Summary of Contents for Illuminated Mirrors Diamond X 100877K145
- Page 1 www.illuminated-mirrors.uk.com Model: Corner Sensor Cabinets Diamond X Collection | From www.illuminated-mirrors.uk.com INSTRUCTION MANUAL...
- Page 2 www.illuminated-mirrors.uk.com Model: Corner Sensor Cabinets Diamond X Collection | Corner Cabinets Mirrors with Shaver Sockets and Sensors (Model Numbers: 100877K145, K146, K147, K148) Thank you for purchasing our illuminated mirror cabinet(s). To avoid product damage, personal injuries, carefully read, understand, and follow all the Instructions in this installation guide before installing the product.
- Page 3 www.illuminated-mirrors.uk.com Model: Corner Sensor Cabinets Diamond X Collection | WARNING! To avoid the risk of electrocution, please turn off the electricity supply mains before commencing the installation. INSTRUCTION MANUAL...
-
Page 4: Table Of Contents
www.illuminated-mirrors.uk.com Model: Corner Sensor Cabinets Diamond X Collection | CONTENT I. STANDARDS a. Safety Instructions b. IP Rating c. Bathroom Zones II. MIRROR CABINET PARTS III. STEP-by-STEP INSTALLATION Step 1: Remove top mirror panel carefully with a screw driver. Step 2: Remove LED strip / Fluorescent bulb to gain access to the cable entry hole. Step 3: Offer the cabinet up to the required position and mark the holes on to the wall for drilling (Cabinet is heavy and we suggest 2 people for this job). -
Page 5: Standards
www.illuminated-mirrors.uk.com Model: Corner Sensor Cabinets Diamond X Collection | I. STANDARDS a. Safety Instructions Installation of this product can require a qualified electrician. If necessary, hire or consult a qualified electrician in accordance with the current IEE Wiring Regulations and UK Building Regulations for assistance before continuing. - Page 6 www.illuminated-mirrors.uk.com Model: Corner Sensor Cabinets Diamond X Collection | II. CABINET PARTS (Figure i) – Corner Cabinet with closed door. (Figure ii) – Corner Cabinet with open door. INSTRUCTION MANUAL...
- Page 7 www.illuminated-mirrors.uk.com Model: Corner Sensor Cabinets Diamond X Collection | III. INSTALLATION Please turn off the electricity supply mains before commencing the installation. Wiring Colours: Earth (E) GREEN Neutral (N) BLUE Live (L) BROWN Step 1: Remove top mirror panel with a screw driver. Step 2: ...
- Page 8 www.illuminated-mirrors.uk.com Model: Corner Sensor Cabinets Diamond X Collection | Step 3: Offer cabinet up to required fixing position and mark the holes for drilling using a pencil. Step 4: Pull the 240volt connection cable through the rubber grommet on the back plate. ...
-
Page 9: Step 6 (If Required)
www.illuminated-mirrors.uk.com Model: Corner Sensor Cabinets Diamond X Collection | Step 5: Refix top mirror panel on to the cabinet. Step 6 (If required): In case of loosened mirror door and the hinge during the transport, please adjust hinge and mirror door using a screw driver with the following illustrating diagrams. Please note cabinet door can only be adjusted when cabinet is fitted to the wall. - Page 10 www.illuminated-mirrors.uk.com Model: Corner Sensor Cabinets Diamond X Collection | After loosening Screw.1, please move the mirror door to the left or to the right, and make sure the mirror door is in the middle between two side mirror panels as show in the below diagram.
-
Page 11: Inward Positioning
www.illuminated-mirrors.uk.com Model: Corner Sensor Cabinets Diamond X Collection | (b) Inward Positioning Using a screw driver rotate Screw.2 to the left or to the right hand side, as shown below. Mirror door will be moved inwards or outwards from the cabinet by adjusting Screw.2 towards the left-hand side or right-hand side respectively, as shown below. -
Page 12: Step 7: Add Glass Shelves
www.illuminated-mirrors.uk.com Model: Corner Sensor Cabinets Diamond X Collection | Step 7: Add glass shelves. Step 8: And your cabinet is ready to use! INSTRUCTION MANUAL... -
Page 13: Care And Cleaning
www.illuminated-mirrors.uk.com Model: Corner Sensor Cabinets Diamond X Collection | IV. CARE AND CLEANING Please be aware when cleaning the mirror surface, do not to use abrasive materials as these will damage the overall finish. V. FAQs 1. On/Off Infra-Red Sensor? All our LED Mirrors include Infra-Red on/off Sensor, simply wave your hand to the sensor and it will instantly powers up the lights and demister pad.
