CrossCore EZ-KIT Lite Quick Start Manual

Thank you for purchasing this EZ-KIT Lite
Lite, you must first perform the following procedure, which leads you through the software installation
and hardware setup.
For further information, please refer to the EZ-KIT Lite Evaluation System Manual on the CD-ROM.

Software Installation

1) Check the contents of your package and identify the following items:
•
Installation Quick Reference Card for VisualDSP++ Development Environment
• VisualDSP++  development environment CD-ROM (CD includes the EZ-KIT Lite evaluation
system software)
•
EZ-KIT Lite board
Power supply
•
- 9V DC for ADSP-2181
-
7.5V DC for ADSP-2189 and SHARC DSPs
•
RS-232 serial port 9-pin cable
•
Registration form (to be filled out and returned to Analog Devices)
2) Ensure that your PC meets the following minimal requirements along with the requirements stated
in the Installation Quick Reference Card for VisualDSP++:
Windows® 98, ME, 2000, XP, or Windows NT
An available RS-232 port
3) Ensure that the VisualDSP++ Development Environment is installed.
a. If the latest version of VisualDSP++ is installed, insert the VisualDSP++ CD into CD-
ROM drive. Click on Install VisualDSP++. Click on Install Tools. On this prompt screen,
select Modify to add the EZ-KIT Lite software. On the next Component prompt screen
make your EZ-KIT Lite selection and begin install.
b. If VisualDSP++ is not installed please refer to the Installation Quick Reference Card for
VisualDSP++ Development Environment for further instructions. Perform only tasks 1
and 2. Continue after you have completed the VisualDSP++ install.
Important:
Please note that installing the latest version of VisualDSP++ will completely replace
the older VisualDSP++
you need to use the older version you will need to uninstall this version and re-install the older
version.
Note: The VisualDSP++ serial number shipped with this EZ-KIT Lite evaluation system creates a
permanent license, but limits the software's capability. For detailed information on these limitations
refer to the EZ-KIT Lite Restrictions section in the EZ-KIT Lite Evaluation System Manual.
EZ-KIT Lite    Quick Start Guide
evaluation system. Before you begin to use your EZ-KIT

versions on your computer, making them inoperable. If for some reason,

www.BDTIC.com/ADI
84-001970-01 Rev. 3.2
