Summary of Contents for Schwamborn FBS P
- Page 1 -Translation of the original operating instructions- OPERATING INSTRUCTIONS Parquet Saw FBS P Order no. 619006 2021-07 Schwamborn Geratebau GmbH Robert-Bosch-Strasse 8 73117 Wangen/Göppingen Tel.: +49 (0) 7161 2005-0 info@schwamborn.com...
-
Page 3: Table Of Contents
Parquet saw FBS P # 619006 TABLE OF CONTENTS CHAP 1 Safety instructions CHAP 2 Product Information 2.1 Technical description 2.2 Technical data 2.3 Identification 2.3 Standard accessories 2.4 Accessories and tools CHAP 3 Operation 3.1 Operating elements 3.2 Startup 11/12 3.3 Working method... -
Page 4: Safety Instructions
Parquet saw FBS P # 619006 SAFETY INSTRUCTIONS DEVICE SAFETY Before using the electrical device, read and act upon the operating instructions and the safety instructions, commands and local accident prevention rules and regulations. Failure to comply with or disregard the symbols attached to the appliance or this manual may result in electric shock, fire and / or serious injury to the operator or bystanders. - Page 5 Parquet saw FBS P # 619006 SAFETY INSTRUCTIONS The insert tool must have at least as high a permissible speed as the maximum speed indicated on the electrical appliance. Failure to comply with the risk of breakage and flying around the tool.
- Page 6 Parquet saw FBS P # 619006 SAFETY INSTRUCTIONS MAINTENANCE / REPAIR When working on the electrical device always unplug the mains plug! Maintenance, replacement, or adjustment of the tool or engine components may result in personal injury to the operator and / or bystanders when the electrical appliance is plugged into the electrical outlet.
- Page 7 Parquet saw FBS P # 619006 SAFETY INSTRUCTIONS KICKBACK AND RELATED WARNINGS Kickback is a sudden reaction to a pinched or snagged rotating wheel, backing pad, brush or any other accessory. Pinching or snagging causes rapid stalling of the rotating accessory which in turn causes the uncontrolled power tool to be forced in the direction opposite of the accessory’s rotation at the...
-
Page 8: Product Information
Parquet saw FBS P # 619006 PRODUCT INFORMATION Technical description With our new parquet saw, its 2400 watt strong motor and the especially manufactured saw blades, continuous ergonomic work when cutting parquet flooring is guaranteed. Professional device for the renovation of cracks and joints up to 50 mm depth and for cutting parquet before removing. -
Page 9: Standard Accessories
Parquet saw FBS P # 619006 PRODUCT INFORMATION Standard accessories (A) Angle grinder with suction housing and guide rod (disassembled) 5 x Standard saw blade for wood 1 x already installed 4 x replacement part (C) Tool for saw blade change... -
Page 10: Operation
Parquet saw FBS P # 619006 OPERATION Operating elements Guide handle Height adjustable Depth adjustment sawblade Safety switch Drive motor Height adjustment Mobile suction housing with extraction nozzle Wheel guide OPERATING INSTRUCTIONS 2021-07... -
Page 11: Startup
Parquet saw FBS P # 619006 OPERATION Startup Assembly of the guide rod For easy transport, the device is delivered disassembled. Assembly according to the following steps: 1. Attach bracket: Place the guide rod on the machine recess with the bracket, screw and nut. - Page 12 Parquet saw FBS P # 619006 OPERATION Startup CONTROL Please check before every start whether all device parts are assembled safely and correctly. The electrical device is equipped with a switch-on / lock. This prevents unwanted start-up and locks the switch in continuous operation.
-
Page 13: Working Method
Parquet saw FBS P # 619006 OPERATION Working method SET CUTTING DEPTH The desired depth of cut can be infinitely adjusted with the adjusting lever (1) and the wing nut setting (2). maximum cutting depth Rest position - no cutting depth Before switching on, lift the appliance off the floor. -
Page 14: Maintenance
Parquet saw FBS P # 619006 MAINTENANCE Insert / replace tools Unplug the power cord! Remove saw blade guide. Set depth setting to rest position. Set saw blade depth to maximum. Put the device on its side. open damper To unscrew, press the spindle lock with... -
Page 15: Maintenance And Care
Parquet saw FBS P # 619006 MAINTENANCE Cleaning and care Before any maintenance / care or repair work unplug the power cord. CLEANING Wipe the electrical appliance regularly with a dry cloth. Check the ventilation slots on the engine block regularly and keep them clean. - Page 16 DECLARATION OF CONFORMITY Schwamborn Gerä t ebau GmbH Robert-Bosch-Strasse 8 73117 Wangen/Göppingen GERMANY declare under our responsibility that the product Parquet Saw FBS P Machine type Order-No. 619006 Serial-No. ______________________ Year of manufacture ______________________ comply with the EU-Directrives Machinery directive 2006/42/EC EMC directive 2004/108/EC...
- Page 17 2021-07 OPERATING INSTRUCTIONS...
- Page 18 OPERATING INSTRUCTIONS 2021-07...
- Page 19 OPERATING INSTRUCTIONS 2021-07...
- Page 20 Schwamborn Geratebau GmbH Robert-Bosch-Strasse 8 73117 Wangen/Göppingen Tel.: +49 (0) 7161 2005-0 info@schwamborn.com...
