AVICHE AH-C10 User Manual

Medical compressor nebulizer

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

Medical Compressor Nebulizer

Model: AH-C10

User Manual

Version 1.0

Thank you for choosing AVICHE Medical Compressor Nebulizer. Please read this User

Manual carefully before use and maintenance and keep it properly for future reference.

Table of Contents

Need help?

Do you have a question about the AH-C10 and is the answer not in the manual?

Questions and answers

Summary of Contents for AVICHE AH-C10

Page 1 Medical Compressor Nebulizer Model: AH-C10 User Manual Version 1.0 Thank you for choosing AVICHE Medical Compressor Nebulizer. Please read this User Manual carefully before use and maintenance and keep it properly for future reference.
Page 3: Table Of Contents
Table of Contents Before Using the Device ………………………………… Introduction ………………………………………………… Intended Use ……………………………………………… Safety Information ……………………………………… Know Your Unit …………………………………………… Operating Instructions …………………………………… Preparing the Nebulizer for Use …………………… Attaching the Air Tube ………………………………… Using the Device ………………………………………… Care and Maintenance ……………………………………...
Page 4: Before Using The Device
CONSULT YOUR DOCTOR. SAVE THESE INSTRUCTIONS Intended Use The AH-C10 Medical Compressor Nebulizer is intended to provide air to the pneumatic nebulizer in order to aerosolize medications for inhalation by the patient for respiratory disorders. The system is designed for use with pediatric (defined by the prescribed medication) and adult patients in the home, hospital, and sub-acute settings.
Page 5: Safety Information
Safety Information To ensure the correct use of the product, basic safety measures should always be followed including the warnings and cautions listed in this user manual. SAFETY SYMBOLS USED IN THIS USER MANUAL Indicates a potentially hazardous situation which, if not WARNING avoided, could result in death or serious injury.
Page 6 Pentamidine is not an approved medication for use with this device. Always dispose of any remaining medication in the medication cup after each use. Use fresh medication each time you use the device. Do not leave the device or its parts where it will be exposed to extreme temperatures or changes in humidity, such as leaving the device in a vehicle during warm or hot months, or where it will be exposed to direct sunlight.
Page 7 Make sure the air filter is clean. If the air filter has changed color or has been used on average for more than 60 days, replace it with a new one. Make sure the nebulizer kit is correctly assembled, the air filter is properly installed, and the air tube is correctly connected to the compressor and the nebulizer kit.
Page 8 Changes or modification not approved by AVICHE will void the user warranty. To avoid injury to the nose mucosa, do not squeeze the optional nosepiece into the back of the nose.
Page 9 Do not immerse the compressor (main unit) in water or other liquid. Do not spill water or other liquids on the compressor and power cord. These parts are not waterproof. If liquid spills on these parts, immediately unplug the power cord and wipe off the liquid with gauze or other soft absorbent material.
Page 10: Know Your Unit
Inspection Date: Quality Inspector: Version 1.0 Thank you for choosing AVICHE Medical Compressor Nebulizer. Please read this User Manual carefully before use and maintenance and keep it properly for future reference. User Manual (including Warranty Card) × 1 Product Inspection Certificate × 1...
Page 11 Main Unit Air Tube Connector Air Filter Cover Nebulizer Kit (*Air Filter Inside) Holder Power Switch Ventilation Slots Nebulizer Kit Inhalation Cap Knob Inhalation Cap Inhalation Top Baffle Mask Medication Cup Nozzle Air Tube Connector...
Page 12: Operating Instructions Preparing The Nebulizer For Use
Operating Instructions Preparing the Nebulizer for Use WARNING ·Clean and disinfect the nebulizer kit, and optional masks before using them for the first time after purchase. ·If the device has not been used for a long period of time, or if more than one person uses the same device, clean and disinfect the nebulizer kit, and optional masks before using them.
Page 13 3 Add the correct amount of prescribed medication to the medication cup. WARNING ·For type, dose, and regime of medication follow the instructions of your physician or licensed healthcare practitioner. ·Do not spill water or other liquids on the compressor and power cord.
Page 14: Attaching The Air Tube
5 Attach the desired inhalation accessory. USING ADULT MASK or CHILD MASK Turn the inhalation cap knob to cover the inhalation air inlet(A). Attach the mask(B) NOTE: 1. Amount of aerosol can be adjusted by turning the inhalation cap knob. 2.
Page 15: Using The Device
3 Use the nebulizer kit holder as a temporary holder for the nebulizer kit. NOTE: Align the mark on the unit with the mark on the nebulizer kit as shown. Using the Device WARNING ·Do not use the device where the device may be exposed to flammable gas or vapors.
Page 16 1 Hold the nebulizer kit as illustrated on the right. CAUTION ·Do not tilt the nebulizer kit so the angle of the kit is greater than 45˚. Medication may flow into the mouth. ·Do not shake the nebulizer kit while using the device.
Page 17 4 Complete the treatment. WARNING For type, dose, and regime of medication, follow the instructions of your physician or licensed healthcare practitioner. 5 Turn the power switch to the off ( ) position. The compressor turns off and nebulization stops. 6 Disconnect the air tube from the nebulizer kit.
Page 18: Care And Maintenance
Care and Maintenance Cleaning after Each Use Following cleaning instructions after each use will prevent any remaining medication in the bottle from drying resulting in the device not nebulizing effectively and will help prevent infections. WARNING Wash the nebulizer parts after each use. Dry the parts immediately after washing.
Page 19: Daily Disinfecting
Daily Disinfecting Disinfect the nebulizer kit and particle adjusters and mask after the last treatment of the day. To disinfect the parts, use one of the methods described below: A. Use a commercially available disinfectant. Follow the instructions provided by the disinfectant manufacturer. 1.
Page 20: Changing The Air Filter
Do not operate the device without the air filter. Use only the AVICHE air filter designed for this device. 4 Put the air filter cover back on the compressor.
Page 21: Caring For The Device
·Do not subject the compressor or any of the components to strong shocks, such as dropping on the floor. ·Use only AVICHE authorized parts and accessories. Parts and accessories not approved for use with the device do not perform the expected specification or it may damage the unit.
Page 22: Troubleshooting
CAUTION ·Do not carry or leave the nebulizer kit with medication in the medication cup. ·Do not wrap the power cord around the compressor (main unit). Troubleshooting Troubleshooting Guide PROBLEM CAUSE SOLUTION No power to unit The power cord is not plugged into Turn the power switch off.
Page 23: Limited Warranty
THAT MAY BE IMPOSED BY LAW, IF ANY, ARE LIMITED IN DURATION TO THE PERIOD OF THE ABOVE EXPRESS WARRANTY. AVICHE SHALL NOT BE LIABLE FOR LOSS OF USE OR ANY OTHER SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT COSTS, EXPENSES OR DAMAGES.
Page 24: Fcc Statement
FCC Statement NOTE: POTENTIAL FOR RADIO/TELEVISION INTERFERENCE (for U.S.A. only) This product has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 25: Specifications
Specifications Model AH-C10 Type Compressor nebulizer Power Supply AC200-240V 50Hz 120VA Nebulization Rate Approx. 0.25 mL/min Particle Size *MMAD approx. 3 µm (based on EN13544-1:2007) Medication Cup Capacity 8 mL (cc) max. Appropriate Medication Quantities 2 mL - 8 mL (cc) Operating Condition Intermittent operation 30 min.
Page 26: Guidance And Manufacturer's Declaration
Nevertheless, special precautions need to be observed: ·The use of accessories and cables other than those specified by AVICHE, with the exception of cables sold by AVICHE as replacement parts for internal components, may result in increased emission or decreased immunity of the device.
Page 27 The AH-C10 is intended for use in the electromagnetic environment specified below. The customer or the user of the AH-C10 should assure that it is used in such environment. Electromagnetic Emissions IEC60601-1-2 Electromagnetic Environment Emission Test Compliance — Guidance The AH-C10 uses RF energy only for its internal function.
Page 28 40 % U 40 % U environment. (60 % dip in U (60 % dip in U Voltage dips, short If the user of the AH-C10 for 5 cycles for 5 cycles interruptions and requires continued voltage variations operation during power...
Page 29 Level — Guidance Portable and mobile RF communications equipment should be used no closer to any part of the AH-C10 including cables, than the recommended separation distance calculated from the equation appropriate to the frequency of the transmitter. Recommend separation...
Page 30 To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the AH-C10 is used exceeds the applicable RF compliance level above, the AH-C10 should be observed to verify normal operation.
Page 31 Recommended separation distance between portable and mobile RF communications equipment and the AH-C10 The AH-C10 is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customers or the users of the AH-C10 can help prevent electromagnetic interference by...
Page 33: After-Sales Service And Warranty Card
(Service Hotline: +86-400-800-9850) 1. Implement the national policy of Three Guarantees. 2. Free maintenance will be provied by AVICHE in case of quality problems within one year from the date of purchase. In case of such issues over one year, Users can seek services by right of invoice and warranty card to the...
Page 34 2. Spare Parts Spare parts will be provided free of charge within the warranty period, and is subject to charges out of warranty period. 3. Contact Information for After-sales Service Phone: +86-400-800-9850 AVICHE Shandong Medical Technology Co., Ltd.
Page 36 Manufacturer: AVICHE Shandong Medical Technology Co., Ltd. Address: Floor 26, Building A, A2-1 Jinan Pharm Valley, Gangxingsan Road, High-tech District, Jinan City, Shandong Province, China. Service Hotline: +86-400-800-9850 Website: www.aviche.cn Email: info@aviche.com Tel/Fax: +86-531-55683666 Postcode: 250101...
