- Page 1 Freightliner / Daimler Corporation Western Star Mirror Systems Manual...
-
Page 2: Table Of Contents
(G.5) General Maintenance and Cleaning Tips ........................9 (T.1) Adjusting Folding Bracket ............................... 9 (T.2) Mirror Movement Analysis Flowchart – Western Star ....................10 (T.3) Removing, Attaching, or Adjusting the Mirror Head (From the Bracket) ..............11 (W.1) Warranty Coverage ..............................12 Figure 1: Lower Bracket Holder .............................. -
Page 3: (G.1) Removal Of Entire Bracket And Mirror
These products may be the subject of Tel: 1-888-MEKRA-4U / Fax: (803) 337-5265 pending U.S. patent applications or may Email: quality@lang-mekra.com be covered by one or more U.S patents. www.lang-mekra.com (G.1) Removal of Entire Bracket and Mirror 1. Remove the antenna from the top of the mirror. 2. -
Page 4: (G.2) Changing The Upper Fastener Kit
These products may be the subject of Tel: 1-888-MEKRA-4U / Fax: (803) 337-5265 pending U.S. patent applications or may Email: quality@lang-mekra.com be covered by one or more U.S patents. www.lang-mekra.com (G.2) Changing the Upper Fastener Kit Ensure that the mirror and bracket system is firmly secured throughout the process in order to prevent injury or damage. -
Page 5: (G.3) Removing & Installing Mirror Plates
These products may be the subject of Tel: 1-888-MEKRA-4U / Fax: (803) 337-5265 pending U.S. patent applications or may Email: quality@lang-mekra.com be covered by one or more U.S patents. www.lang-mekra.com (G.3) Removing & Installing Mirror Plates Your Mekra-Lang mirror system is equipped with a durable mirror plate assembly reinforced with shatter-resistant adhesive to minimize splintering in the event of breakage. -
Page 6: (G.4) Removing & Installing The Back Cover
These products may be the subject of Tel: 1-888-MEKRA-4U / Fax: (803) 337-5265 pending U.S. patent applications or may Email: quality@lang-mekra.com be covered by one or more U.S patents. www.lang-mekra.com Actuate mirror down Slide mirror plate up Pull mirror plate out Figure 6: Main Glass Plate Removal (G.4) Removing &... - Page 7 These products may be the subject of Tel: 1-888-MEKRA-4U / Fax: (803) 337-5265 pending U.S. patent applications or may Email: quality@lang-mekra.com be covered by one or more U.S patents. www.lang-mekra.com Figure 8: Left Hand Hole Template Figure 9: Left Hand Mirror System Measurements...
- Page 8 These products may be the subject of Tel: 1-888-MEKRA-4U / Fax: (803) 337-5265 pending U.S. patent applications or may Email: quality@lang-mekra.com be covered by one or more U.S patents. www.lang-mekra.com Figure 10: Right Hand Hole Template Figure 11: Right Hand Mirror System Measurements...
-
Page 9: (G.5) General Maintenance And Cleaning Tips
These products may be the subject of Tel: 1-888-MEKRA-4U / Fax: (803) 337-5265 pending U.S. patent applications or may Email: quality@lang-mekra.com be covered by one or more U.S patents. www.lang-mekra.com (G.5) General Maintenance and Cleaning Tips surface glass has an exposed reflective surface and is not subject to corrosion. When cleaning 1 surface mirror glass, abrasive cleaners or brushes should be avoided. -
Page 10: (T.2) Mirror Movement Analysis Flowchart - Western Star
U.S patents. www.lang-mekra.com (T.2) Mirror Movement Analysis Flowchart – Western Star 1. Follow the flowchart above in order to promptly diagnose mirror movement problems. 2. Make sure all cables and connections are tight. -
Page 11: (T.3) Removing, Attaching, Or Adjusting The Mirror Head (From The Bracket)
These products may be the subject of Tel: 1-888-MEKRA-4U / Fax: (803) 337-5265 pending U.S. patent applications or may Email: quality@lang-mekra.com be covered by one or more U.S patents. www.lang-mekra.com (T.3) Removing, Attaching, or Adjusting the Mirror Head (From the Bracket) ... -
Page 12: (W.1) Warranty Coverage
(W.1) Warranty Coverage Lang-Mekra provides a warranty for production parts covering materials and workmanship. The time period of the warranty coverage, as well as terms of reimbursement, are determined by Western Star. The warranty will cover: • Functional Quality of Components •...
