- Page 1 AIR MAGNA 100 GREEN ENERGY SYSTEMS AIR TO WATER HEAT PUMP DC INVERTER INSTALLATION AND MAINTENANCE MANUAL The piping connection should be installed according to the local legal laws and regulations as well as the profession standard.
-
Page 2: Table Of Contents
AIR MAGNA 100 GREEN ENERGY SYSTEMS CONTENT 1. Safe precautions 2. Structure 3. Installation 4. User instruction 5. Trial operation 6. Unit operation and performance 7. Maintenance and trouble shooting 8.Wiring diagram 9. WIFI function... - Page 3 AIR MAGNA 100 GREEN ENERGY SYSTEMS W a r n i n g T h e s a f e t y o f y o u a n d y o u r f a m i l i e s i s t h e m o s t i m p o r t a n t ! This machine belongs to class I equipment.
-
Page 4: Safe Precautions
AIR MAGNA 100 GREEN ENERGY SYSTEMS I. Safety Precautions Warning Requirements for the installation environment The installation location must be ventilated, waterproof, sun-proof, and requires a convenient powersupply, water supply and drainage channels. Customer‘s electrical environment must be in accordance with local electrical safety regulations. -
Page 5: Structure
AIR MAGNA 100 GREEN ENERGY SYSTEMS 2.Structure 2-1 Outer Structure 12kW 16kW 21kW 1030 1030 1030 1110 1335 1250 1-Wind net 2-Wiring cover 3-Maintenance panel 4-Water outlet 5-Water inlet The photo in this manual is only for explanations purpose. If the appearance, function are not in accordance with the real one, please in kind prevail. -
Page 6: Installation
AIR MAGNA 100 GREEN ENERGY SYSTEMS 3.Installation Attention The following installation places may cause the malfunction of the machine The places where there is mineral oil; The place that contains salt in the air, such as the seaside; The place that contains corrosive gas, such as hot spring area;... - Page 7 AIR MAGNA 100 GREEN ENERGY SYSTEMS 3.Installation 3-2 Movement 1)Because the gravity center of the unit is not in the middle, when you move the machine, please beware of the drumping. 2) Please do not hold the air inlet, or it will be deformed.
- Page 8 AIR MAGNA 100 GREEN ENERGY SYSTEMS 3.Installation 3-4 The space of installation and maintenance...
- Page 9 AIR MAGNA 100 GREEN ENERGY SYSTEMS 3.Installation 3-5 Installation of the water pipes 1)To reduce the resistance of the water pipe as much as possible , reducing the elbow position and variable diameter can be adopted. 2) In the process of the piping connection, please make sure the whole system to be clean, no rust and no other dirt, in order to prevent the piping blockage.
- Page 10 AIR MAGNA 100 GREEN ENERGY SYSTEMS 3.Installation 3-7 Antifreezing measures 1) When the ambient is lower than minus 5°C , please make sure the unit is energized. 2)The unit is set with anti-freeze protection program, in the state of power on, when the...
- Page 11 AIR MAGNA 100 GREEN ENERGY SYSTEMS 3.Installation 3-8 Installation diagram a. Installation for only heating b. Installation for only hot water...
- Page 12 AIR MAGNA 100 GREEN ENERGY SYSTEMS 3.Installation 3-8 Installation diagram c. Installation for hot water & heating...
-
Page 13: User Instruction
AIR MAGNA 100 GREEN ENERGY SYSTEMS 4.User instruction The unit can be pre-programmed by the wire controller and will then be run automatically. 4-1 Controller description 4-2 Key function Remarks: The control panel will be locked automatically if there is no key operation within 60s and icon is displayed on the screen. - Page 14 AIR MAGNA 100 GREEN ENERGY SYSTEMS 4.User instruction 4-2-2 Function key On the main screen, press this key to switch modes: room heating, auto mode, heating + hot water, cooling +hot water, room cooling, the corresponding icon will be light.
- Page 15 AIR MAGNA 100 GREEN ENERGY SYSTEMS 4.User instruction...
- Page 16 AIR MAGNA 100 GREEN ENERGY SYSTEMS 4.User instruction...
- Page 17 AIR MAGNA 100 GREEN ENERGY SYSTEMS 4.User instruction...
- Page 18 AIR MAGNA 100 GREEN ENERGY SYSTEMS 4.User instruction 4-3-2 Run parameters query (table 4.2) In the main interface, long press the „-“ key for 3 seconds to enter to check the run parameters. As shown in the table below:...
- Page 19 AIR MAGNA 100 GREEN ENERGY SYSTEMS 4.User instruction 4-3-3 Current clock setting In the main interface, press the „timing“ key for 3 seconds to enter the current clock setting interface; In the current clock interface, press the „timing“ key once, and the digits of the hour part will...
- Page 20 AIR MAGNA 100 GREEN ENERGY SYSTEMS 4.User instruction After setting the hour part, press the “timing” key again, and the number of the minute part will flash. At this time, press the “+” key or “-” key to set the minutes of the current clock;...
- Page 21 AIR MAGNA 100 GREEN ENERGY SYSTEMS 4.User instruction When the timing is flashing, press the “timing” button to enter the hour part setting interface of the timing power-on time. The number of the hour portion of the timing power-on time flashes. At this time, press the “+” key or “-” key to start the timer hour;...
- Page 22 AIR MAGNA 100 GREEN ENERGY SYSTEMS 4.User instruction 4-3-5 Key lock and unlock When there is no operation for 60 seconds, the screen will be locked automatically and icon is displayed on the screen. In the key-locked state, press and hold the “switch” key for 3 seconds, and the key-lock will be released after the buzzer beeps once.
-
Page 23: Trial Operation
AIR MAGNA 100 GREEN ENERGY SYSTEMS 5.Trial operation 5-1 Inspection before the trial operation Please check if the following items before the trial operation. 1)If the unit is installed correctly; 2)If the piping and wiring are correct; 3)If the drainage is smooth;... -
Page 24: Unit Operation And Performance
AIR MAGNA 100 GREEN ENERGY SYSTEMS 6. Unit operation and performance 6-1 explanation for some phenomena during the unit operation 1) Start delay During the unit running, if the unit is turned off or stops automatically, if restart the unit, the unit has to wait for 3 minutes to start. - Page 25 AIR MAGNA 100 GREEN ENERGY SYSTEMS 6. Unit operation and performance 6-3 Performance parameter Heating capacity (A7/W35) 12,0 16,0 21,0 Heating power input (A7/W35) 1,38 2,07 2,69 3,66 4,59 COP (A7/W35) 4,42 4,40 4,42 4,43 4,40 Heating capacity (A2/W35) 5,30...
-
Page 26: Maintenance And Trouble Shooting
AIR MAGNA 100 GREEN ENERGY SYSTEMS 7.Maintenance and trouble shooting 7-1 Fault code table (table 8.1) The unit will stop automatically if any fault happens during the operation, meanwhile, the fault code will display on the controller screen. Please contact the serviceman to check by... - Page 27 AIR MAGNA 100 GREEN ENERGY SYSTEMS 7.Maintenance and trouble shooting 7-2 Malfunctions and treatment Warning If any fault occurs and the unit stops running, please contact your dealer or after-sales technician to solve the problem. Please do not dismantle the unit and do repair by your own in order to avoid any unnecessary injury.
-
Page 28: Wiring Diagram
AIR MAGNA 100 GREEN ENERGY SYSTEMS 8.Wiring diagram... -
Page 29: Wifi Function
AIR MAGNA 100 GREEN ENERGY SYSTEMS 9.WIFI function 9-1 Software download and installation: For IOS: Enter “Multi-Machine” in Google Play or App Store, search for multifunction machine APP, download and install. For Android: Enter the URL in the browser: http://d.3appstore.com/phx9, you will find “Multi-Machine”... - Page 30 AIR MAGNA 100 GREEN ENERGY SYSTEMS 9.WIFI function 9-3 WIFI Connection Long press the “timing” key and “-” key for 3 seconds, the wire controller will make a beep to enter the state of intelligent network distribution, and the “...
- Page 31 AIR MAGNA 100 GREEN ENERGY SYSTEMS 9.WIFI function 9-4 App user guide Open the app, click on the device name. Enter the app control interface, see the description for the name of each part of the interface.
- Page 32 AIR MAGNA 100 GREEN ENERGY SYSTEMS 9.WIFI function 9-4-2 Set water temperature Drag the big dot on the temperature circle with your finger to adjust the set water temperature. 9-4-3 Operation mode selection Press the “M” button, You can call out the operating mode menu, you can select the...
- Page 33 AIR MAGNA 100 GREEN ENERGY SYSTEMS Note...
- Page 34 ANTEK Green Energy Systems A DIVISION OF ANTEK INDUSTRIAL GROUP Büro und Lager: Am Wienerweg 8 A-2403 Scharndorf E-Mail: info@antek.at www.ANTEK-GreenEnergy.com www.ANTEK-IndustrialGroup.com www.ANTEK-BM.com...
