INSTRUCTION MANUAL
59888
6L, Air Compressor, 1HP, Horizontal Tank, Direct Driven
59889
15L, Air Compressor, 2HP, Horizontal Tank, Direct Driven
59890
25L, Air Compressor, 2HP, Horizontal Tank, Direct Driven
59891
50L, Air Compressor, 2HP, Horizontal Tank, Direct Driven
59892
80L, Air Compressor, 2HP, Vertical Tank, Belt Driven
59893
50L, Air Compressor, 3HP, Horizontal Tank, Belt Driven
THANK YOU FOR BUYING AGRI-SUPPLY AIR COMPRESSOR.
Your new air compressor has been engineered and manufactured to high
standard of dependability, ease of operation, and operator safety. Properly cared
for it will give you years of trouble-free performance.
CAUTION!: Carefully read through this entire operator's manual before
using your new air compressor.
SAVE THIS MANUAL FOR FUTURE REFERENCE
Advertisement
Table of Contents
Summary of Contents for agri supply 59888
- Page 1 INSTRUCTION MANUAL 59888 6L, Air Compressor, 1HP, Horizontal Tank, Direct Driven 59889 15L, Air Compressor, 2HP, Horizontal Tank, Direct Driven 59890 25L, Air Compressor, 2HP, Horizontal Tank, Direct Driven 59891 50L, Air Compressor, 2HP, Horizontal Tank, Direct Driven 59892 80L, Air Compressor, 2HP, Vertical Tank, Belt Driven...
-
Page 2: General Safety Rules
GENERAL SAFETY RULES WANRING: Pay close attention to all Safety Rules, Warnings, and Cautions. If you use your air compressor properly and only for what it is intended, you will enjoy years of safe, reliable service. WARNING: Read and understand all instructions. Failure to follow all instructions listed below may result in electric shock, fire and/or serious personal injury. - Page 3 OTHER PEOPLE OR ANIMALS. ALWAYS TURN THE COMPRESSOR OFF AND BLEED PRESSURE FROM THE AIR HOSE AND TANK BEFORE ATTEMPTING MAINTENANCE, ATTACHING TOOLS OR ACCESSORIES. To Avoid Risk to Breathing ALWAYS OPERATE AIR COMPRESSOR OUTSIDE IN A CLEAN, WELL VENTILATED AREA. AVOID ENCLOSED AREAS SUCH AS GARAGES, BASEMENTS, STORAGE SHEDS, WHICH LACK A STEADY EXCHANGE OF AIR.
-
Page 4: Specification
Warning: If any parts are missing do not operate your air compressor, until the missing parts are replaced. Failure to do so could result in possible serious injury. SPECIFICATION Part No. 59888 59889 50890 Horsepower 1 HP... -
Page 5: Know Your Air Compressor
Part No. 59891 59892 508903 Horsepower 2 HP 2 HP 3 HP Voltage 120V~ 60Hz Motor Speed 2,850 RPM 1200 RPM 920 RPM Air Tank Capacity 50 L 80 L 50 L Air Delivery 7 CFM 9.8 CFM 12.5 CFM Max. -
Page 6: Installation
the air tank (big one) and the output pressure (small one). Air Intake Filter (5): This filter is designed to clean air coming into the pump. This filter must always be clean and ventilation openings free from obstructions. See "Maintenance". Air Compressor Pump (6): To compress air, the pistons moves up and down in the cylinder. - Page 7 Closely follow instructions packaged with the filter for proper installation. It must be installed as close as possible to the accessory. The air compressor should be as near to air outlets as possible in order to avoid long pipe lines. Do not place the air compressor where heat is excessive.
-
Page 8: Operation
Lubrication and Oil WARNING: Air compressors are shipped without oil. A small amount of oil may be present in the pump upon receipt of the air compressor. This is due to plant testing and does not mean that the pump contains the correct amount of oil. Do not attempt to operate in order to check wiring or for any reason without first adding oil to the crankcase. -
Page 9: Maintenance
WARNING: Too much air pressure causes a hazardous risk of bursting. Check the manufacturer's maximum pressure rating for air tools and accessories. The regulated outlet pressure must never exceed the maximum pressure rating. Place the pressure switch ON/OFF lever in the ON position. The motor will stop when air tank pressure reaches "cut-out pressure". - Page 10 Every 40 Hours of Operation: Inspect condition of drive belt; replace if necessary. (for Belt Driven model only) Every 100 Hours of Operation: Drain and refill compressor crankcase with clean compressor oil. Increase frequency of oil changes if humidity or operating conditions are extreme. Every 160 Hours of Operation: Check drive belt tension;...
-
Page 11: Troubleshooting
Pull ring on safety valve allowing air to bleed from the tank until tank pressure is approximately 20 psi. Release safety valve ring. Drain water from air tank by opening drain valve on bottom of tank. WARNING: Risk of Bursting. Water will condense in the air tank. If not drained, water will corrode and weaken the air tank causing a risk of air tank rupture. - Page 12 Air leaks at fittings. Tube fittings tight Tighten fittings where air can be heard enough. escaping. Check fittings with soapy water solution. DO NOT OVER TIGHTEN. Air leaks at or inside Check valve seat damaged. A defective check valve results in a check valve.
- Page 13 Compressor is not Prolonged excessive use of air Decrease amount of air usage. supplying enough air to operate Compressor is not large enough Check the accessory air requirement. If accessories. for air requirement. it is higher than the CFM or pressure supplied by your air compressor, you need a larger compressor.
- Page 14 Motor will not run. Tank pressure exceeds pressure Motor will start automatically when tank switch "cut-in" pressure. pressure drops below "cut-in" pressure of pressure switch. Check valve stuck open. Remove and clean, or replace. Extension cord is wrong length or Check for proper gauge wire and cord gauge.
- Page 15 WARR WARRANTY WARR WARR ANTY ANTY ANTY Full 1 Years Home Use Warranty If this Air Compressor is founded to be defective in materials or workmanship within a 1 year period from the date of purchase, then the tool will be replaced free of charge Warranty replacement is only available by returning the tool to the place of purchase along with the receipt showing...
