Page 1: Table Of Contents
Owner’s Manual TA1501C Clark Synthesis Amplifier NOTE: READ THIS MANUAL BEFORE OPERATING THE AMPLIFIER. FAILURE TO FOLLOW THE INSTRUCTIONS IN THIS MANUAL MAY RESULT IN DAMAGE TO THE AMPLIFIER AND/OR THE SOUND EQUIPMENT BEING POWERED BY THE AMPLIFIER. PROFESSIONAL INSTALLERS:...
Page 2: Company Overview
For many years, Clark Synthesis has been providing Tactile Sound Transducers for use in home theaters, listening rooms, outdoor decks, military simulators, theme park attractions, game chairs, professional music, and swimming pools. With such a variety of products, it is likely that Clark Synthesis has the right type of transducer for your application.
Page 3: Warranty
United States Warranty and Return Policy TA1501C CLARK SYNTHESIS AMPLIFIER WARRANTY Clark Synthesis, Inc. warranties the TA1501C Amplifer to be free from defects and workmanship under normal use for a period of two (2) years from date of original purchase.
Page 4: Safety Instructions
THE LIGHTNING BOLT TRIANGLE IS INTENDED TO ALERT THE USER TO THE RISK OF ELECTRIC SHOCK. SPECIAL SAFTEY CONSIDERATION FOR THE AQUASONIC SWIMMING POOL SPEAKER: WHEN USING THE TA1501C AMPLIFIER WITH THE CLARK SYNTHESIS AQUASONIC SWIMMING POOL SPEAKER, WE RECOMMEND THE FOLLOWING: - The amplifier must be plugged into a GFI-protected outlet.
Page 5: Product Introduction
Clark Synthesis product(s). USING THIS AMPLIFIER WITH A CLARK SYNTHESIS TRANSDUCER The TA1501C amplifier works with all Clark Synthesis transducers. This manual outlines how to use this amplifier with our transducers. CAUTION: This amplifier is designed to provide power to one (1) transducer.
Page 6: Unpacking Your Amplifier
(1) Operating Manual CONTACT INFORMATION IF PARTS ARE MISSING If you are missing any items, please contact Clark Synthesis at 1-800-898-1945. We recommend that you save the original carton to use if you ever have to ship the amplifier. WARNING: Before you set up this amplifier, make sure you read and observe the Important Safety Instructions in this manual.
Page 7: Product Overview
PRODUCT OVERVIEW Front Panel Rear Panel Ventilation Threaded Foot Hole Threaded Foot Hole Vents www.clarksynthesis.com TA1501C Amplifier...
Page 8 PRODUCT OVERVIEW Front Panel Overview Gain (Volume) Control Crossover (X-Over) Control Auto/On Switch Low Pass/Bypass Switch Power Indicator Light www.clarksynthesis.com TA1501C Amplifier...
Page 9 GAIN (VOLUME) CONTROL The Gain (Volume) Control on the face of the TA1501C amplifier controls the degree to which the input signal is amplified. The gain level, combined with the level of the input signal, determines the actual volume output. CROSSOVER (X-OVER) CONTROL The Crossover Control on the face of the TA1501C amplifier controls the range of low-frequency (bass) sound sent to the output device, i.e.
Page 10 PRODUCT OVERVIEW Rear Panel Overview AC Power Switch High/Low Input Signal Switch Audio Input/Output Connectors AC Power Cord Connector Transducer (IEC-601) Connector www.clarksynthesis.com TA1501C Amplifier...
Page 11 PRODUCT OVERVIEW Rear Panel Overview AC POWER SWITCH The AC Power Switch controls the AC power to the amplifier. The round circle on the switch represents “OFF” and the line represents “ON.” This switch works independently from the Auto/ On Switch, which is discussed in the Front Panel Overview section. AUDIO INPUT/OUTPUT CONNECTORS The Audio Input/Output Connectors accept standard RCA plugs.
Page 12: Setting Up Your Amplifier
SETTING UP YOUR AMPLIFIER This page intentionally left blank www.clarksynthesis.com TA1501C Amplifier...
Page 13: Setting Up Your Amplifier
SETTING UP YOUR AMPLIFIER Quick Setup Instructions The following instructions are a quick overview of the steps necessary to install your new amplifier. For more detailed instructions, please refer to the sections in the manual that are referenced below. Remove the amplifier from its package (for package contents, see “Unpacking Your Amplifier”...
Page 14 SETTING UP YOUR AMPLIFIER Initial Settings Prior to Making Connections CAUTION: Before connecting any wires or input/output lines, insure all equipment is off and no signals are being sent from the input device. In order to reduce the chances of accidentally damaging the amplifier or transducer, please set the amplifier controls to the safety positions described and shown below: •...
Page 15 SETTING UP YOUR AMPLIFIER Mounting the Amplifier(s) on a Clamping Rackshelf Up to three (3) TA1501C Amplifiers may be installed in a 2U rack space using a Clamping Rackshelf. When mounting in a Clamping Rackshelf, DO NOT install the feet provided with the amplifier. The bottom of the amplifier MUST be in full contact with the metal rackshelf.
Page 16 SETTING UP YOUR AMPLIFIER Connecting the Audio Source HOME THEATER There are several different ways to hook up your system in terms of which source material (signal) is delivered to the amplifier(s) and transducer(s). Since our inception, we have discovered that approximately half of our customers prefer using the LFE/SUB signal with their transducers.
Page 17 SETTING UP YOUR AMPLIFIER Right Front (RF) and Left Front (LF) Hookup For this hookup, connect the RF and LF Pre-Amp Outputs to the TA1501C amplifier inputs. NOTE: Not all receivers have Pre-Amp outputs for the Right Front and Left Front outputs. If you have a question about your receiver’s outputs, please consult your owner’s manual or contact your receiver’s manufacturer.
Page 18 SETTING UP YOUR AMPLIFIER Connecting the Transducer to the Amplifier If you are able to locate the amplifier within 3 feet of the transducer (3 ft. is the approximate length of the speaker wire attached to the transducer), connect the transducer wires directly to the amplifier. This can be done by unscrewing the wire binding posts, inserting the wire through the hole in the post (see photo #1 on this page), and then retightening the binding posts (see photo #2).
Page 19 SETTING UP YOUR AMPLIFIER Using the Powered Loop-Through to Run Multiple Transducers The TA1501C has powered loop-through. This feature enables the user to take the signal from an audio source and pass it to a series of TA1501C amplifiers in order to drive multiple transducers. The drawing for this type of hookup is shown below.
Page 20: Operating Your Amplifier
OPERATING YOUR AMPLIFIER Balancing the Transducer with the Subwoofer Once you have properly set up your amplifier, it is important to take time to balance the transducer and subwoofer sound. The volume of the transducer is controlled by the receiver and will rise or fall in direct proportion to that of the primary speakers.
Page 21 OPERATING YOUR AMPLIFIER If you are using the LFE/SUB signal as your input for the transducer, insure the is set to “Low Pass” (see photo #4) and the Crossover Control on the TA1501C is set to 400 Hz (photo #5). If you are using the RF/LF signal, set the switch to “Bypass.”...
Page 22: Specifications
SPECIFICATIONS General • Power Supply...100 – 240 VAC, 50/60 Hz, Auto • Standby Current (110 VAC / 220 VAC)...0.12 A / 0.11 A • Max Current (110 VAC / 220 VAC)...2.4 A / 1.1 A • Total Amplifier Efficiency...70% • Dimensions, without Feet (W x H x D)...5.125 in x 2.75 in x 8.875 in (130.2 mm x 69.9 mm x 225.4 mm) •...
Page 23: Troubleshooting
Symptom No Power Is the power cord plugged into the wall? Is the power cord plugged into the back of the amplifier? Is the power switch on the back of the amplifier switched on? Is the fuse blown? No Sound Is the transducer connected? Is the input source connected to the amplifier input?
Page 24: Glossary Of Terms
GLOSSARY OF TERMS Term 2U Rack Space Audio Input/Output Connectors Auto/On Switch Automatic Balancing System Crossover (X-Over) Control Gain Control High/Low Input Signal Switch IEC-601 Connector TA1501C Amplifier Definition With U (Unit), being a standard unit of measurement for audio/video racking systems, a 2U rack is a standard rack that occupies 2 units within the rack system.
Page 25 Term LFE/SUB Signal Loop-through Low Pass/Bypass Switch Multiple Signal Hookup Pre-Amp Receiver RF/LF Signals Tactile Sound Transducer (Audio) X-Over Control Y Adapter www.clarksynthesis.com GLOSSARY OF TERMS Definition A low-frequency signal that is often associated with subwoofer (bass) sound. The ability to connect multiple amplifers to a single audio source. A switch on the TA1501C that enables and disables the Crossover function of the amplifier.
Page 26: Index
INDEX Symbols 5-Way binding post 5, 18 AC Power Cord Connector 5, 10, 11 AC Power Switch 10, 11, 13, 14, 20, 21, 23 Audio Input/Output Connectors 10, 11, 13, 16, 17, 19, 24 Auto/On Switch 5, 8, 9, 21, 23, 24 Balancing 13, 20 Contact Information 6 Crossover Frequency 5, 9, 21, 22, 23...
Page 27 Mixer 17 Mounting 14 Clamping Rackshelf 14, 15 Multiple Signal Hookup 17 Package Contents 6 Placing/Mounting 14 Power Indicator (LED) 8, 9 Power (Output) 22 Pre-Amp 17, 25 Quick Setup Instructions 13 Rear Panel 7, 10, 11, 14, 20 Return Policy 3 RF/LF Hookup 17 Right Front (RF) 25 Specifications 22...
Page 28 For additional questions/concerns/issues, contact Clark Synthesis or visit our web site. Clark Synthesis, Inc. 8020 Southpark Circle, Suite 600 Littleton, CO 80120 Phone: 1-800-898-1945 Fax: 303-797-7501 Web: www.clarksynthesis.com Email: info@clarksynthesis.com www.clarksynthesis.com www.clarksynthesis.com...
