Summary of Contents for Venmar AVS CONSTRUCTO 1.5
- Page 1 UIDE VB0109 MODELS ONSTRUCTO ONSTRUCTO EAD AND SAVE THESE INSTRUCTIONS 08055 rev. A...
- Page 2 CONGRATULATIONS! You have made an excellent choice! We have prepared this User Guide especially for you. Please read it carefully to ensure you obtain full benefits from your Heat Recovery Ventilator unit. About this Guide This guide uses the following symbols to emphasize particular information: WARNING Identifies an instruction which, if not followed, might cause serious personal injuries including possibility of death.
- Page 3 1.0 U ESCRIPTION 1. Filters 2. Blowers 3. Condensation tray 4. Heat recovery core VB0097 1.1 S PECIFICATIONS ODEL ONSTRUCTO ONSTRUCTO 30 ¼’’ (768 30 ¼’’ (768 IDTH 16 ½’’ (419 16 ½’’ (419 EIGHT 17 ¼’’ (438 17 ¼’’ (438 EPTH .
- Page 4 3.0 C ONTROLS 3.1 I NTEGRATED ONTROL All units are equipped with an integrated control, located in front of the electrical compartment. Use the push button (1) to control the unit. The LED (2) will then shows on which mode the unit is in. VD0193 Refer to table below to see how to operate the unit using its integrated control.
- Page 5 3.0 C ’ ONTROLS CONT 3.2 O ’ PTIONAL ONTROLS CONT 3.2.2 C ONSTRUCTO Location: Located in the busiest area of the house. Purpose: To adjust air supply and select desired indoor humidity level. 5°C 41°F OFF MIN MAX Adjusting the AIR SUPPLY CONTROL: -5°C a) Select speed MIN.
- Page 6 3.0 C ’ ONTROLS CONT 3.3 O PTIONAL UXILIARY ONTROLS 3.3.1 Dehumidistat Location: Located in the bathroom or in other locations where there is temporary humidity excess. Purpose: To eliminate excess humidity produced by showers or other periodic activities producing humidity. In the fall, winter and spring: Adjust knob to the desired humidity level.
- Page 7 4.0 M AINTENANCE WARNING In order to prevent personal injury, turn off the unit and unplug it before performing maintenance. When cleaning the unit, it is recommended to wear safety glasses and gloves. 4.1 R EGULAR Air filters: The air filters are washable. Under normal conditions, we recommend to wash them every 3 months. •...
- Page 8 5.0 T ROUBLESHOOTING If you think your unit is malfunctioning, check some of the following: TYPE OF PROBLEM TRY THIS... Nothing works. • See if the unit is plugged in. • See if the breaker is receiving power from the house circuit breaker. Condensation on windows •...
