- Page 1 7 D AY W I R E L E S S F O R E C A S T E R WEATHERFX FOR HUNTING INSTRUCTION MANUAL MODEL# 960072C Lit #: 98-1521/12-09...
- Page 3 The Bushnell HuntFXi Features: Automatically Updated 7-DAY Forecast As long as your PC is connected to the Internet, and the Bushnell HuntFXi software is active (it can be left running in the background with minimal CPU usage, while you use your computer for other tasks), the 7-day forecast and weather data displayed on the unit will be automatically updated from the Internet throughout the day via AccuWeather.com and sent...
-
Page 4: Install The Software
Quick Start Guide 1) Install the Software Insert the CD, click the “HuntFXi Setup Wizard” button and follow the onscreen directions to install the HuntFXi software on your PC (Windows 2000 or later, with an “always on” internet connection). 2) Connect the Transmitter Connect the USB Transmitter to your PC’s USB port. -
Page 5: Installation And Setup Instructions
STEP 3: START THE HuntFXi APPLICATION and SET LOCATIONS Double click the Bushnell “HuntFXi” icon on your desktop to start the program. After it opens to the main weather data screen (this may take a minute or so the first time the program is launched), there are two simple, onetime setup steps. - Page 6 move the cursor down to the “Edit Location” button that pops up below it (Fig. 3)-click on this, and the main weather data screen will change to the Location Settings window (Fig. 4). Normally you should set your current location or “home city” in the first location box (still highlighted in yellow at the top).
- Page 7 STEP 4: SETTING UP THE RECEIVER UNIT The Receiver may be powered by batteries or from the included AC adapter. To use the AC adapter, insert the round plug into the jack on the lower left side of the unit, then connect it to a wall outlet.
- Page 8 Receiver/Transmitter BUTTONS AND PARTS (see table on next page) Battery Compartment Back of Receiver Stand Keyhole USB Transmitter Fig. 7 Antenna...
- Page 9 RECEIVER/TRANSMITTER BUTTONS AND PARTS Front/ Top of Receiver Button Name Location Back of Unit 1) SEARCH Back of Unit 2) UNITS Back of Unit 3) BRIGHTNESS Top of USB 4) TRANSMIT Transmitter Front of Unit 5) + and - Top of Unit 6) SNOOZE/BACKLIGHT Top of Unit 7) ALARM...
- Page 10 RECEIVER DISPLAY GUIDE A) RF (RADIO FREQUENCY) RECEPTION STATUS This icon shows the connection status between the Receiver unit and the USB Transmitter. There are three basic status indications: The Receiver is successfully synchronized to the USB Transmitter and receiving weather data from it periodically.
-
Page 11: Wind Speed And Direction
D) WEATHER FORECAST SYMBOLS (ICONS) Please see the “Forecast Icons Reference” at the back of this manual for a complete table of the forecast icons for the HuntFXi software screen and the Receiver display, along with the weather conditions they indicate. E) FAVORITE LOCATION INDICATOR All the displayed weather data is for the location currently selected on the Receiver. - Page 12 M) FORECAST CONDITIONS AND HIGH/LOW TEMPERATURE FOR ADDITIONAL DAYS OR MORNING/ AFTERNOON/EVENING The right frame area of the Receiver’s display is capable of displaying different information, depending on which buttons are pressed next to it, on the right side of the unit. Normally it will display the forecast for the next three days (if “Today”...
- Page 13 FORECAST ICONS REFERENCE BACKLIGHT COLOR REFERENCE : Temperature Range *Colors Approximate...
-
Page 14: Troubleshooting
1. Be sure that you are using Windows 2000, XP or Vista and your PC is connected to the Internet. You need to have Microsoft .NET Framework 1.1 driver installed in your PC in order to complete the installation of the HuntFXi program. Most PCs purchased after 2005 will already have this-if you have an older PC, click “Help and Support”... - Page 15 Try again later if you wish to update the forecast manually by clicking “UPDATE” on the HuntFXi program screen. For any other problems or questions, please contact Bushnell Customer Service at: (800) 423-3537 • www.bushnell.com ) but one or more of the next 3 days’...
- Page 16 In the event of a defect under this warranty, we will, at our option, repair or replace the product, provided that you return the product postage prepaid. This warranty does not cover damages caused by misuse, improper handling, installation, or maintenance provided by someone other than a Bushnell Authorized Service Department.
- Page 18 For further questions or additional information please contact: Bushnell Outdoor Products 9200 Cody, Overland Park, Kansas 66214 (800) 423-3537 • www.bushnell.com ©2010 Bushnell Outdoor Products NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS...
