MM
SECTION
input:
1 pair RCA input for MM cartridges
input impedance:
47 k
Ω
gain:
33 dB (low out), 48 dB (high out)
noise floor:
-84 dBV
1 pair RCA 50
1 pair RCA 600
MC
SECTION
input:
1 pair RCA input for MC cartridges
selectable input impedance:
100 / 220 / 470 / 1000 Ω
selectable gain:
44 / 50 / 56 dB (low out)
62 / 68 / 74 dB (high out)
noise floor:
-90 dBV
outputs:
1 pair RCA 50
1 pair RCA 600
power supply:
Thesis , or Thesis
power consumption:
max 60VA
weight:
7 kg
dimensions:
22 x 8.5 x 32.5 cm (W x H x D)
Heed Audio Kft. (Ltd.)
Reviczky Gyula u. 9-11
H-1181 Budapest
Hungary
Tel.: +36 1 294 7401
info@heedaudio.hu
www.heedaudio.com
/ 150 pF
Ω
, high level
Ω
, low level
Ω
, high level
Ω
, low level
π
λ
( ), max
λ
350 VA
( , γ and ω)
π
( )
λ
