ZIPLINE KIT WITH SEAT INSTRUCTIONS AND SAFETY RULES
Thank you for your purchase of the b4adventure ZIPLINE! This product was engineered to provide safe fun for ages 8+ years
when the instructions and rules are followed. For best and safe results please read and follow all instructions carefully
wheninstalling and riding your SLACKERS™ ZIPLINE. Obey all safety rules at all times.
IMPORTANT: FILL IN YOUR DATE OF PURCHASE
ON YOUR MAIN CABLE STICKER!
KIT CONTAINS:
(1) Trolley with sealed ball bearing pulleys. Non-slip
handgrips. Note: Actual trolley shape may vary.
(1) Main Cablelength varies with model, 1/5in galvanized
steel cable, with looped eye on oneend.
(1) Sling Cable 5ft. (1.5m), 1/5in steel cable w/looped eye.
(1) Turnbuckle 6in (15.24cm) Steel w/ 2 eye bolts & nuts.
(3) U-clamps 1/5in with thread cover caps.
(1) Seat and Rope Only included with kits with seats. Seat color varies.
(1) Instructions
(1) Turnbuckle backup cable with (3) U-Clamps 1/5in with thread cover caps.
(1) Assembly Socket Wrench Tightening Tool
(1) Zipline Registration Form
Items Required (Not included):
7) (2) Adjustable wrenches
8) Pair of work gloves
9) 100 ft. Tape measure
1.
BE SAFE! ALWAYS FOLLOW THESE RULES
WARNING!. THIS PRODUCT IS INTENDED FOR USE BY ages 8+
years or older.
To be setup and installed only by an Adult
WARNING! Maximum weight 200lbs(91kg). This zipline is designed
for children to ride a few feet off ground.
Wear suitable shoes and close fitting clothing. No jewelry, scarves
or other loose clothing.
Make sure everything is installed correctly. Inspect and test the line
before each use
If worn or damaged parts are found, contact b4Adventure for
replacement parts – DO NOT substitute with other ,non-
b4Adventureparts or failure resulting in injury may result.
order parts: 1-844-834-4334.
Remain seated for the entire ride, wait until you have
stopped COMPLETELY before letting go of the trolley or
dismounting seat. One zipline rider only at a time. Keep people
and animals at least 25ft (7.62 m) away from the zipline course.
Never use the line when it is wet or if there is rain or lightning in the area.
Do not place fingers or hair inside of trolley or serious injury may result.
Do not reach up to grab cable while riding or as a spectator to slow down rider or serious injury may result.
WARNING!
Only for domestic use. Outdoor use.
2) Step ladder
3) (6) 2 inch nails
4) Duct tape
5) (2) Helpers with brooms
6) Pair of safety glasses
B4 Adventure • Denver Colorado 80216 • 1-844-834-4334 QUESTIONS?
www.b4adventure.com
WARNING:
REQUIRED - SERIOUS INJURY OR
cable attachment.
WARNING:
HAZARD
Do not attach or use a tree that is
-
diseased, damaged, or not healthy and stable.
Improper tree selection may cause product failure
and serious injury or even death.
WARNING:
REQUIRED
This product should be tested
-
using 250 LBS (113 kg) at 5 feet (152 cm) from
each end at the Start and Finish Points.
To
WARNING:
REQUIREMENT
can wear or loosen during use. Inspect and tighten
all hardware. Replace your cable after one year of
use.
SLA.479/ SLA.480
READ CAREFULLY!
ADULT SUPERVISION
UN-HEALTHY TREE
ADULT STRESS TEST
MAINTENANCE
This product has parts that
-
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the slackers ZIPLINE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for b4Adventure slackers ZIPLINE

  • Page 1 READ CAREFULLY! Thank you for your purchase of the b4adventure ZIPLINE! This product was engineered to provide safe fun for ages 8+ years when the instructions and rules are followed. For best and safe results please read and follow all instructions carefully wheninstalling and riding your SLACKERS™...
  • Page 2 •Do not setup course on a steep hill as unsafe speeds may result. See Sloping Course Adjustment Section. • The longest zipline kits we sell are for 100’ maximum courses length. b4Adventure does not sell longer kits as the starting height is too high for rider’s starting height.
  • Page 3 30 in. 24 in. 18 in. 12 in. Every course is different, examine the course clearances so the rider’s feet do not drag near the end of the course. Finish Point B4 Adventure • Denver Colorado 80216 • 1-844-834-4334 QUESTIONS? www.b4adventure.com...
  • Page 4 This product contains small parts. Do not the grips shaft. allow children under 3 years of age near the •For a longer sling cable, contact b4Adventure at 1-844-834-4334 parts or assembly area or visit www.slackersline.com/accessories Step B: U-Clamp installation - Have your helping friends use their brooms to lift and support the trolley and cable while you perform the installation.
  • Page 5 TEST 5 TIMES! This test helps stretch out cable. Start Point and release. Be careful not Note: Weight should not drag on the ground during the test. to be in the way. 250lbs. B4 Adventure • Denver Colorado 80216 • 1-844-834-4334 QUESTIONS? www.b4adventure.com...
  • Page 6 Place thread cover caps on each of the U-bolts. ZIPLINE SPRING BRAKE SYSTEM Your Slackers Zipline may include our Spring brake. If not, you can go online to purchase our SLA.803 Zipline brake kit which is is over 5ft of powder coated steel that can be added to your line prior to installation for a safe and easy ending point.
  • Page 7 QUESTIONS OR SETUP ISSUES? Get answers 24/7 at: www.slackersline.com/help-center/ Watch helpful videos at: http://slackersline.com/videos/ then select Slackers Zipline Setup STILL NEED MORE HELP? Contact our support team at: info@b4Adventure.com B4 Adventure • Denver Colorado 80216 • 1-844-834-4334 QUESTIONS?
  • Page 8: Maintenance Required

    REPLACE YOUR ZIPLINE SLING CABLE AND COURSE all hardware and inspect all components for wear. Check grips CABLE AFTER EVERY 12 MONTHS for loosening. Replace with only b4Adventure parts. OF NORMAL USE! CONTACT b4Adventure to order: 1-844-834-4334 SAFETY FIRST! rope/cable will FAIL if misused, abused, worn-out or damaged.
  • Page 9 Replace any defective parts only with b4Adventure parts. At the beginning of each play season: • Tighten all hardware. • Lubricate all metallic moving parts (bearings) with a light coating of lithium grease. • Check all protective coverings: Trolley frame, grips and seat. Replace if they are loose, damaged, cracked or missing.
  • Page 10 1-844-834-4334 OR EMAIL US AT info@b4Adventure.com Important Product Disclaimer and Notice Activities involving the installation and use of ziplines are inherently hazardous by their nature. Poor installation, poor site selection, inadequate rider instruction, poor adult supervision or improper use can cause severe injury or death.
  • Page 11: Contenu De L'ensemble

    LIRE ATTENTIVEMENT LE MODE D’EMPLOI ET LES RÈGLES DE SÉCURITÉ DE LA TYROLIENNE AVEC SIÈGE ! Merci d’avoir acheté la tyrolienne ZIPLINE de b4adventure ! Ce produit est destiné à l’amusement en toute sécurité des enfants agésplus de 8 ans, dans le respect du mode d’emploi et des règles de sécurité. Pour des résultats plus sûrs, lire et suivre attentivement les instructions d’installation et d’utilisation de votre tyrolienne ZIPLINE de b4adventure.
  • Page 12 • La plus longue tyrolienne que nous offrons permet un trajet d’un maximum de 30,5 m (100 pi) de longueur. b4Adventure ne vend pas de tyrolienne plus longue puisque la hauteur de départ serait trop élevée pour les utilisateurs. •...
  • Page 13 En général, la course de l’utilisateur s’arrêtera près de l’arrivée, puis il repartira en arrière vers le milieu du câble. B4 Adventure • Denver Colorado 80216 • 1-844-834-4334 QUESTIONS? www.b4adventure.com...
  • Page 14 GUIDE DE HAUTEUR D’INSTALLATION POUR TERRAIN PLAT Installation générale : Hauteur du point de départ du trajet (espace entre les arbres) Hauteur de fixation du point d’arrivée Longueur du trajet 30,48 m (100 pi) 27,43 m (90 pi) 24,38 m (80 pi) 21,34 m (70 pi) 18,29 m (60 pi) 15,24 m (50 pi) 12,19 m (40 pi) 9,14 m (30 pi) 198 cm (78po) Hauteur initiale fonction...
  • Page 15 Remarque : si le diamètre de l’arbre de départ est trop grand, inverser l’installation en mettant le câble d’attache au point d’arrivée. Pour un plus long câble d’attache, appeler b4 Adventure au 1-844-834-4334 ou visiter le www.B4ADVENTURE.com/accessories. Conseil facultatif pour l’installation : Déterminer la hauteur d’attache aux points de départ et d’arrivée, et planter trois des six petits clous (espacés de 5 cm [2 po]) dans chaque arbre pour retenir le câble à...
  • Page 16 Enrouler l’excédent de câble,et attacher et couvrir l’enroulement avec du ruban adhésif. 5. TENDRE LA TYROLIENNE Tout en tendant la tyrolienne à l’aide du tendeur, vérifier l’installation initiale attentivement et complètement. Le câble de la tyrolienne peut soutenir plusieurs fois le poids de la plupart des utilisateurs. Les boucles, les serre-câbles et les arbres de fixation sont les plus susceptibles de lâcher si l’installation présente des défauts, c’est pourquoi ils doivent être vérifiés très attentivement et souvent.
  • Page 17 NOUS SOMMES LÀ POUR VOUS AIDER! POUR TOUTE QUESTION SUR VOTRE TYROLIENE, NOUS CONTACTER :1- 844-834-4334 OU PAR COURRIEL À Info@b4Adventure.com DIRECTIVES AUX UTILISATEURS – À PASSER EN REVUE AVEC TOUS LES UTILISATEURS! (pour tyrolienne avec ou sans siège)
  • Page 18 Habiller les enfants avec des vêtements bien ajustés et des chaussures fermées, a de sandales, tongs, sabots, etc. RESPECTER LES RÈGLES CI-DESSUS À CHAQUE UTILISATION. FAIRE PREUVE DE PRUDENCE SANS CHERCHER À ÊTRE PLUS RAPIDE! B4 Adventure • Denver Colorado 80216 • 1-844-834-4334 QUESTIONS? www.b4adventure.com...
  • Page 19 ENTRETIEN OBLIGATOIRE REMPLACER LE CÂBLE PRINCIPAL ET LE CÂBLE D’ATTACHE APRÈS 12 MOIS D’UTILISATION NORMALE! CONTACTER b4Adventure pour commander : 1-844- 834- 4334 LA SÉCURITÉ AVANT TOUT ! VÉRIFIER L’INSTALLATION AVANT CHAQUE UTILISATION. PRENDRE SOIN DU MATÉRIEL! REMPLACER LES PIÈCES EN CAS DE : CÂBLES POIGNÉES PINCEMENT ROUILLE/DÉCOLORATION...
  • Page 20 Remplacer les pièces défectueuses seulement par des pièces authentiques de b4Adventure. Au début de chaque période d’utilisation : • Serrer tout le matériel • Graisser toutes les pièces métalliques mobiles (paliers) avec une légère couche de graisse au lithium. •...
  • Page 21 Câble d’attache de 0,61 m (2 Câble SLA.C065 ....... principal de 19,8 m (65pi) SLA.C085 ....... SLA.C095 ....... Câble principal de 25,9 m (85pi) Câble principal de 28,95 m (95 pi) B4 Adventure • Denver Colorado 80216 • 1-844-834-4334 QUESTIONS? www.b4adventure.com...
