SWIT Electronics CL-M100D User Manual

CL-M100D Studio Panel LED Light
Ver:A
Thank you for choosing SWIT products. Please read the instructions before using, and keep it for future reference.
Specification
Model
LED QTY
Color Temperature
Brightness
Illumination
Half Peak Beam Angle
CRI
TLCI
SSI （D55）
Working Voltage
Output Power
Dimension
Weight
Warning
1.Do not disassemble the panel light or touch the interior with metal objects to avoid damage；
2.Do not store the panel light in dusty or wet environment to avoid damage；
3.USB interface is reserved interface, please use it according to the specified environment of the company's related products,
not for other purposes, so as not to cause loss；
4.Do not connect the output device of the DMX signal in the panel light network when using the mutual control function of the panel light,
otherwise the function can not be used normally；
5.Only use the light in the temperature range of -10℃-40℃.
Maintenance
1. Please use a soft dry cloth to clean the front panel of the product, or use a soft cloth dipped in a neutral detergent solution Wipe with a soft,
dry cloth.
2. Do not wipe the front panel with a wet cloth, anhydrous alcohol, gasoline, or the mixture of anhydrous alcohol and ether. Otherwise, the
front panel may be damaged.
USER MANUAL
S W I T E l e c t r o n i c s C o. , L t d .
CL-M100D
576pcs
2700K-6500K
0%-100%
3400 Lux@1m
About 62°
98
99
73
AC 100-240V,50/60Hz ; DC 11-17V
≤130W
See Fig.1、 Fig.2、 Fig.3
5.6Kg
370mm
275mm
245mm
Fig.1 CL-M100D Front View
Tel:+86-25-85805753
Fax:+86-25-85805296
http://www.swit.cc
E-mail: contact@swit.cc
130mm
Fig.2 CL-M100D Side View
