- Page 1 INFECTION CONTROL CONSULTANTS LLC ® giccllc.com OPERATING MANUAL The M3 System Delivery Module ® Measure Manage Monitor...
- Page 2 INFECTION CONTROL CONSULTANTS LLC ® giccllc.com PROVIDING A SAFE AND HEALTHY INDOOR ENVIRONMENT...
-
Page 3: Table Of Contents
Table of Contents General Safety Guidelines Purpose of Use and Safety Environmental Safety Transportation and Storage Installation Piping Connections Priming Troubleshooting Maintenance Warranty... -
Page 4: General Safety Guidelines
This manual uses the following safety message icons: Danger! Warning! Indicates a hazardous situation which, if not avoided, could result in death or serious injury. Important! A practice not related to personal injury or additional information. The M3 System® Delivery Module... -
Page 5: Purpose Of Use And Safety
PURPOSE OF USE AND SAFETY The M3 System® Delivery Module is intended for fluid dispersion of Path-Away Anti-Pathogenic Aerosol Solution® or an alternate approved by GICC. • Do not use in explosive area • Do not use with flammable chemicals •... -
Page 6: Environmental Safety
For spare parts orders or any other communication, refer to the pump’s label. The serial number can be used to uniquely identify the Delivery Module.. Fig. 1. UL label. THIS DELIVERY MODULE IS TESTED AND CERTIFIED BY UL FOR MATERIALS SAFETY. The M3 System® Delivery Module... -
Page 7: Transportation And Storage
Back Pressure Regulator w/Nozzle n. 1 Axial Foot Filter (PVDF) n. 1 Injection Valve (PVDF) m 7.6 Delivery Hose m 2.4 Suction Hose m 3.0 Discharge Hose m 1.8 Power Cable n. 1 Operating Manual The M3 System® Delivery Module... - Page 8 Max installation height ••••••••••••••••••••• 1.5 m Tab. 1. Capacity FLOW cc per pulse Maximum Hoses STROKE pressure Model cc/h delivery suction (PE) (PE) 4.31 4.69 0.00113 0.001239 0.249 101.5 4 x 6 4 x 6 The M3 System® Delivery Module...
-
Page 9: Installation
• Pay attention to the risks presented by outside gas and vapors in the work area • Avoid all electrical dangers. Pay attention to the risks of electric shock or arc flash hazards • Avoid water splashes and direct sun The M3 System® Delivery Module... - Page 10 Replace all corroded fasteners. positioning Make sure that all fasteners are properly tightened and that there are no missing fasteners. Delivery hose Air discharge Purge activation button Back pressure regulator Power cable Suction hose Nozzle Pick up valve The M3 System® Delivery Module...
- Page 11 When mounting the unit, ensure the unit is fastened securely to the surface, able to withstand weight and vibration. Single mounting location (top) Two mounting locations (bottom) The M3 System® Delivery Module...
-
Page 12: Piping Connections
Assemble as shown in Fig. 6. Insert hose into pipe holder until it reaches the bottom. Lock hose on pump’s head by screwing down the tightening nut. The M3 System® Delivery Module... - Page 13 Lock hose on pump’s head by screwing down the tightening nut. Hand-tighten nuts firmly. Do not use other tools to tighten nuts. Connect the other end of the hose to the injection valve using the same procedure. The M3 System® Delivery Module...
- Page 14 Refer to Fig. 8 below for delivery and discharge self venting hose. Assembling procedures are the same as described previously. pump head connection To bleed hose To delivery hose/ back pressure regulator To suction hose Suction, delivery and discharge (bleed) valves are different. The M3 System® Delivery Module...
- Page 15 Refer to Fig. 9 and Fig. 10 below for mounting instructions of the back pressure regulator and back pressure nozzle. When connecting the piping, ensure that regulator the o-ring has been properly installed to avoid leakage. Screw mounting positions Notes: The M3 System® Delivery Module...
-
Page 16: Priming
6. After the prime cycle is complete, the system will enter “normal operation mode,” activating 6 seconds per hour. The M3 System® Delivery Module... - Page 17 Once liquid starts to disperse from the nozzle, start to screw the pin clockwise, this will then raise the pressure and begin to allow the nozzle to disperse correctly. The M3 System® Delivery Module...
-
Page 18: Troubleshooting
Before returning the delivery module to the service manufacturer for repair, drain the product from pump head and rinse it. Make sure that the product is isolated from the power supply and cannot be powered by mistake. The M3 System® Delivery Module... - Page 19 • Pull back cover until it’s completed separated from main unit • Remove board • Completely disconnect wires from main board and replace it • Reconnect wires to the main board • Reassemble the back cover • Reinsert screws The M3 System® Delivery Module...
-
Page 20: Maintenance
Installation and maintenance tasks should be Installation carried out by authorized and qualified personnel only in accordance with local regulations. Use maintenance original spare parts for repairs. The M3 System® Delivery Module... - Page 21 Use the following safety equipment within the work area during installation, service and when handling product: • Protective mask • Protective gloves • Safety goggles • Ear plugs or ear muffs • Further security device, if necessary The M3 System® Delivery Module...
- Page 22 System Delivery Module: The product supplied as approved by GICC LLC. Use of any other product will immediately void all warranties. Path-Away Anti-Pathogenic Aerosol Solution when used with the GICC M3 System is proven effective against COVID-19. The M3 System® Delivery Module...
-
Page 23: Warranty
M3 System Diffuser acts or omissions or otherwise. To the fullest extent permitted by applicable law, GICC LLC shall not, in any event, be liable for incidental,... - Page 24 INFECTION CONTROL CONSULTANTS LLC ® giccllc.com PROVIDING A SAFE AND HEALTHY INDOOR ENVIRONMENT For all customer service inquires visit: www.m3systemprotection.com Tel: In the USA +1-843-368-7063 When dismantling a pump please separate material types and send them according to local recycling disposal requirements. We appreciate your efforts in supporting your local Recycle Environmental Program.
