Summary of Contents for ETENON Fitness PC2032
- Page 1 OWNER S MANUAL ’ LAT PULLDOWN / LOW ROW CAUTION Please read all instructions in this manual before use the equipment and keep the manual well.
- Page 4 Equipment Schematic stand frame Door Frame High pull handle set Low pull handle set leg pad foot rack Seat pad set Main Frame...
-
Page 7: Assembly Step
Assembly step 1 Step Description Specifications Frame Socket Head Inner Hexagon Bolt M10*35 Spring Washer Flat washer Φ20*Φ10.5*2 ground frame cable 1 foot rack pulley set socket cap screw M10*25 socket cap screw M10*50 spring washer flat washer Φ20*Φ10.5*2... - Page 8 Assembly step 2 Step Description Specifications left connection frame right connection frame cable 1 stand frame socket cap screw M10*25 spring washer flat washer Φ20*Φ10.5*2...
- Page 9 Assembly step 3 Step Description Specifications adjustment frame aluminum cover stop screw High pull handle set Low pull handle set Semi-sliding sleeve group Countersunk head hexagon socket screw M8*25 socket cap screw M8*75 spring washer spring washer flat washer Φ16*Φ8.4*1.6 leg pad back pad...
- Page 10 Assembly step 4 Step Description Specifications Guide Rod Guide Rod Fixer Bumper Bumper Guide Rod end cap Pulley sets φ89*32 Selector pin Inner Hexagon Socket Head Bolt M8*20 Inner Hexagon Socket Head Bolt M10*55 Spring washer Flat washer Φ16*Φ8.4*1.6 Flat washer Φ20*Φ10.5*2 Nylon nut cable 1...
- Page 11 Assembly step 5 Step Description Specifications Upper shield Shield fixed plate Fixed bushing Front shield Back shield cross recessed countersunk head screw M5*10 Countersunk head hexagon socket screw M6*16 Inner Hexagon Socket Head Bolt M6*16 Spring washer Flat washer Φ12*Φ6.4*1.6...
-
Page 12: Cable Routing Diagram
CABLE ROUTING DIAGRAM Correct Wrong Cable Cable limiting post limiting post... -
Page 13: Exploded View
Exploded View... - Page 14 Exploded List Description Specifications Doorframe Upper shield Shield fixed plate Guide rod Guide rod fixed plate Fixed bushing Front shield Back shield Rubber bumper φ64*φ32*φ20*35 Rubber bumper φ38*φ21*10 Floor cushion Rod end cover Pulley sets φ89*32 Selector pin cross recessed countersunk head screw M5*10 Countersunk head hexagon socket screw M6*16...
- Page 15 Exploded View...
- Page 16 Exploded List Description Specifications ground frame adjustment frame left connection frame right connection frame pulley frame cable 1 cable 2 foot rack stand frame aluminum cover adjustment plunger chain stop screw sping M20 Nut cable end assembly Hoist hook High pull handle set Low pull handle set 10lb weight stack assembly 10lb top weight assembly...
- Page 17 Exploded List Description Specifications flat washer Φ20*Φ10.5*2 Rivet nut with small countersunk head M8*18 leg pad back pad...
- Page 19 Weight stack label instructions 1 Wipe front surface of weight stack 2 Peel off back sheet adhesive side from label and make sure that the label remains attached to the application tape 3 Aline the center hole of label with the weight stack center hole 4 Line up the first label to hole on top plate 5 Make sure label is straight and slowly press into place...
