Summary of Contents for Califone Music Maker
- Page 1 Infrared Music Maker Plus ™ Multimedia Player/Recorder 2395IR Infrared Music Maker™ Plus 2395IRPLC-6 Six-Person Learning Center (shown above) califone.com Owner’s Manual...
- Page 2 Player/Recorder Owner’s Manual Thank you for purchasing this Wireless Music Maker™ Multimedia Player. I invite you to register your product online for its one year warranty coverage at our website: www.califone.com — while you’re there — make sure to learn more about our complete line of portable and installed PA systems, multimedia players and recorders, wired and wireless headphones and headsets, computer peripherals and other Califone products.
-
Page 3: Initial Setup
NOTE: Califone cassette recorders are designed for use only with 60-minute Type 1 Normal Bias recording tape. V i s i t u s o n l i n e a t c a l i f o n e . c o m... -
Page 4: Front View
Front View Rear View HEA DPHONE REMOTE EXT.SPK . B EAT CUT V i s i t u s o n l i n e a t c a l i f o n e . c o m... - Page 5 BALANCE PHONES PHONES POWER REBL REBL TAPE AM/FM AM/FM Power On Power/Standby Switch LCD Display Tape AM/FM Volume Down Volume Up Treble Up Treble Down Bass Up Bass Down Telescoping Antenna Tuner Up Tuner Down Preset Program CD Door Play/Pause Skip Forward Skip Backward Stop...
-
Page 6: Getting Started
Getting Started When the ‘Power’ button (1) is depressed the LED (2) to the left of the LCD display (3) will be red for standby mode. Pushing the LED will cause the LED to be green indicating the unit is fully powered up. •... - Page 7 Radio Function Programming Stations Twenty FM stations and Twelve AM stations can be saved in memory with the ‘PRESET’ (16) function. • To save a station into memory, first select a station and then press the ‘PROGRAM’ (17) button to see ‘_ _’ appear on the LCD display. Memory Display 89.90 •...
- Page 8 The CD player will accept both 12 cm and 8 cm discs and will read CD, CD-R and CD-RW formats. • Before opening the CD door (18) the LCD will show dashed lines. Open the CD door and the LCD display will show ‘Open’ . Insert a CD, close the door and the LCD will display the number of tracks and total play time of the disc.
- Page 9 Memory Programming Up to 16 tracks can be programmed. With the CD stopped press the ‘PROGRAM’ button one time. Select a track to play by pushing the ‘Skip Forward’ | or ‘Skip Back’ | button. Push the ‘PROGRAM’ button again to enter another track to save in memory. When finished, press the ‘PLAY/PAUSE’...
- Page 10 CD Function continued To search forward or backward to a particular point on a track during playback Press and hold the (SKIP|) or (SKIP |) buttons to search forward or backward through the current track. Playback resumes at the point you release the button. Program Playback Up to 20 tracks can be programmed for playback.
- Page 11 Cassette Function To Fast Wind/Rewind Press the REWIND (42) (43) or FAST-FORWARD (44) (45) key. Press the STOP/EJECT key to stop winding at the desired position. During fast winding, regular play, or recording, the tape will stop automatically when its end is reached. Continuous Play from one cassette deck to the other cassette deck 1.
-
Page 12: Headphone Listening
Listening with Wired Headphones Two headphone jacks are located on the Music Maker™ - a single 3.5 mm jack (26) on the top and one 1/4” phone jack (27) on the rear of the cabinet. A jackbox can be plugged into either for multiple listeners. -
Page 13: Other Features And Functions
RC-2300 Remote Control • The RC 2300 provides most functions available on the Music Maker™ controls. It does not, however, function with tape operations. • INTRO : One feature added to the remote is the Intro function. While in the CD mode press the ‘PLAY’ button, then press the ‘INTRO’... -
Page 14: Specifications
Care and Maintenance Cassette Maintenance & Service Cleaning The heads, capstan and pinch roller should be cleaned from time to time to prevent buildup of tape oxide, which degrades performance. 1. Remove cassette tape before cleaning. 2. Clean the head of all visible, reddish-brown oxide with a cotton-tipped swab moistened with a methyl alcohol or any solution specifically manufactured for this purpose. -
Page 15: Troubleshooting
PROBLEMS General The unit does not operate. Cassette Cassette cannot be loaded. The tape does not move. The tape gets caught in the tape transport mechanism. Tape speed is slow. Tape running is unstable. There is excessive noise, the sound quivers or there are breaks in the sound. -
Page 16: Important Safety Instructions
TAKEN SO THAT THE GROUNDING OR POLARIZATION MEANS OF THE APPLIANCE ARE NOT DEFEATED. Califone® International Inc. • 1145 Arroyo Avenue, # A • San Fernando, CA 91340 USA Toll Free 800.722.0500 | Toll Free Fax 877.402.2248 International Customers call 818.407.2400 or Fax 818.407.2405 califone.com...
