Summary of Contents for Norstar DS30
- Page 1 • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • DS30/Station Port Adapter Installation Guide...
-
Page 2: Regulatory Approval
All manuals and user guides at all-guides.com DS30/STATION PORT ADAPTER REGULATORY APPROVAL Table 1. Regulatory Approvals TYPE COUNTRY SPECIFICATION PROCEDURE Radiated Canada ICES-003/CISPR22 Class B ANSI C63.4 Emissions US FCC Part 15/CISPR22 Class B ANSI C63.4 EN55022 ANSI C63.4 Conducted Canada ICES-003/CISPR22 Class B ANSI C63.4... -
Page 3: Product Description
RELIABILITY Mean time before failure (MTBF) target is greater than 20 years using Mil-Std-217F method TBD reliability calculations. FUNCTIONAL Multiplexes up to eight Nortel Norstar TCM Loops DESCRIPTION (up to 16 voice paths) into one DS-30 fiber optic line. Each TCM Loop may include up to two active voice/data paths as well as a control signaling path. -
Page 4: Installation
DS-30/Station Port Adapter Fiber Spool 1 4 7 2 5 8 FIBER DS - 30 KSU 1 - 4 KSU 5 - 8 LINE POWER FIBER OPTIC Norstar KSU Applications Module Figure 3. Installation Diagram DS30/Station Port Adapter Installation Guide... -
Page 5: Troubleshooting
NOTE: Timing master uses highest numbered TCM Loop connected port to synchronize DS-30 link. The DS30/Station Port Adapter is compatible with ACCESS 2.6 ver. 6.52 and higher within application products running on the NAM II platform. Systems with previous versions of ACCESS should obtain an appropriate upgrade. - Page 6 All manuals and user guides at all-guides.com Norstar is a trademark of Northern Telecom. P0878745 Issue 01 Printed in the United States • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •...
