Summary of Contents for Ros IC-15X
- Page 1 ROS IC-15X CONTROLLER OPERATION AND MAINTENANCE MANUAL SERIAL NUMBER: __________ SALES ORDER: __________ 5618 Copley Drive San Diego, CA 92111-7902 TEL: (858) 565-8500 FAX: (858) 565-8808 www.rosys.com 45-03287 REV D...
- Page 2 (d) This warranty shall be governed by the laws of the State of California. In the event the defect is determined to be within the terms of this warranty, then ROS agrees to repair and/or replace (at ROS' discretion) the product or defective portion at no charge to the Purchaser.
-
Page 3: Customer Assistance
CUSTOMER ASSISTANCE ROS, Inc. uses a worldwide network of stocking distributors and representatives who are familiar with our products and are able to provide assistance during installation and/or operation of these products. If you have any questions or problems with this product that are not covered by this manual or instruction, please contact our agent in your area, or contact us directly by phone or fax or email. -
Page 4: Change Record
CHANGE RECORD DESCRIPTION DATE SEE EC-02596 22JUL16 45-03287 REV D... -
Page 5: Table Of Contents
TABLE OF CONTENTS WARRANTY ........................II CUSTOMER ASSISTANCE ................... III CHANGE RECORD ....................... IV DESCRIPTION ......................1 CONTROL UNIT SPECIFICATIONS ............... 2 OUTPUT CONNECTOR PINOUT ................4 APPENDIX ........................5 45-03287 REV D... -
Page 6: Description
The Integrated Controller is used to operate a complete, remotely positioned viewing system that typically includes an ROS Bipolar Controlled Camera, a 120 VAC Pan & Tilt Unit, and Dual 250W (max) Lamps. -
Page 7: Control Unit Specifications
2. CONTROL UNIT SPECIFICATIONS Power Source: 115 + 10 VAC, 60 Hz Up to 550 watts with (2) lamps, 250W each Front Panel Controls: POWER ON SYSTEM Toggle POWER OFF EXPOSURE OPEN EXPOSURE CLOSE ZOOM TELE ZOOM WIDE (3)Toggle- CAMERA Momentary FOCUS NEAR FOCUS FAR... - Page 8 Main Connector: Mil-Spec 17-pin Mating Cable: CA-95 (maximum length 500 ft) Housing Material: Front and Rear panels - Anodized Aluminum Chassis – Die cast aluminum Covers - Vinyl clad aluminum Dimensions: Height - 3.50 inches (89 mm) Depth - 13 inches (330 mm) (not including handles) Width - 17 inches (432 mm) Weight (typical): 19.75 pounds (8.9 kg)
-
Page 9: Output Connector Pinout
The main output connector for use with a cable to the remote camera, pan & tilt as well as the lamp is a 17-pin, mil-spec connector. The ROS mating cable is CA-95. Standard IC-15X Controller pin assignments are as follows:... -
Page 10: Appendix
APPENDIX IC-15X CONTROLLER DRAWINGS***: 45-03289 Installation Outline Drawing, IC-15X Controller 45-03285 Top Assembly, IC-15X Controller ***Drawings are available from ROS upon request*** 45-03287 REV D...
