Summary of Contents for Imperial Freedom
- Page 1 Freedom Assembly Instructions PN 21337 REV B - 2 - 3-16-12...
-
Page 2: Helpful Hints
INTRODUCTION Satellite portable restrooms must be assembled according to approved assembly procedures. Avoid variations in assembly procedures which could adversely affect product life and warranty. All references to front, left, right, and rear are looking at the door of the unit from the outside. LEFT RIGHT FRONT... - Page 3 Install Angles on Floor: 1) Place floor P/N 21268 on a table or 2) Rivet long angles to floor using rivets 3) Rivet short angles (2) PN 21270 to left box with textured side up. Layout 3 long P/N 14351. Align holes in angles with &...
- Page 4 Install Front assembly: 10) Bend right facing, position on top of 11) Rivet right facing to edge of right side 12) Repeat steps 8) through 10) to install & outside of the short angle on floor. panel (facing on outside of panel). Rivets left facing with door / top facing.
- Page 5 Install Handrails on Left & Rear Panels “USING TEMPLATES TO LOCATE MOUNT HOLE LOCATIONS ON PANEL” [OLD STYLE PANELS WITH NO DRILL POINTS FOR PLASTIC HANDRAILS]: 17) Install Handrails PN 21291 (use 18) With left handrail template on inside 19) Rivet handrail to left panel. There are handrail templates to mark & drill holes of left panel align mark on left end of 4 pre-drilled holes on back of handrails.
- Page 6 Install Handrails Left & Rear Panels: “WITH NO TEMPLATE: MEASURE / MARK MOUNT HOLE LOCATIONS ON PANEL” [OLD STYLE PANELS WITH NO DRILL POINTS FOR PLASTIC HANDRAILS / IGNORE EXSISTING DIMPLES]: 25) Mark locations on left panel “OLD STYLE PANEL WITH NO DRILL POINTS FOR PLASTIC HANDRAILS” shown below. Drill at marks using #10 (.193”) [5 mm] Drill bit. Rivet handrail to left panel following steps 19) & 20) NOTE: “NEW STYLE PANEL WILL HAVE 10 DRILL POINTS FOR PLASTIC HANDRAILS AT LOCATIONS SHOWN BELOW”...
- Page 7 26) Mark locations on rear panel “OLD STYLE PANEL WITH NO DRILL POINTS FOR PLASTIC HANDRAILS” shown below. Drill at marks using #10 (.193”) [5 mm] Drill bit. Rivet handrail to left panel following steps 23) & 24) NOTE: “NEW STYLE PANEL WILL HAVE 10 DRILL POINTS FOR PLASTIC HANDRAILS AT LOCATIONS SHOWN BELOW” PN 21337 REV B - 8 - 3-16-12...
- Page 8 Install Tank and Vent pipe: 27) Install seat lid PN 10570 on tank PN 28) Apply pressure on tank out against 29) Install second screw through left 16538. Plastic bolt through seat lid hinge panel while installing screws PN# 13860 panel into dimple in center of groove into the tank Thread plastic nut on bolt for the outside of unit.
- Page 9 Install Paper guard: Install Lift Handles: 36) Install paperguard PN 17082 and 37) Locate 6 dimples in each side panel 38) Rivet handles PN 14611 to panels / washer PN 11315 on the inside. Insert (left & right) for rear lift handles. Drill 1/4" facings using rivets PN 11270 through the spindle PN 16844 into the (0.25) [6.35mm] holes through panels.
- Page 10 Install Inside Door Handle: Install Outside Door Handle: Install Front Hasps: 42) Rivet handle PN 16807 on inside of 43) Rivet handle PN 16807 on outside of 44) Locate dimples for hasp PN 13197 door. Drill out dimples in door using #10 door.
- Page 11 Install Door Closure / Door closure cover: Install the Decal Bracket & Decal: 51) Drill at 4 dimple locations on inside 52) Place door closure cover PN 21314 53) Place decal bracket PN 21308 flat of door using a #10 (.193”) [5 mm] Drill over door closure.
