Summary of Contents for Clarity JOSEPH ABBOUD

  • Page 1 WATCH INSTRUCTIONS & 1 YEAR LIMITED WARRANTY...

  • Page 2: Setting The Watch

    SETTING THE WATCH: These instructions apply to a variety of watch styles. To change the Time, Day or Date on your analog watch, simply follow the accompanying instructions, A. NEUTRAL POSITION: This is the normal operating position of the watch in which the Crown is free to turn in either direction without any effect on the time.
  • Page 3 SETTING THE TIME ON STANDARD ANALOG WATCH STYLES: NOTE: The “standard” style has no Calendar or Day/Date “windows” on the dial, and unlike the above diagram, has only 2 Crown positions - Closed (‘A’) and Open (‘C’). To change the time, simply pull out the Crown all the way until it stops (position ‘C’). Rotate the Crown in either direction until the desired time is obtained.

  • Page 4: Setting The Time

    1L45, VD78 CROWN AT NORMAL POSITION TIME SETTING POSITION SMALL SECOND HAND SETTING THE TIME Pull the crown out to the time setting position. Turn the crown to set hour and minute hands. When the crown is pushed back to the normal position, second hand begins to run. NOTE: Never pull the Crown when the watch is wet.

  • Page 5: Day Of The Week

    CROWN AT NORMAL POSITION DATE SETTING POSITION TIME SETTING POSITION DATE DAY OF THE WEEK NOTE: *Date & Day of the week position may be located at different position depends on models. Day of the week may not be available.

  • Page 6: Setting The Date

    SETTING THE TIME Pull the crown out to the 2nd position. Turn the crown to set hour and minute hands. When the crown is pushed back to the normal position, second hand begins to run. NOTE: Never pull the Crown when the watch is wet. SETTING THE DATE Pull the crown out to the 1st position.
  • Page 7 24-HOUR HAND VD 54 B (Indicates the time on a 24-hour basis) BUTTON (A) *In stopwatch function Start/Stop CROWN AT NORMAL POSITION TIME SETTING POSITION BUTTON (B) *In stopwatch function Split/Split Release/Reset STOPWATCH STOPWATCH MINUTE HAND SECOND HAND (Move in minute increments) (Move in second increments)
  • Page 8 Before setting the time, check if the stopwatch second and minute hands are in the “60” (12 o’clock) position. If either of the stopwatch hands are not in the “60” position, reset them following the procedure below: Pull out the crown. Press button A or B to reset the stopwatch second and minute hands to “60”...

  • Page 9: How To Use The Stopwatch

    HOW TO USE THE STOPWATCH The measured time indicated by the stopwatch hands, move independently of the center and 24-hour hands. The stopwatch can measure up to 60 minutes in seconds. *Seconds elapsed up to one minute (6 o’clock eye) *Minutes elapsed up to one hour (9 o’clock eye) Before using the stopwatch, reset the stopwatch hands to the “60”(12 o’clock) position.
  • Page 10 DAY HAND VX9N (Indicates day of the week) BUTTON (A) (Day correction) CROWN AT NORMAL POSITION TIME SETTING BUTTON (B) (Date correction) 24-HOUR HAND (Indicates the time DATE HAND on a 24-hour basis)
  • Page 11 SETTING THE TIME (Never pull the Crown when the watch is wet) Pull out the crown to the 1st click position when the second hand is at the 12 o’clock position. The second hand will stop on the spot. Turn the crown to set the time taking AM/PM into consideration. NOTE: As the hour hands moves, the 24-hour hand moves correspondingly.
  • Page 12 6P29 FEATURES • Hours, Minutes, Seconds, Date and Day of the Week are displayed. • Date, Day and 24 Hour (Military Time) Sub Dials • Water Resistant from 100 ft. to 165 ft.
  • Page 13 NOTE: Actual watch case may be different. Look for the position of the Day, Date, Month or 24 Hour Sub Dials to see if this is your watch. SETTING THE TIME To Advance the Time, Day of the Week and 24 Hour (Military Time): A) Pull the Crown out to Position 3 and rotate the Crown clockwise or counter clockwise until the desired Time and Day are obtained.
  • Page 14 DIAGRAMS FOR ADJUSTABLE BRACELET WATCHES: 1. CLASP EXTENDER 2. HAIRCLIP PIN Metal Pin Push to close Turn over the watch to look for arrows on the underside of the links, showing you which way you need to push the pin out of the link. Use a pin remover tool to push out the “Hairclip Pin”...
  • Page 15 3. SLIDING BAR Lift up to open Slide along for adjustment Top of Band Push down when done Align protruded line inside the sliding part Grooves on the Back Side with desired groove in band Smallest size Largest size 4. FOLD-OVER BUCKLE Compress the push pin, and put the ends into the suitable holes along the buckle.
  • Page 16 EXTENDER TO MAXIMIZE THE SIZE OF THE FOLD-OVER CLASP FOR A LARGER WRIST (For a Smaller Size Wrist discard the Extender) If your watch did not come with the Extender, please call with the style number (which is engraved on the case back) and the Extender will be shipped to you.
  • Page 17 Dear Customer: Help your watch/jewelry retailer protect our environment by properly recycling the button cell battery in your watch. Professional jewelers and watch retailers are best equipped to replace the battery in your watch without damage to the watch case and movement inside. They have the specialized tools and experience to do the right job.

  • Page 18: Changing The Battery

    CHANGING THE BATTERY: Replace the batteries when the watch becomes slow or does not operate. It is not necessary to return your watch to EGC for battery replacement. However, it is recommended that you bring your watch to a local jeweler. Some important facts to remember when changing the battery are: (1) before removing the battery, be sure to denote polarity so that the new battery is installed in exactly the same way and (2) replace with same or equivalent.

  • Page 19: Year Limited Warranty

    1 YEAR LIMITED WARRANTY: EGC warranties that it will repair or replace any failure due to defects in materials and/or workmanship free of charge. This warranty is provided by EGC, not by the dealer from whom it was purchased. This limited warranty does not apply to normal wear and tear, misuse or abuse and excludes the battery, case, strap, crystal or bracelet.
  • Page 20 FROM OUTSIDE OF THE UNITED STATES: Clarity Ltd. Flat A - B, 12/F, Sing Mei Industrial Building 29 - 37 Kwai Wing Road, Kwai Chung, N.T. Hong Kong tel: 852.2424.2211 fax: 852.2424.2077 email: service@egc-clarity.com...
