INSTRUCTION Dear Customer: Thank you for purchasing our products! We want to help you to get the best results from your new product and to operate it safely. This manual contains information on how to do that; please read it carefully before operating the product.
SPECIFICATIONS MODEL HCOMBI336F-A Model of Engine SPK36F Air-cooled; 2 cycle; vertical Engine type Piston valve; gasoline engine Engine displacement 33 cm Max. engine power 1.0kW Engine speed at idling 3000+/- 200 min-¹ Max. engine speed 10000 min 8000 min-¹ Max. rotational frequency of the spindle...
Page 4
- Uncertainty K 1.5 m/s Weight of tool (empty no cutting attachment 6,55 kg Hedge trimmer: Cutting length of trimmer blade: 390mm Cutting capacity Ø 24mm Speed 1600 min-¹ Noise(in accordance with EN ISO 22868): 97.06 dB(A) - Sound pressure level 110.02 dB(A) - Sound power level - Uncertainty K...
Page 5
Wear hearing protection while operating the power tool. The declared vibration total value has been measured in accordance with a standard test method and may be used for comparing one tool with another. The declared vibration total value may also be used in a preliminary assessment of exposure. Warning The vibration emission during actual use of the power tool can differ from the declared total value depending on the ways in which the tool is used.
SAFETY MESSAGES Your safety and the safety of others are very important. We have provided important safety messages in this manual and on the engine. Please read these messages carefully. A safety message alerts you to potential hazards that could hurt you or others. Each safety message is preceded by a safety alert symbol and one of three words, DANGER, WARNING, or CAUTION.
Page 7
- Beware of foot injury - Beware of falling objects - Beware of blade thrust - Wear eye protection, ear mufflers and helmet - Wear sturdy boots to protect yourself from slipping - Wear glove to protect your hands - Always beware of the danger from overhead electric-power line, keep a safe distance at least 10m from the power line Do not use sawblade Caution! Beware of blade thrust!...
SYMBOLS ON THE MACHINE For safe operation and maintenance, symbols are carved in relief on the machine. According to these indications, please be careful not to make a mistake. The port to refuel the “GASOLINE” Position: FUEL TANK CAP The direction to close the choke Position: AIR CLEANER COVER The direction to open the choke Position: AIR CLEANER COVER...
(4) Thick work gloves (5) Non-slip-sole work boots Do not wear loose clothing, jewelry, short trousers, sandals, or go barefoot. Do not wear anything which might be caught by a moving part of the unit. Secure hair so it is above shoulder length.
Page 10
After starting the engine, check to make sure that the cutting attachment stops rotating when the throttle is full released. If it continues to rotate even after the throttle has been fully released, turn off the engine and take the unit to the dealer for repair. If the unit starts to shake or vibrate, turn off the engine and check the whole unit.
HANDLING FUEL The engine is designed to run on gasoline, which contains highly flammable gasoline. Never store cans of fuel or refill the tank of the unit in any place where there is a boiler, stove, wood fire, electrical sparks, welding sparks, or any other source of heat or fire which might ignite the fuel. Never smoke while operating the unit or refilling its fuel tank.
Page 12
Warning: there are safety consequences from using other cutting attachments, e.g. metal multi-piece pivoting chains and flail blades. WARNING! Make sure the chain and guide bar are correctly adjusted before operating the equipment . Never attempt chain adjustment with the engine running! Always make sure the cutting attachment is properly installed and firmly tightened before ...
SET UP THE EQUIPMENT JOINT ATTACHMENT 1 Pull the ring out 2 Insert the attachment to the main shaft. Fix the pin into the hole; 3 Tighten the knob bolt securely. INSTALLING HANDLE Align the mounting holes and assemble the handle / barrier onto the rubber support (pre-assembled on the upper shaft).
Page 15
a. Pole pruner Installing chain and guide bar Place the sawing chain onto the sawing rail. Open the cover sprocket by unscrew the screw with the provided wrench. Position the guide bar so that the chain tensioning stud projects into the guide bar, Ensure that the saw chain runs in the correct direction! Chain tensioning stud Reinstall the cover and then tighten the fixing bolt lightly.
Page 16
NOTE! The chain should not sag, but it should be possible to pull it a few millimeters away from the saw rail. Set the chain tension WARNING! The saw chain has very sharp edges. Use protective gloves for safety. Always pay attention to the chain tension.
Page 17
Cutting device for grass trimmer Put a spanner in the hole of the cap and the hole shaft to block it. Remove the screw with a wrench (provided). Cutting device (brushcutter) Put a spanner in the hole of the cap and the hole shaft to block it. Remove the screw with a wrench (provided).
Page 18
Install the bar of the brush cutter on the main unit. Make sure that it is securely fixed. c. Hedge trimmer Unscrew the locking screw. Install the hedge trimmer in the extension tube. Screw then the screw to fix the hedge trimmer. a.
Page 19
Fuel mixture Warning: Gasoline is highly flammable. Keep the fuel in specially designed cans. Only fill the tank outside and do not smoke during the operation. Avoid sparks or open flames near the fuel. Fill the tank before starting the engine. Never remove the fuel tank cap, add fuel while the ...
OPERATION BEFOR OPERATION CHECKS Warning! For your safety, and to maximize the service life of your equipment, it is very important to take a few moments before you operate the engine to check its condition. Be sure to take care of any problem you find, or have your servicing dealer correct it. Before beginning your pre-operation checks, be sure the engine stop switch is in the OFF position.
Page 21
Put the starter in the OFF position 3. Press the priming pump, located under the air filter cover, about 7 to 10 times until the fuel enters the carburetor. 4. Pull the thrower softly until you feel a resistance, then pull with a sharp blow. Be careful to accompany the handle to avoid a sudden return of it on the engine of the machine.
Page 22
IMPORTANT! Place the unit on a flat, firm place. Keep the cutting head clear of everything around it. The product is equipped with a centrifugal clutch mechanism, so the cutting attachment begins to rotate as soon as the engine is started by putting the throttle trigger into the start position.
Page 23
NOTE! The oil reservoir has a capacity sufficient to provide about 40 minutes of cutting time (when set to deliver the minimum flow rate, or about as long as you’ll get from a tank of fuel). Be sure to refill the oil tank every time when refuelling the saw.
Page 24
like all chainsaws, flings oil from the chain during operation. Protect yourself from falling oil drops with suitable protective glasses and clothing. To operate the pruner, press down the throttle lockout and then pull the throttle trigger. The pruner is equipped with a low-kickback chain and it was also done everything from an engineering ...
ADJUSTING THE ANGLE OF THE CUTTING BLADES 1. Stop the engine. 2. Lift the lock lever and press down the adjusting lever. 3. Adjust the angle of the blades to the desired angle and loose your hand. OPERATION OF BRUSH CUTTER Grab the device with the right hand at the rear handle and with the left hand at the front handle.
Page 26
Direction of rotation OPERATION FOR GRASS TRIMMER Hold the machine safely with both the hands. Trim the grass and weed only, low shrubbery may be cut with a thick blade. Work in a regardful manner and do not threaten anybody while mowing. Work quietly and considerately! Work only in conditions of sufficient visibility and sufficient light! Watch the cutting head!
1) Hold the running machine over the grass and knock the ground several times with the cutting head the nylon line will get prolonged in thus way. 2) The cutter enclosed in the protection shield will cut the nylon line to the required length. Caution! The nylon line remnant may be thrown off and cause an injury.
SPARK PLUG Starting failure and misfiring are often caused by a fouled spark plug. Clean the spark plug and check that the plug gap is in the correct range. To replace the demolished spark plug with a new one with same specifications. Remove carbon Demolished spark plug ~...
1. Loosen lock nut (A) as shown in the diagram. 2. Tighten screw (B) fully, and then turn one-third to one half of a rotation backward. 3. While holding onto the screw to keep it in position, tighten the lock nut. 4.
SPROCKET Check for extensive wear, and replace it when the teeth are worn over 0.3 mm. Sprocket SAW CHAIN Sharpening Sharpen the chain saw if you have enough experience and you have the proper tools. If not, take the tool to a qualified professional service for sharpening.
Page 32
Be sure to round off the front edge to reduce the chance of kickback Make sure every cutter has the same length and edge angles as illustrated. Cutter length Side plate angle Top plate cutting angle Filing angle TRANSMISSION The reduction gears are lubricated by multipurpose, lithium-based grease in the transmission. Supply new grease every 25 hours of use or more often depending on the job condition.
TROUBLESHOOTING GUIDE Case 1. Starting failure PROBABLE CHECK ACTION CAUSES fuel tank incorrect fuel drain it and use correct fuel → → fuel filter fuel filter is clogged clean → → carburetor adjustment out of normal range adjust to normal range →...
Page 34
Case 4. The pruner runs but is not cutting CHECK PROBABLE CAUSES ACTION The chain is fitted in Refer to the assembly of → → Guide bar & Saw chain reverse on the guide guide bar and chain Case 5. Insufficient chain lubrication. CHECK PROBABLE CAUSES ACTION...
Tel : +33 (0)534.502.502 Fax : +33 (0)534.502.503 declares that the machines: Multi-function Garden Tool Model: HCOMBI336F-A Serial No.: 20211203926-20211204225 the people name holding the technical file:Mr. Olivier Patriarca have been designed in compliance with the following standards: EN ISO 11680-1:2011...
WARRANTY WARRANTY The manufacturer guarantees the product against defects in material and workmanship for a period of 2 years from the date of the original purchase. The warranty only applies if the product is for household use. The warranty does not cover breakdowns due to normal wear and tear. The manufacturer agrees to replace parts identified as defective by the designated distributor.
PRODUCT FAILURE WHAT TO DO IF MY MACHINE BREAKS DOWN? If you bought your product in a store: a) Empty the fuel tank. b) Make sure that your machine is complete with all accessories supplied, and clean! If this is not the case, the repairer will refuse the machine.
WARRANTY EXCLUSIONS THE WARRANTY DOES NOT COVER: • Start-up and setting up of the product. • Damage resulting from normal wear and tear of the product. • Damage resulting from improper use of the product. • Damage resulting from assembly or start-up not in accordance with the user manual. •...
