Page 1 MANUAL ENGLISH PLB-2342FM Ordercode: 100263 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
Page 2: Table Of Contents
PLB-2342FM Table of contents Warning ....................................2 Tools required for installing the PLB-2342FM bracket ..................... 2 Safety Instructions ................................. 3 Operating Determinations ............................4 Return Procedure ................................4 Claims ....................................4 Description of the device ..............................5 Overview ..................................5 Installation ...................................
Page 3: Warning
 DMT PLB-2342FM bracket  User manual Tools required for installing the PLB-2342FM bracket  Phillips head screwdriver (200 mm length excluding the handle)  Power drill + 10 mm masonry (concrete) and 4,5 mm (wood) drill bits for wall installation ...
Page 4: Safety Instructions
PLB-2342FM Safety Instructions Every person involved with the installation, operation and maintenance of this device has to:  be qualified  follow the instructions of this manual Before your initial start-up, please make sure that there is no damage caused by transportation. Should there be any, consult your dealer and do not use the device.
Page 5: Operating Determinations
PLB-2342FM Operating Determinations  The relative humidity must not exceed 50% with an ambient temperature of 40°C.  If this product is operated in any other way, than the one described in this manual, the product may suffer damages and the warranty becomes void.
Page 6: Description Of The Device
Overview Fig. 01 Installation Remove all packing materials from the PLB-2342FM. Check that all foam and plastic padding is removed. Connect all cables. Do not supply power before the whole system is set up and connected properly. Always disconnect from electric mains power supply before cleaning or servicing.
Page 7 PLB-2342FM  The provided hardware is for mounting through or attachment to a standard thickness drywall or plaster into studs. Installers are responsible for providing the hardware for other types of mounting situations. Ordercode: 100263...
Page 8: Solid Brick And Concrete Block Mounting
PLB-2342FM Solid Brick and Concrete Block Mounting  Use a 10 mm drill bit (concrete) to drill the holes (hole size: 10 mm, hole depth: 60 mm).  When installing the wall mounts on a cinderblock, verify that you have a minimum of 1-3/8” of actual concrete thickness in the hole to be used for the concrete anchors.
Page 9: Installation
PLB-2342FM Installation 01) Select the desired height. Use the wall bracket as a template and mark the drilling locations (for wood studs, please detect the center with a stud finder). Make sure that the alignment is correct. 02) Drill pilot holes at marked locations.
Page 10 PLB-2342FM 03) Identify the VESA pattern on the back of your flat screen. 04) Align the screen bracket with the VESA hole pattern on the back of the flat screen. Insert the appropriate screws from the Monitor Kit (M-A or M-B).
Page 11 PLB-2342FM 06) When using the longer M-B screws,you can also use the additional plastic rings (M-C). 07) Screw 2 screws (W-A) into the wall, but do not tighten just yet and let the bracket slide into the holes. 08) After that, screw the 3 screw (W-A) into the hole.
Page 12 PLB-2342FM 09) Tighten all 3 screws with a Phillips screwdriver. 10) Attach the 2 plastic caps to protect the bracket and its screws. Ordercode: 100263...
Page 13 PLB-2342FM 11) Attach the cable management system. 12) Loosen the screw to set the inclination angle. 13) Tilt the Monitor / TV to the desired position and tighten the screw again. 14) Guide all cables through the cable management system.
Page 14: Maintenance
03) Mechanically moving parts like axles, eyes and others may not show any traces of wearing. 04) The electric power supply cables must not show any damages or material fatigue. Product Specifications Model: DMT PLB-2342FM Maximum Load: 20 kg Screen size: 23"...
Page 15 PLB-2342FM Ordercode: 100263...
