TPS SAS908X-7-DF Manual

SAS908X-7-DF(DC) Waterline Master Control Controller
SAS908X-7-DF(DC) waterline master controller can cooperate with SAS2010DE control center,used as on
off the thermo actuator for adjust the room temperature application.
Power source ....................................2 AA size 1.5V alkaline battery，DC power transformer plug
enter 12 V.
Wireless frequency band........................868MHZ（FSK）
Wireless transmitte range.......................100m in the open air
Room temperature setting range .............5℃~40℃ or 41℉~104℉
Accuracy.............................................0.5℃ or 1℉
Ambient temperature-operation...............0℃~+50℃（32℉~122℉）
Ambient temperature-transport................-10℃~+60℃（14℉~140℉）
Dimensions.........................................135×113×32mm
Button and Functional description:
① Power on/ anti-freezing /off button；
② Time setting button；At starting shortly press
key, adjust the minute， press
date，press add and subtract key, adjust the week，press
③ Program Setting button；at starting up and program running state(programming mode) shortly press
③
button enter the program and set the date
③
enter programming temperature
than 3 seconds enter keeping running mode forever；at shutdown state long press button
seconds enter implied parameters setting the first item，then press button
setting the next item.
④ Confirm/Exit button；At setting state shortly press button
keeping mode, or at temporarily keeping mode shortly press button
SPECIFICATION
KEYBOARD, DISPLAY AND SWITCH DESCRIOPTION
④
button to confirm and exit
；at starting up and program running state long press button
②
button enter setting the
； then shortly press
④
button to conf
， then press button ③
enter programming time
④
is all setting confirmation and exit forever
1
minute, press add and subtract
②
button enter setting the
irm and exit.
， press button
③
more than 3
③
enter implied parameters
④
to exit and return to program
③
more
