Summary of Contents for AMP AMP 21x-2
- Page 1 AMP - User manual for 70 bar aqua misting pump system for cooling and humidifying This unique type plate is placed both inside the cabinet and on the head frame. AMP mounting and user manual, Pumps 2022-1 page 1 of 14...
-
Page 2: Model Info
If your purchase includes a SAFE misting controller, you will find a separate instruction for this controller. For more information about AMP product series, contact: sales@amn-misting.com AMP mounting and user manual, Pumps 2022-1 page 2 of 14... -
Page 3: Safety Instructions And Warnings
2.6 MOTOR CONNECTION TO POWER All systems have CEE plug 400 Vac pre-installed. In case of pump service, the CEE plug must be removed from socket to avoid any hazard. AMP mounting and user manual, Pumps 2022-1 page 3 of 14... -
Page 4: Operation Directions
After few hours of operation, make a control, that the operation in total is OK including an extra control, that the pulley is tensioned and in the right position. Inside the belt house, you find an extra V-belt – for service if needed. AMP mounting and user manual, Pumps 2022-1 page 4 of 14... -
Page 5: Maintenance
Make a pressure relief by opening the valve at the end of the pipeline or loosening a screw fitting on the pipeline for taking of the high pressure. AMP mounting and user manual, Pumps 2022-1 page 5 of 14... -
Page 6: Troubleshooting And Solutions
Check water inlet connection / filters. pressure System is frozen. De-freeze. Broken valves. Change valves. Pipe system leaking. Repair pipe systems. Pump unit loses Leaking gaskets Check and repair gaskets. water Replace the pump AMP mounting and user manual, Pumps 2022-1 page 6 of 14... - Page 7 Quick guide for use of AMP Pumps 2022-1. Filter change: Change - Max 500 hour or 1 year or pressure difference > 1 bar Oil service: Mineral oil SAE 15W-40: Change every max. 500 hours or 1 year bad seal rings, condense or cleaning with water can eventually lead to water in the oil.
- Page 8 Delivery and mounting the pump. Delivery: Demounting from transportation pallet: AMP mounting and user manual, Pumps 2022-1 page 8 of 14...
- Page 9 When ordering a universal pump with AMP 54. When delivered the system is standard for 1 section: Bleed-off valve for eliminating the pressure when pump stop (No dripping from nozzles) Low pressure solenoid valve open 1 sec. before pump start (reduced vacuum at start) Why change the pump to handle multiple sections: ...
- Page 10 Wall mounting: Mounting details (close up): AMP mounting and user manual, Pumps 2022-1 page 10 of 14...
- Page 11 B = Free distance (without pipe hanger) from pump to pipe > 1 mtr. C = Free distance to pipe hanger > 0,5 mtr. High-pressure connection AMP 16 (Extra equipment): AMP mounting and user manual, Pumps 2022-1 page 11 of 14...
- Page 12 View of the replacement pump Demount the high-pressure pipe. Demount the by-pass hose Demount the high-pressure set. Demount the filter set The pump is ready for Demount the gauge. Demount the fitting demounting AMP mounting and user manual, Pumps 2022-1 page 12 of 14...
- Page 13 Push with 1 kg pressure on center of V-belt through inspection hole - and the belt should move from 4 to 6 mm. If more than 6 mm, you need to tighten. Adjust the 3 nuts set below of the pump. AMP mounting and user manual, Pumps 2022-1 page 13 of 14...
- Page 14 You will need about 1 liter of anti-frost fluid per 10 meters of pipe + a some extra for pumps, filters etc. AMP 48 remote wi-fi control for service, can with success be used for this job. 1. Empty the filter house and insert a new cartridge filter.
