Summary of Contents for Motorline MPXRQ1MWS

  • Page 1 MPXRQ1MWS MPXRQ1MWS USER’S AND INSTALLER’S MANUAL V1.0 REV. 02/2021...
  • Page 2: Table Of Contents

    00. CONTENT 01. SAFETY INSTRUCTIONS INDEX ATTENTION: 01. SAFETY INSTRUCTIONS This product is certified in accordance with European 02. PRODUCT Community (EC) safety standards. PRODUCT DESCRIPTION TECHNICAL CHARACTERISTICS This product complies with Directive 2011/65/EU of the BASIC CONTENT European Parliament and of the Council, of 8 June 2011, on OPERATING SHCEME the restriction of the use of certain hazardous substances in DIMENSIONS AND PRODUCT DIAGRAM...
  • Page 3: Safety Instructions

    01. SAFETY INSTRUCTIONS GENERAL WARNINGS the motorized door or gate from being triggered involuntarily. • This manual contains very important safety and usage information. WARNINGS FOR TECHNICIANS very important. Read all instructions carefully before beginning the installation/usage procedures and keep this manual in a safe place •...
  • Page 4 01. SAFETY INSTRUCTIONS to the release mechanism. use or maintenance! • Disconnect means, such as a switch or circuit breaker on the electrical • Safety norms are not followed in the installation, use and panel, must be provided on the product’s fixed power supply leads in maintenance of the product.
  • Page 5: Product

    (CONTROL BOARD) BASIC CONTENT SUCCESSFULLY VERIFICATION 01 • 01 MPXRQ1MWS FAILED VERIFIED 02 • 01 Embedding MPXRQ1MWS Please try again! Thank you 03 • 02 Screw for fixing to the wall 04 • 01 Cable ACCESS CODE VERIFICATION CLOSE DOOR...
  • Page 6: Dimensions And Product Diagram

    02. PRODUCT DIMENSIONS AND PRODUCT DIAGRAM SIDE FRONT BACK 38mm Indicator ID Setting QR Code Area 14 Pin MIFARE Card Conectors: Area • RS485 • Power Supply Input 86mm 14mm 24mm...
  • Page 7: Installation

    This ID is crucial to identify the task that each device performs and which port/access is installed. The definition is made through the existing dip switch frame on the back of each reader, according to the following table: Mount the MPXRQ1MWS terminal on the back. Dip switch Door...
  • Page 8: Connection Scheme

    05. CONNECTION SCHEME 05. CONNECTION SCHEME EXTERNAL POWER CONNECTION CONNECTION TO MRAC CONTROL BOARD Nº PIN DESCRIPTION WIRE +12Vdc GND (Black) Black 12Vdc (Red) 12Vdc (Red) MRAC GND (Black) RS485 RXD (Blue) RS485 TXD (Yellow) MRAC CONTROL BOARD Recommended power supply: •...
  • Page 9: Components Test

    06. COMPONENT TEST 07. TROUBLESHOOTING DEVICE TEST INSTRUCTIONS FOR FINAL CONSUMERS / SPECIALIZED INSTALLERS To avoid self-sensing interference from the touch sensor, please do not touch the sensor when turning PROBLEM SOLUTION on the device power. Please contact technical support 1 •...
