Ziton ZP3-RDUB1 Installation Sheet

Installation Sheet
Description
The ZP3-RDUB1 Remote Display Unit (Repeater
Panel) mimics the status of a host ZP3 Panel at a
remote location.
between them is via the ZP3 Serial Control Bus
(SCB), which makes use of a RS485 link.
The RDU Panel has the RDU Display and RDU Zone
Boards mounted to its door. The door has cut-outs
prepared for access to push-button switches, LED's
and the LCD. The door is closed by a Camlock. The
Controls Key can be software enabled in the host
panel to control access to the Accept, Reset, Sound
Alarms and Silence buttons.
Wiring to the RDU Panel is done through the
knock-outs situated at the back of the panel.
Specification
Compatibility:
Software:
Data Interface:
24V Power Supply:
Voltage
Current (quiescent)
Current (max)
Current (LCD
backlighting off)
Display Type:
Primary LED
indications:
Installation sheet
ZP3-RDUB1 Remote Display Unit
Bi-directional communication
ZP3 Panels
SW72301.XXX, SW72201.XXX
ZP3 Serial Control Bus (RS485)
24Vdc (-20% +25%)
150mA
300mA
100mA
Euro 4 x 40 LED
Common Fire, Common
Fault, Common Disabled,
ZP3-RDUB1 Remote Display Unit
Secondary LED Indicators
No. of Zone indications
Audible Alarms:
Pushbutton Switches:
Keyswitches:
Jumper Links:
Controls Enable (L1)
Reset Comms
Controller (L11)
Reset Main Controller (L12)
Buzzer Mute (L16)
Termination (L2)
Fail-safes (L5, L6)
Terminals:
Earth (TB4.1)
0V & +24V (TB4.2&3)
Comms (TB3)
Crls Off (TB2.1&2)
Commis (TB2.3&TB5.1)
Reserved (TB5.2&3)
Dimensions:
Weight:
EN60529 Rating:
Temperature Range:
Page 1
No.: 1453 iss 01
Other, Silence Alarms, Sound
Alarms
26 LEDs
50
On-board buzzer to
acknowledge key presses
and signal alarms.
14
Controls On/Off
Enables Accept, Reset,
Sound Alarms and Silence
Alarms
Resets the communications
microcontroller
Resets the display
microcontroller
Kills the buzzer (only with
commissioning terminals
shorted)
Terminates the RS485 line
with 120
Used together to apply a fail-
safe bias to the RS485 line
Connect to building earth
24V DC supply
RS485 connection to the
Serial Control Bus
Not used
Link to place RDU in
commissioning mode (buzzer
mute)
Connection for the controls
on/off keyswitch
358mm (W) x 220mm (H) x
52mm (D)
2.7 kg
IP30
-5 to 45ºC
501-1453ZE-1-01
14/12/2005
