Summary of Contents for Keizer Nuage PLS
- Page 1 Zitsysteem | Seating system | Système d’assise Siddesystem | Sitte-system Nuage PLS USER MANUAL GEBRUIKERSHANDLEIDING NOTICE D’UTILISATION BRUGERMANUAL NUAGE PLS BRUKERMANUAL NUAGE PLS ACTIVE NUAGE PLS ACTIVE XS 9011307F...
- Page 2 This manual describes how to use Keizer’s Nuage PLS seating system in combination with Sunrise Medical HCM’s Ibis wheelchair with Sedeo Pro seating system. If you want to use the Nuage PLS seating system in a different combination, ask Keizer about the options and for the appropriate manual.
- Page 3 Safety ..........................34 Temperature Moving parts General safety rules and regulations Product description ......................35 Nuage PLS series Positioning options and accessories Use ............................37 Getting into and out of the seat Reducing the seating system in size for transportation Use as a passenger seat in a vehicle Adjusting the seating system Set-up (by a rehabilitation engineer) .................39...
- Page 4 Nuage Maintenance ........................47 Cleaning the upholstery Replacing the upholstery Reuse Technical specifications ......................48 Technical information Warranty ..........................49 Labelling ..........................50 10.1 Markings on the seating system The PLS seating system and optional system components..........51...
- Page 5 Revalidatiestoffeerderij Keizer B.V. contributes to a more independent and pleasant Gildestraat 18 lifestyle. 7622 AC Borne Tel.: +31 (0)74 - 250 16 65 The Nuage PLS Seating System is intended to be E-mail: info@keizerstoffeert.nl used in combination with so-called tilt-in-space Web : www.keizerstoffeert.nl wheelchairs. Warning! Warnings for the user to prevent personal injury.
-
Page 6: Symbols Used In This Manual
Nuage 1.3 Symbols used in this manual Lot number Warning! Legal manufacturer Warnings for the user to prevent personal injury. Caution! Advice for the user to prevent damage to the product. Symbols in illustrations Some illustrations include icons and numbering to indicate what needs to be done and in which order. -
Page 7: Moving Parts
Nuage 2 Compatibility 3.3 General safety guidelines and instructions All Nuage PLS seating systems and components are compatible and have passed crash tests in Keizer accepts no liability whatsoever for damage combination with the Sedeo Pro seating system or injury caused by failure to (strictly) adhere by Sunrise Medical HCM. -
Page 8: Product Description
The Nuage seating system reduces prolonged pressure on body parts and is, therefore, important for your health and comfort. Nuage PLS seating systems are compatible with (tilt-in-space) wheelchairs of many different brands. For more information, please contact Keizer or check www.nuagezitstemen.nl 4.1 Nuage PLS series... - Page 9 Nuage 4.2 Positioning, optional system components Nuage PLS seating systems offer a number of adjustment options to optimise the positioning and support for each individual user. With the adjustable webbing straps, the seat and backrest contours can be accurately aligned with the body contours of the user.
-
Page 10: Reducing The Seating System In Size For Transportation
Nuage 5 Use Nuage PLS seating systems are intended for use on tilt-in-space wheelchairs. The tilt makes it possible to easily change the seating position. It also reduces prolonged pressure on body parts and is, therefore, important for your health and comfort. -
Page 11: Use As A Passenger Seat In A Vehicle
Please note that a seating posture belt or fixation belt is not a safety belt. 5.4 Adjusting the seating system The adjustment possibilities and the way of adjusting depend on the wheelchair frame on which the Nuage PLS seating system is mounted. Note! Refer to information about wheelchair-specific adjustment options ( Wheelchair). - Page 12 How to set up the seating system can differ by wheelchair make and model. The wheelchair- specific settings are marked with the addition ‘(wheelchair-specific)’. In this manual, the instructions and figures refer to the set-up of a Nuage PLS system on an Ibis wheelchair with Sedeo Pro seating system. Note! If you have a different wheelchair, i.e. not an Ibis with Sedeo Pro, check your wheelchair’s manual ( Wheelchair) or contact your dealer.
-
Page 13: Seat Webbing
Nuage 6.2 Seat and backrest shells The seat (D) and backrest (E) shells have a number of slotted holes. These slotted holes are intended to make it simple to make a large number of different adjustments using the webbing straps. The middle row of slots is for standard use (as indicated in figure 9). The other positions can be used to, for example, better follow the body contour or compensate for pelvic obliquity. - Page 14 Nuage Given that the required seat width differs per person, the Nuage PLS and the Nuage PLS Active seating systems come as standard with a split threshold cushion (C) made up of four segments. The two outer segments and two inner segments are kept together by a Velcro strip.
-
Page 15: Pelvic Obliquity
Nuage 6.5 Pelvic obliquity Create an asymmetrical support by choosing different slotted holes (F1 to F5) left and right. Loop the webbing straps (B) through slotted holes (F1 to F5) or, if required, over edge (G), and tension. 6.6 Leg length discrepancy Move one of the seat shells (D1) forwards. To do so, loosen the armrest holder, slide it in the rail towards the front of the seat and fasten again. On (D1) shift the position of the webbing straps (B) one slot position to the rear. -
Page 16: Dorsal Obliquity
Nuage 6.8 Dorsal obliquity Create an asymmetrical support by choosing different slotted holes (J1 to J3) left and right. Loop the webbing straps (B) through slotted holes (J1 to J5) or, if required, over edge (G), and tension. 6.9 Tensioning the cover Free the cover back flap (O) by detaching the Velcro ends (P) at the bottom of the flap from the Velcro surfaces on the seat shells. Untie the elastic rope (Q) in the hem of the cover. Position the cover as required. Tension and secure the elastic rope (Q). Close the back flap (O) by attaching the Velcro ends (P) to the Velcro surfaces on the seat shells. 6.10 Cushion filling Remove the cover (A). Open the zipper (R). Add or remove filling (S). - Page 17 Nuage 6.11 Seat width (wheelchair specific) Determine the space you want between the shells. Bear in mind the thickness of the contour cushion. The right space between the edges of the shells (T) is twelve centimetres more than the required seat width (U), i.e.: (T) = (U) + 12 cm. Rough adjustment When mounting the seat, choose the screw hole pattern that fits the required seat width range: 30cm to 40cm, 40cm to 50cm, or over 50cm.
-
Page 18: Backrest Width
Nuage 6.13 Backrest width The seat width and backrest width are separately adjustable, so that a good position can be attained for people with broad hips/small shoulders as well as people with small hips/broad shoulders. If required, loosen the straps by detaching the Velcro ends on one end from the Velcro surfaces of the shells. - Page 19 Nuage 6.16 Angle backrest shells (wheelchair specific) If required, loosen straps (D). Loosen screws for shell angle adjustment (E). Turn backrest shells (B) inwards or outwards. Fasten (E) again. Tension the straps (D). 6.17 Backrest angle (wheelchair specific) 1. Turn (F) to adjust the inclination angle of the backrest (G). Warning! Alternatively, the wheelchair can be equipped with optional gas spring-actuated angle adjustment ( Wheelchair).
-
Page 20: Maintenance
7.3 Reuse dryer at low temperature and can also be ironed at low temperature. When the Nuage PLS seating system is set to be Warning! reused by another client, the party supplying the system to the new user must be certain that all Inserting the cushion filling incorrectly may relevant safety requirements are met. -
Page 21: Technical Specifications
Armrest width 12 or 16 Footplate width Footplate depth Integrated abduction cushion height *Specifications may vary depending on the wheelchair configuration and settings. **Other specifications depend fully on the wheelchair on which the seating system is fitted. The Nuage PLS Active Seating System including matching terry cloth covers meet the following specifications *) Description Unit Maximum user weight Seat width 38 - 55... -
Page 22: Warranty
**Other specifications depend fully on the wheelchair on which the seating system is fitted. 9 Warranty Keizer, being the manufacturer of the Nuage PLS seating system, issues a 1-year warranty for the seat and backrest shells and assembly set. Keizer also issues a 1-year warranty for the quality of the stitching of contour cushions and terry cloth covers. Warranty claims will be accepted only in the event of a manufacturing fault. -
Page 23: Markings On The Seating System
Never remove or cover up the markings, symbols and instructions affixed to the seating system. These safety features must remain present and clearly legible throughout the entire lifespan of the seating system. KZR 200000 model: Nuage PLS Active Revalidatiestoffeerderij Keizer B.V. Gildestraat 18 7622AC Borne The Netherlands... - Page 24 Nuage PLS seating system Nuage PLS Active seating system Nuage PLS Active XS seating system Nuage PLS seating system with abduction Nuage PLS Active seating system with abduction Nuage PLS Active XS seating system with abduction Optional components Headrest (I) Headrest XS (I) Drop-shaped head roll cushion (H)
- Page 25 Bamboo terry cloth cover for Nuage PLS with abduction Bamboo terry cloth cover for Nuage PLS Active with abduction Bamboo terry cloth cover for Nuage PLS Active XS with abduction Bamboo terry cloth cover for Nuage PLS armrest Bamboo terry cloth cover for Nuage PLS drop-shaped head roll cushion...
- Page 26 Nuage Nuage seating systems are products of Revalidatiestoffeerderij Keizer B.V. and are in conformity with the relevant requirements of the Medical Device Regulation (EU) MDR 2017/745.
