Infinity HPS 1.5 Technical Manual

Technical Manual
HPS 1.5
ACOUSTIC & ELECTRICAL SPECIFICATIONS
• Nominal Impedance
• Max Amp Power
• Frequency Response
• Sensitivity
• Crossover Frequency
SYSTEM COMPONENTS:
• Cabinet
• Grille
• Low Frequency
Transducer
DC Resistance
• High Frequency
Transducer
DC Resistance
• Crossover Network
PACKAGING
Owner's Manual
334936-001
Survey Card
330033-001
Warranty Card
333715-001
OWNER'S
MANUAL
Top/Bottom
Foam
331277-001
Outer Carton
334939-001
8 ohms
125 watts
100Hz – 20kHz
89 dB SPL, 1 watt @ 1 meter
2200Hz
HPS 1.5 (Not for sale)
334931-001
5 1/4" (133mm) Co-injected
woofer, shielded 334940-001
3.5 ohms ±10%
1" (25mm) Neodymium
Silk Dome 333232-001
3.6 ohms ±10%
334930-001
Infinity Systems, Inc. 250 Crossways Park Dr., Woodbury, New York 11797
AURAL SWEEP TEST SPECIFICATIONS:
• System Aural Sweep Test 6.0V Input 100 Hz to 20 kHz
• L.F. Aural Sweep Test
• H.F. Aural Sweep Test
PHYSICAL SPECIFICATIONS
• Enclosure dimensions:
SHIPPING WEIGHT:
• 18 lbs. (8.1 kg) Sold in pairs
WARRANTY:
• Refer to Warranty Statement packed with each product.
WIRING DIAGRAM
Driver
High Frequency
333232-001
Black
Driver
Low Frequency
334940-001
Red/Black
HPS 1.5 SCHEMATIC
L1
780 uH
C1
24uF/100V
Input L.F.
R1
1 ohm/10W
R3
10 ohms/10W
C3
2.7 mfd/100V
Input H.F.
6.0V Input 80 Hz to 3kHz
2.0V Input 2 kHz to 20 kHz
10 1/2" x 6 1/2" x 8" (H x W x D)
(267 x 165 x 203mm)
334930-001
Network
Blue
BLK
Red
RED
L2
1.8 mH
C2
12uF/100V
R2
5.4 ohm/10w
RED/BLACK
BLUE
L3
150uH
BLACK
RED
+
L.F.
+
H.F.
4-99
