Airplane Ride On
This page lists the contents included in the box. Please take
time to identify the hardware as well as the individual
components of the product. As you unpack and prepare for
assembly, place the contents on a carpeted or padded area
to protect them from damage. Please follow the assembly
instructions closely. Improper assembly can result in
personal or property damage.
WARNING:
CHOKING HAZARD - SMALL PARTS
Small parts present in unassembled state.
Adult assembly required.
A
B
2 - Connecting
2 - Large
bolts
bolts
E
F
2 - Large
1 - Small
screws
screw
Large Allen
Small Allen
wrench
wrench
8135 River Drive • Morton Grove, IL 60053 • p: (800) 933-9904 • e: customerservice@landofnod.com • www.landofnod.com
Assembly Instructions
C
D
2 - Medium
4 - Small
bolts
bolts
2 - Flat
4 - Wood
washers
dowels
Phillips head screwdriver
(not included)
1 - Body
1 - Seat
1 - Tail base
1 - Steering
wheel
1 - Wings
1 - Base
1 - Propeller
x 01
2 - Wheels
1 - Axel
