Vents PA 01 E Operation Manual

Air supply unit
Hide thumbs Also See for PA 01 E:
Table of Contents

Advertisement

Quick Links

Download this manual
OPERATION MANUAL
PА 01 Е
PА 02 Е
PА 03 Е
Air Supply Unit

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PA 01 E and is the answer not in the manual?

Questions and answers

Related Manuals for Vents PA 01 E

Summary of Contents for Vents PA 01 E

  • Page 1 OPERATION MANUAL PА 01 Е PА 02 Е PА 03 Е Air Supply Unit...

  • Page 2: Table Of Contents

    PА Е CONTENTS Introduction Purpose Delivery Set Designation key Basic technical data Safety Requirements Design and Operating Principle Installation and Setup Power Mains Connection Technical Maintenance Troubleshooting Storage and Transportation Rules Manufacturer’s Warranty Acceptance Certificate Connection Certificate Warranty Card...

  • Page 3: Introduction

    INTRODUCTION The present Operation Manual consisting of technical details, operating instructions and technical specification for the installation of the PA E air supply unit of VENTS series (hereinafter Unit). PURPOSE The unit is designed to supply heated air in air supply systems of private residences, offices, hotels, cafes, conference halls and other accommodation and public spaces.

  • Page 4: Basic Technical Data

    PА Е BASIC TECHNICAL DATA The unit is designed for operation in an enclosed area at ambient temperatures from -25 ºC to + 55 ºC for PA 01 Е and from -25 ºC to + 45 ºC for PA 02 Е and PA 03 Е at relative humidity of up to 80%. Hazardous parts access and water ingress protection standard: unit motors - IP 44;...

  • Page 5: Safety Requirements

    Table. 2 . Unit Technical Parameters Model PА 01 Е PА 02 Е PА 03 Е Supply Voltage, V/50 Hz 3 ~ 400 Maximum Fan Power, W 1330 Fan Current, A 0,55 1,05 Electric Heater Power, kW 12,0 18,0 21,0 Electric Heater Current, A 17,4 26,0...

  • Page 6: Design And Operating Principle

    PА Е DESIGN AND OPERATING PRINCIPLE The unit is designed for supply of purified and heated intake air. The unit design is given on Fig. 2. The basic configuration includes: Electric motor with a fan (Item 1). Built-in electric heater (Item 2). Class G4 filter (Item 3).
  • Page 7 Example 1 Example 2 Spacer Spacer Rubber Vibration Damper Spacer Nut with Rubber Vibration Locknut Damper Fig. 3. Unit Installation For best performance provide a straight section of air duct at least 1 m long on each side while installing the unit. The unit must be equipped with a grill or other device (maximum mesh size - 12.5 mm) to prevent free access to the fans.

  • Page 8: Power Mains Connection

    PА Е POWER MAINS CONNECTION Disconnect the unit from the power mains prior to any electrical work. The power mains connection shall only be performed by professional electricians qualified for unassisted operations with electrical installations up to 1000 V after careful reading of the present operation manual.

  • Page 9: Technical Maintenance

    b) Electric Heater Power Wiring Diagram a) Unit Fan Electric Motor Wiring Diagram ~400 V ~400 V 50 Hz 50 Hz TS1/1 where QF is the automatic switch (not included in the delivery TS1/2 package); X1 - terminal block; TS2/1 TB1 and TB2 - thermal protection contacts of the motor.

  • Page 10: Troubleshooting

    PА Е TROUBLESHOOTING Possible faults and fault handling Trouble Possible reasons Fault handling Make sure the power supply line is The fan does not No power supply. connected correct, otherwise troubleshoot get started. the connection error. Cold supply air. Filter is clogged. Clean or replace the filter.

  • Page 11: Manufacturer's Warranty

    MANUFACTURER’S WARRANTY Manufacturer hereby guarantees normal performance of the unit during two years from the date of retail sale provided compliance with transport, storage, mounting and operation regulations. In case of no confirmation of the sales date the warranty period is calculated from the manufacturing date.

  • Page 12: Acceptance Certificate

    PА Е ACCEPTANCE CERTIFICATE The air handling unit with heat recovery PA E has been duly certified as serviceable. Acceptance Inspector’s Stamp Date of manufacture _____________________ Sold by Name of trade company _______________________________________________________________ ___________________________________________________________________________________ Date of sale _____________________________ ELECTRICAL CONNECTION CERTIFICATE This is to certify that the air handling unit PA E has been connected to power mains pursuant to the requirements stated in the present user’s manual by a qualified technician: Company:...

This manual is also suitable for:

Pa 02 ePa 03 e
