SECTIONAL AND TILTING DOOR OPENER
INSTALLATION INSTRUCTIONS AND USER GUIDE
600N
1000N
1000N Speed
1200N
Please read the manual carefully before installation and use.
The installation of your new door opener must be carried out by a technically quali ed or licensed person.
Attempting to install or repair the door opener without suitable technical quali cation may result in severe
personal injury, death and / or property damage.
S/N
WARNING
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Force+ 600N and is the answer not in the manual?

Questions and answers

Michael Olesen Rosfeldt
May 6, 2025

hej med jer, jeg har en force600n garageport åbner hvor fjernbetjeningen er blevet væk, kan man ikke købe en ny og hvad koster så 1 eller 2 ? Vh Michael

0

Summary of Contents for Move Force+ 600N

  • Page 1 SECTIONAL AND TILTING DOOR OPENER INSTALLATION INSTRUCTIONS AND USER GUIDE 600N 1000N 1000N Speed 1200N WARNING Please read the manual carefully before installation and use. The installation of your new door opener must be carried out by a technically quali ed or licensed person. Attempting to install or repair the door opener without suitable technical quali cation may result in severe personal injury, death and / or property damage.

  • Page 2: Table Of Contents

    CONTENTS Important Safety Recommendations Product Description & Features 2-3D Pre-Installation Recommendations Installation Instructions Installation (Wall Bracket & Door Bracket) Installation (Steel Track) Installation (Sectional Steel Track Assembly) Battery Backup Assembly (optional) Display Menu Instructions (Plus II) Display Menu Instructions 9-19D Terminal Introduction and Application 21-22D Manual Disengagement...

  • Page 3: Important Safety Recommendations

    IMPORTANT SAFETY RECOMMENDATIONS FAILURE TO COMPLY WITH THE FOLLOWING SAFETY RECOMMENDATIONS MAY RESULT IN SERIOUS PERSONAL INJURY, DEATH AND / OR PROPERTY DAMAGE. 1. PLEASE READ CAREFULLY AND ADHERE TO ALL SAFETY AND INSTALLATION RECOMMENDATIONS. 2. The opener is designed and manufactured to meet local regulations. The installer must be familiar with local regulations required in respect of the installation of the opener.

  • Page 4: Product Description & Features

    PRODUCT DESCRIPTION & FEATURES 1. Obstruction force adjustment The minimum force display “1” and it can be adjusted upward. Display “5” means the maximum force. 2. Travel speed adjustment “8” appears on the display means the 80% of the travel speed. Display “A” means the full speed 160mm/s or 200mm/s.
  • Page 5 13. Available terminal for Photo beams & Extra receivers & Wire or wireless wall switch & Caution light & Pass door protection device. 14. Energy saving - L.E.D courtesy light 3 minutes L.E.D light delay, switching on with each cycle to illuminate your darkened garage. 15.

  • Page 6: Pre-Installation Recommendations

    PRE-INSTALLATION RECOMMENDATIONS 1. Garage door must be able to be lifted and closed easily by hand and without much e ort. A well balanced & sprung door is critical for proper installation. 2. The garage door opener can’t compensate for a badly installed garage door and should not be used as a solution for a “hard to open”...

  • Page 7: Installation (Steel Track)

    Installation (Steel Track) Figure 3 STEP 1 (Fig.3) Attach the opener head to the steel track. Assembly the 2 “U” Hanging brackets with 6mm nuts supplied. STEP 2 (Fig.3) Place the steel track and opener head assembly centrally on the garage oor, with the open head furthest away from the door.
  • Page 8 Sectional Steel Track Assembly 2 Parts Steel Track B:1500 mm A:1500 mm Sleeve Figure 6 E:1000 mm D:1000 mm C:1000 mm Sleeve Sleeve Figure 7 1. 2-Parts Track: As Fig.6, slide the A rail into the sleeve, slide the B rail into the sleeve. 3-Parts Track: As Fig.7, slide the C rail into the sleeve, slide the D rail into the sleeve;...

  • Page 9: Battery Backup Assembly (Optional)

    Battery backup Assembly (optional) Option 1 - Top Fixed STEP 1 (Fig.11) Assemble the battery & battery bracket like the photo, x by screws supplied. STEP 2 (Fig.12) Join the battery to opener, nd the Fig.12. Figure 11 Figure 12 Option 2 - Side Fixed STEP 1 (Fig.13) Assemble the battery &...

  • Page 10: Display Menu Instructions

    DISPLAY MENU INSTRUCTIONS FEATURES SETTINGS: a) Press and hold SET button until “1” appears on the display then release the button. b) Press UP / DOWN button, then it displays the number “1-E”. c) Press SET button to con rm the feature you need to set, then it enters to the interface for detail setting of the appointed feature.
  • Page 11 PROGRAMMING INSTRUCTIONS Pre- Instruction for programme buttons 1.Short click SET button : When it standby, it will clear the error, alarm display, and return to normal display. 2.Short click CODE button : . ( In the Setting Status) Exit the current operation and return to the standby interface. .
  • Page 12 PROGRAMMING INSTRUCTIONS 1. PROGRAMMING OPEN & CLOSE LIMITS a) Press and hold SET button to enter this function setting until “ ” appears on the display then release the button. b) Press the SET button again. The door opener is now in Programming Mode.
  • Page 13 2. OBSTRUCTION FORCE ADJUSTMENT CAUTION: The obstruction force adjustment is set automatically during programming. Normally adjustment is necessary. a) Press and hold SET Button until “ ”appears on the display, next press the UP Button until “ ” appears on the display to enter this function setting then release the button.
  • Page 14 4. AUTOMATIC CLOSING & TIME SETTING NOTE: We recommend that Safety Photo Beams be used in any installation where the Auto Close function is enabled. a) Press and hold SET Button until“ ”appears on the display, next press the UP button until “ ”...
  • Page 15 5. 5. AUTOMATIC CLOSING CONDITION SETTING a) Press and hold SET Button until “ ” appears on the display, next press the UP button until “ ” appears on the display to enter this function setting then release the button. b) Press the SET button again.
  • Page 16 7. REVERSAL HEIGHT SETTING a) Press and hold SET Button until “ ” appears on the display, next press the UP button until “ ” appears on the display to enter this function setting then release the button. b) Press the SET button again. The unit is now in reversal height adjustment mode.
  • Page 17 8. PARTIAL OPEN/HEIGHT SETTING a) Press and hold SET Button until “ ” appears on the display, next press the UP button until “ ” appears on the display to enter this function setting then release the button. b) Press the SET button again. The unit is now in partial-open/height adjustment mode.
  • Page 18 9. TRANSMITTER BUTTONS RECOGNITION FUNCTION SETTING a) Press and hold SET button to enter this function setting until “9” appears on the display then release the button. b) Press the SET button again. The unit is now in buttons recognition function adjustment mode. And then you will see a gure “...
  • Page 19 B.REVERSAL HEIGHT IGNORANCE SETTING a) Press and hold SET Button until “ ” appears on the display, next press the UP button until “b” appears on the display to enter this function setting then release the button. b) Press the SET button again. The unit is now in reversal height ignorance adjustment mode.
  • Page 20 D. PHOTO CELL ON/OFF SETTING NOTE: Make sure the photo cell has been correctly installed and used Normally Closed contacts to the accessory terminals of the opener. Also note that the photo beam function must be disabled if NO photo beams are tted, otherwise the door cannot be closed, and the LED display will show the letter“...
  • Page 21 E. MAINTENANCE ALARM - OPERATION CYCLES COUNT SETTING a) Press and hold SET Button until “ ” appears on the display, next press the UP button until “ ” appears on the display to enter this function setting then release the button. b) Press the SET button again.
  • Page 22 F. PROGRAMMING COMMUNITY FUNCTION a) Press and hold SET Button until “ ”appears on the display, next short press the UP/Down Button until “ ” appears on the display to enter this function setting then release the button. b) Press the SET Button it will display the status that you choose.

  • Page 23: Terminal Introduction And Application

    TERMINAL INTRODUCTION AND APPLICATION PHOTO BEAM CONNECTION (OPTIONAL) – Fig.15,Fig.16 SWITCH CONTROL CONNECTION (OPTIONAL) – Fig.15 Remark: 1.Flash (Caution Light) Should be less than 25W. 2.PB (External Push Button) Should be “ NO”. GARAGE DOOR OPENER +24V Figure 15 O/S/C PHOTOBEAM FOR PULSE +24V PE...
  • Page 24 Flash Transforming Device A C 2 2 0 V Flash Light ( AC220V) Figure 17 GARAGE DOOR OPENER Flash Light Flash +24V O/S/C Figure 18 Flash Photo beam Pass-door for pulse safety device ASS. Terminal connection -22D-...

  • Page 25: Manual Disengagement

    MANUAL DISENGAGEMENT The opener is equipped with a manual release cord to disengage shuttle and move door by hand while holding the handle down (Fig 19). Pull on the handle to disengage the shuttle. To re-engage the door simply run opener in automatic mode or move door by hand until the trolley engages in the chain shuttle.

  • Page 26: Technical Speci Cations

    TECHNICAL SPECIFICATIONS 600 N 1000 N 1200 N 1000Speed Input voltage 220 - 240V / 110 - 127V, 50–60 Hz Max. pull force 600 N 1000 N 1200 N Max. door area 10.0 m2 15.0 m2 18.0 m2 Max. door weight (balanced) 80 kg 100 kg 130 kg...

  • Page 27: Parts Listing

    PARTS LISTING Item Description Item Description Item Description Top Cover Self-tapping Screw 3*16 Door bracket L.E.D. Cover Fuse holder Mounting bracket L.E.D. Light Power cord sleeve Click bracket Silicone rubber button Power cord M6 bolt 6*14 PCB-1 U hanging bracket M6 nut Main cover M6 nut...

  • Page 28: Common Fault & Solutions

    COMMON FAULT & SOLUTIONS Fault Appearance Fault Cause Solutions No any working for openers 1. Power supply 1. Check whether the motor socket is energized LCD Screen is not bright 2. Plug wire is loosing 2. Check whether Fuse tube is broken 3.
  • Page 29 Fault Appearance Fault Cause Solutions Door is up moving only. Photo cell function has been e ective 1. Turn o the photo cell function if there is no any photo cell device Do not work in down moving but without connecting any photo cell connected.

  • Page 30: Warranty Certi Cate

    WARRANTY CERTIFICATE NAME ADRESS COUNTRY PHONE INSTALLER SIGNATURE AND STAMP DATE WARRANTY AND LIABILITY Correct use and maintenance of automation is essential to ensure that the warranty is valid. The warranty has a period of two (2) years for residential users and one (1) year for industrial uses. WARRANTY DOES NOT COVER: Repairs performed by persons who are not properly trained and quali ed.
  • Page 32 Parque Empresarial de Padreiro, Lote 13 +351 258 931 334 / 5 www.portasarcuense.com 4970-500 Arcos de Valdevez, Portugal portasarcuense@mail.telepac.pt...

This manual is also suitable for:

Force+ 1000nForce+ 1000n speedForce+ 1200n
