BEINAT ILDA100 Quick Start Manual

From the elegance and prestige that has always characterized the BEINAT Srl, and the concept of home
fitness, comes the level switch ILDA100
The ILDA100 level switch is an electronic device which, by means of the built-in relay, controls a pump or a
valve while maintaining the amount of liquid present in a reservoir within certain thresholds chosen by the user.
Similarly serves for the prevention of flooding, by means of the built-in relay can control both a solenoid valve
is a transfer pump.
There are two probes that determine the functioning of the control switch one for the common and an other
for the maximum level.
On the front panel you can visually check through led's work status of the equipment connected to it is turned
on or off..
The newness of this equipment is given by the flexibility of supply which can range from 230 VAC to both 12/
24 VDC and alternating current.
The mounting bar OMEGA makes installation fast allowing the coaching inside, inside, in a single panel of all
the instruments of command connected to a tank and structured in the same format of the level switch.
Important: Assembly / maintenance of the appliance must be carried out by qualified personnel
and in accordance with applicable laws and regulations.
The manufacturer assumes no responsibility for the use of products that have to comply with
particular environmental and / or installation standards.
Important note
Before connecting the equipment, it is recommended that you read the instruction manual
carefully and keep it for future reference. It is also recommended to perform the electrical
connections correctly as per enclosed drawings, observing the instructions and the Standards.
N.B. Refer to the documentation in all cases where the symbol is on the side

