Summary of Contents for CytoLED Pentaplex
- Page 1 CytoLED Pentaplex Stand Assembly Manual Components & Assembly Instructions Generation 3 Manual - Version 1.0 SITE: SOCIAL: CONTACT : CytoLED.com IG: @cytoledmedia Email: info@cytoled.com FB: @cytoledmedia...
- Page 2 CytoLED Pentaplex Stand Assembly Manual INTRODUCTION Thanks for choosing CytoLED! We've created this digital manual as a companion to your stand to ensure you understand all that it can do and so that you can get it set up quickly and safely. We chose to...
- Page 3 CYTOLED PENTAPLEX STAND ASSEMBLY MANUAL Table of Contents ACCESSORIES LIST ........... 4 ASSEMBLY INSTRUCTIONS ........5-10...
-
Page 4: Accessories List
PAGE 4 CYTOLED PENTAPLEX STAND ASSEMBLY MANUAL Accessories List Description Pattern Quantity Screw M8*35 Lock Nut M8 Allen wrench Small wrench Screw M8*35 Fixed piece Screw M8*16 Holder Screw M8*45 Lock nut M8 Screw M8*12 Knob nut M8 Pull pin knob screw... - Page 5 PAGE 5 CYTOLED PENTAPLEX STAND ASSEMBLY MANUAL Assembly Instructions The f irst step is to assemble the stand's base in an upside-down position, and connect the brake wheels. A: Lock nut M8*4 A: M8*35mm*4 The f ront edge of the base with...
- Page 6 PAGE 6 CYTOLED PENTAPLEX STAND ASSEMBLY MANUAL Assembly Instructions Insert the lower column into the groove of the assembled base. Fix the tube to the base with screws and f ittings. Lower column Back C: Fixer*1 M8*16mm*2 The long legs face the f ront...
- Page 7 PAGE 7 CYTOLED PENTAPLEX STAND ASSEMBLY MANUAL Assembly Instructions Align the upper column with the lower column slot and insert and f ix it. Adjust the hole position F: Pull pin knob screw*1...
- Page 8 PAGE 8 CYTOLED PENTAPLEX STAND ASSEMBLY MANUAL Assembly Instructions Install the Pentaplex hanging plate. Hanging plate 7-shaped support f rame 4.1 D: M8*45mm*4 Lock nut M8*4...
- Page 9 PAGE 9 CYTOLED PENTAPLEX STAND ASSEMBLY MANUAL Assembly Instructions Connect the hook to the screwhole on the back of the Pentaplex. H: Fix the Pentaplex screw E: M8*12mm*2 M8*16mm*4 Knob nut*2 M8*16mm*4...
- Page 10 PAGE 10 CYTOLED PENTAPLEX STAND ASSEMBLY MANUAL Assembly Instructions Hang the Pentaplex with the hook connected with the hook connected to the hanging plate. Tighten the screws under the hook. Hanging plate G: M5*55mm*2...
- Page 11 The information in the CytoLED Pentaplex Stand Assembly Manual has not been evaluated by the FDA or any other medical body. For any medical issue, we recommend seeking out a qualif ied medical professional.
