- Page 1 TRIWATT OD Footswitch Builder’s Guide For the sole personal use of Trinity Amps Customers. May 2020, Version 1.1 Parts © Trinity Amps 2005 - 2020 www.trinityamps.com...
- Page 2 Contents TRIWATT Overdrive Footswitch using Centre Tapped Heater Leads ........3...
- Page 3 TRIWATT Overdrive Footswitch using Centre Tapped Heater Leads TRIWATT FOOTSWITCH RELAY BOARD INSTALLATION LAYOUT...
- Page 4 TRIWATT FOOTSWITCH RELAY BOARD COMPONENT LOCATION Build the Relay PCB following the Footswitch Relay Board Component Location. Locate the: 1 - Relay PCB 1 - Linear Voltage Reg MCP1826S 3V 1A 2 - Al. El. Cap. - 3300uf 10V 1 - Multilayer Cer. Cap Leaded 0.1uf 1 –...
- Page 5 RELAY BOARD - BARE BUILD THE RELAY BOARD First install the 510R resistor. Next, install the IN4007 diode paying attention to the correct orientation of the marked end. Diode Orientation: Pay particular attention to the orientation of the diodes when they are installed.
- Page 6 4. Connect coaxial cable to the front panel; Connect coaxial cable to the front panel to V2 5. Connect wires to tubes socket (V2) footswitch jack and front panel switch, carefully following TRIWATT FOOTSWITCH RELAY BOARD INSTALLATION LAYOUT 6. Test the Relay operation.
- Page 7 Move 100K to relay board...
