AZUNO DTPG150A Quick Start Manual

Acknowledgement
Thanks you for purchasing AZUNO digital tire pressure gauge, model
DTPG150A with hose or model DTPG150B.
Please ensure you read this user manual carefully prior to using this
product and follow the operational Instructions and guidelines correctly.
Please keep this user manual in a safe place for future reference.
PSl, BAR,
Settings
MPA, KG/CM²
0.1PSI, 0.1BAR
Minimum Increment
Accuracy ±1%
Power Source 2xAAA
Measurement Range 0-150 PSI, 0-10.34 Bar, 0-10.55 kg/cm²,0 -1.03MPA
Unit Conversion 1BAR=1.02KG/CM =0.102MPA=14.3PSI
Product description:
Swivel Chuck
LCD Display
Power Button
8mm Standard Chuck
Size of Swivel Chuck
Stainless Steel Hose Length
(Model DTPG150A Only)
Reference of Tire 2.1-2.5BAR
Pressure 30-36PSI
Gauge Display
20×φ60mm
Screen Size
2
Pressure
Release
Button
Select Button
Instructions for use
1. First press the power button to turn on the digital tire pressure
gauge.Then press the select button to choose the correct setting.
2. Remove the tire valve cap, place the pressure gauge on the valve
stem, and press down hard enough that the hissing sound
disappears.
3. Keep the connection for 3-5 seconds. Wait for the reading to
become stable, and then read the results.
4. If the pressure is too low, please inflate the tire in time If the
30cm
pressure is too high, keep the connection stable while pressing the
pressure release button to adjust the tire pressure.
5. After use, remove the swivel chuck and reset the device by pressing
the pressure release button.
6. Do not forget to put the tire valve cap back on, and then press the
power button to turn the gauge off.
Usage tips
1. While the gauge is in use, hold it steady and still so that the result is
accurate.
2
*Attention*
Please read the Vehicle
Safety Manual or Car Tire
Pressure Standard Mark
before you adjust the tire
pressure, and
adjust it according to its
actual requirements.
3
