Talkaphone MS-600 Installation Manual

I. Introduction
This Installation Manual provides detailed instructions for a typical installation of the MS-600. It is
highly recommended that this manual be read in its entirety before starting any installation.
II. Contents
Please ensure receipt of each of the included MS-600 components:
QTY Part Number
1 24541
1 67595
1 67598
III. Installation
THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE
APPLICABLE INSTALLATION CODE (FEDERAL, STATE, AND LOCAL)
BY A PERSON FAMILIAR WITH THE CONSTRUCTION AND OPERATION
OF THE PRODUCT AND THE HAZARDS INVOLVED
PLEASE NOTE THAT THIS INSTALLATION MANUAL IS INTENDED TO
BE USED AS GENERAL INSTALLATION GUIDANCE. INSTALLATION
REQUIREMENTS IN THE FIELD MAY VARY.
1. Mount the MS-600 flush mounting sleeve into a stud wall, cement block, brick wall, or other wall
type. MS-600 must be installed so that the Call Station gasket seals properly with the finished
wall surface. Note that the Call Station faceplate, gasket, and the lip of the MS-600 unit will sit on
top of the finished wall surface. See Figures (1) and (2).
2. Install the top and bottom supports for the MS-600 flush mounting sleeve; these are set at a
distance of 10.50 inches (typical). The distance from the bottom support of the MS-600 to the
ground is dictated by the distance from the Call Station pushbutton to the ground per ADA
requirements. See Figure (1).
Page 1 of 5
Copyright 2015-2020 Talk-A-Phone, LLC. • 7530 North Natchez Avenue • Niles, Illinois 60714 • Phone 773.539.1100 • info@talkaphone.com • www.talkaphone.com.
All prices and specifications are subject to change without notice. Talk-A-Phone, Talkaphone, Scream Alert, WEBS, and WEBS Contact are registered trademarks of Talk-A-
Phone, LLC. All rights reserved. All other trademarks mentioned in this document or website are the property of their respective owners and does not imply or indicate any
approval, endorsement, sponsorship, or affiliation with such owners unless such approval, endorsement, sponsorship, or affiliation is expressly indicated.
Flush Mounting Sleeve
Description
Flush Mounting Sleeve
Gasket for Flush Mounting Sleeve
Paper Mounting Template (MS-600)
MS-600
Installation Manual
Rev. 12/23/2020
