Unication Quick Start Guide
One-Way Signal Booster
1. BOOSTER OVERVIEW
•
Top View
A1
A2
A3
•
Front View
A: Interface
Input prior to the signal
A1
amplification
98mm
A2
Power Input
www.Unication.com
•
Bottom View
Weak Signal
Middle Signal
Strong Signal
•
Back View
Output after signal is
A3
amplified
B2
B: Gain Switching
B1
Gain switch
Advertisement
Summary of Contents for unication 20191112
- Page 1 Unication Quick Start Guide One-Way Signal Booster 1. BOOSTER OVERVIEW • • Top View Bottom View 98mm Weak Signal Middle Signal Strong Signal • • Front View Back View B: Gain Switching A: Interface Input prior to the signal Output after signal is...
- Page 2 To expand the indoor signal coverage area, position the switch to the High-Power gain setting. Important Note: If the receiving range decreases when Booster is set to High gain there is signal interference in the area. To correct, change setting to Low Gain. www.Unication.com...
- Page 3 4. ONE-WAY SIGNAL BOOSTER COMPONENTS INCLUDED COMPONENTS: ◊ Unication One-Way Signal Booster w/ mounting hardware ◊ Power Cable w/ AC Adapter ADDITIONAL COMPONENTS REQUIRED FOR OPERATION: ◊ External antenna (directional Yagi) ◊ Indoor antenna(s) (omnidirectional and/or directional) ◊ Coaxial interior/exterior cable (LMR400 50-ohm or comparable) OPTIONAL COMPONENTS: ◊...
