10/100/1000M
10/100/1000M 10/100/1000M Ethernet
I I I ntroduction ntroduction ntroduction: : :
Model3011, 10/100/1000Mbps adaptive Gigabit Ethernet fiber
converter uses the switching technology to conduct media
conversion, which meets the standards of IEEE802.3, IEEE802.3u,
IEEE802.3z and IEEE802.3ab. This kind of media converter
supports two types of media network connections: 10Base-
T/100Base-TX/1000Base-T and 1000Base-SX/LX.Model3011 can
conduct mutual conversion
TX/1000Base-T twisted pair electrical signals and 1000Base-
SX/LX optical signals. This media converter extends the
transmission distance of a network from 100m over copper wires to
120 Km. This media converter supports transmission in dual-fiber
multi-mode, dual-fiber single-mode, SFP style fiber-optic
connections.
Packing Packing L L L ist Packing ist ist: : :
Model3011 is shipped with following items.
1. Model3011×1
2. 5VDC power adapter ×1(Media converter/5VDC)
3. User manual ×1
F F F eatures: eatures:
eatures:
1. Accord to IEEE802.1 10Base-T, IEEE802.3u 100Base-TX, IEEE
802.3ab 1000Base-TX,IEEE802.3z 1000Base-SX/LX
2. MDI/MDI-X auto negotiation, 10M/100/1000M auto negotiation
3. Supports full /half duplex, Point-to-point transparent transfer
4. Power External input
5. Plug-and-play, easy to installation
6. Can insert to 2U 19", 14 slots Rack(power external)
Your Serial and Data Communications Expert
Model3011
Model3011 Model3011
Ethernet SFP Media
Ethernet SFP SFP Media Media Converter
(SM & & & MM) (SM MM)
(SM MM)
between 10Base-T/100Base-
Shenzhen 3onedata Technology Co.,Ltd
Converter
