antenna Reader Connection Antenna Reader Distance As the Drop Box makes use of the connections to “Reader 1”, “Reader 2” is available for connection to any ONE of the available Antenna Readers.
- Page 5 Mounting the Drop Box CAUTION: Make certain that you mount the Drop Box on a vibration-free surface. NOTE: The Drop Box can be mounted against virtually any surface, including metal, a maximum of 25 mm (0.98 in) thick. XDB902-1-0-GB-XX Mount the Drop Box against the side of a counter taking into consideration any security issues, accessibility, routing of wires and visibility of the “Diagnostic Indicators”.
- Page 6 XDB903-1-0-GB-XX Mount the Drop Box in a suitable location on a cement slab. Take into consideration any security issues, accessibility, routing of wires and visibility of the “Diagnostic Indicators”. Figure 3: Tag Retention Box Position Position the Mounting Bracket inside the base of the Drop Box. Mark out and drill the mounting hole.
- Page 7 Emptying the Tag Retention Box Unlock the Tag Retention Cabinet. Lift the Tag Retention Box off the lip located at position 1 (see Figure 3). Turn the Tag Retention Box so that the lip faces away from the open Cabinet door. Hang the Tag Retention Box on the lip located at position 2 (see Figure 3).
-
Page 8: Electrical Connections
ELECTRICAL CONNECTIONS Typical Electrical Connections Figure 4 shows a typical electrical connection diagram for the ImproX DBv. Figure 4: Typical ImproX DBv Electrical Connections XDB300-0-0-GB-04 December 2007 Page 8... - Page 9 Fixed Address Label Once the ImproX DBv is installed, sketch a rough site plan. Attach the loose (additional Fixed Address Labels packaged with the Drop Box) Fixed Address Labels in the position of the Drop Box on the sketched site plan. When the system installation is complete and all the units are represented on the site plan by their Fixed Address Labels, file the site plan for future reference.
- Page 10 USER NOTES XDB300-0-0-GB-04 December 2007 Page 10...
- Page 11 USER NOTES XDB300-0-0-GB-04 December 2007 Page 11...
- Page 12 USER NOTES This manual is applicable to the ImproX (DBv) Vertical Mount Drop Box, XDB902-1-0-GB-02 and XDB903-1-0-GB-01. (The last two digits of the Impro stock code indicate the issue status of the product). ImproX DBv\English Manuals\LATEST ISSUE XDB300-0-0-GB-04 Issue 05 \ImprXDBv-insm-en-05.docx...
