Summary of Contents for infobit iControl J10
- Page 1 IP Control Joystick Model: iControl J10 www.infobitav.com info@infobitav.com...
-
Page 2: Product Description
1. Product Description Introduction The iControl J10 is a universal PTZ Controller with Joystick for easy pan, tilt and zoom control for any VISCA/PELCO protocol compatible cameras. If you're ready for a versatile, easy to use Joystick controller for your PTZ cameras look no further! This controller is the ideal solution for all INFOBIT cameras. - Page 3 5) The zoom control of the conference camera is carried out by a switch shaping like a ship. Operation is convenient and powerful. 6) Support full-key backlight effect, can be turned on / off independently. 7) Support IE browser to add configuration front-end device parameters. Connection Diagram The keyboard and the dome are connected in the same LAN, and the network segment where the IP address is located is consistent.
- Page 4 Control Keyboard Parameters Ethernet 1 Ethernet port Rocker Function Four-dimensional (control: up, down, left, right) rocker buttons and zoom function Interface Mode Lead mode Display Method Beep Button sound prompt on/off Working Power DC 12V 1A ± 10% inside and outside negative Power Consumption 0.6W max Operating Temperature...
- Page 5 2. Keyboard Function Description 2.1 Key Description Auto white balance button: Set the camera to auto white WB AUTO balance mode. This button will light when the camera is in manual white balance mode. Auto Focus button: Design the camera to be in auto focus FOCUS AUTO mode.
- Page 6 Keyboard local settings button: modify, view keyboard SETUP local settings Query key: query and added device INQUIRE Manually add network device keys; manually add network ADD DEVICE devices (only ONVIF, IP VISCA mode support) Manual adjustment of near focus NEAR Manual adjustment of far focus Turn on the backlight BACKLIGHT ON...
- Page 7 2.2 Rocker switch, knob Manually adjust the focus, NEAR (fixed focus) / FAR (far NEAR / FAR focus). Manually adjust the aperture, OPEN (aperture plus) / OPEN / CLOSE CLOSED (aperture reduction). R- / R+ Manually adjust the red gain B- / B+ Manually adjust the blue gain PTZ SPEED +...
- Page 8 2.3 Rocker Control (clockwise/counterclockwise rotation is only valid for 3D) 2.4 Control keyboard rear interface terminal description Back panel: There is a 5PIN crimp terminal interface, an RS232 interface, a DC-12V power plug, a USB interface, and a network port, as shown in the figure:...
- Page 9 2.5 Function number description Mark Physical interface Description Connect the RS422 bus of the camera; (TA) to the Control output (Ta, ① camera (RA), (TB) to the camera (RB), (RA) to the RS422 Ta, Ra, Rb) camera (TA), (RB) to the camera (TB). Control signal line ②...
