Summary of Contents for HIRED-HAND HH.Net 6407-5110
- Page 1 HH.Net Router/Repeater Hired Hand Manufacturing, Inc. 1733 County Road 68 PO Box 99 Bremen, Alabama 35033 Part No 4801-2996 Installation Guide 900SS Wireless Network...
- Page 2 Table of Contents Section Title Page Description ..............................1 Warnings ...............................1 Limited Warranty ............................1 Installing an HH.Net Router/Repeater......................2 Connecting to Controls..........................2 Connecting to Computer RS232 Serial cable ....................3 Connecting Power Supply ..........................3 Connecting Repeater as Signal Booster......................4 Connecting Wired Repeater to 900SS Wireless Repeater................5 10.
- Page 3 This warranty gives you specific legal rights and you may also have other rights that vary from area to area. Warrantor: Hired-Hand MFG., Inc. 1733 County Road 68 PO Box 99 Bremen, Alabama 35033 Part No.
- Page 4 4. Installing an HH.Net Router/Repeater The distance between repeaters can be up to 4000 feet. Below is an example of a typical farm layout with control rooms in the middle using one repeater to boost the signal and the other to convert from RS485 to RS232, to connect to the computer.
- Page 5 6. Connecting HHI Controls to a Computer RS232 Serial Cable HHI Control Board Status LED RS232 Connection Blue – RX Brown/White – TX Orange – DTR Orange/White - GND BLUE BROWN / WHITE ORANGE ORANGE / WHITE Computer 7. Connecting Power Supply HHI Control Board Status LED Status LED...
- Page 6 8. Connecting Repeater as a Signal Booster Computer HHI Control HHI Repeater HHI Repeater Part No. 4801-2996 900SS Wireless Network...
- Page 7 9. Connecting Wired Repeater to 900SS Wireless Repeater The HHI Repeater can be used in conjunction with the 900SS Wireless Repeater. For example, if the 900SS module has to be mounted further than 20 feet from computer, the HHI 900SS Repeater can be used to feed a RS485 network.
- Page 8 Part No. 4801-2996 900SS Wireless Network...
