Page 1: Table Of Contents
SUPA L16 User Manual Contents Introduction Glossary Away Arming Home Arming System Disarm Bypass Zone Review Event Memory Walk-Test System Test Panic, Medical, Fire Alarm Duress Alarm Programming User Codes Deleting User Codes Programming User Partition ________________________________ Programming Telephone Numbers... -
Page 2: Introduction
Introduction Congratulations on your ownership of this security alarm system. You've made a wise decision in choosing it, for it represents the most innovative, precise and the latest in security protection technology today. We would like to personally thank you for your purchase and would like to provide you with additional information on this remarkable unit. -
Page 3: Away Arming
Away Arming LCD/LED Keypad display Away1 Partition A1 A2 A3 A4 Total Open (00) Zone 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 Away1/Ready 2/3/4 Total Open (00) [ # ] + [ AWAY ] / [ 9 ] + [ Partition Select ] Press (If Quick Away option is enabled) [ User Code ] + [ 9 ]... -
Page 4: Home Arming
Home Arming LCD Keypad display Home1 Partition A1 A2 A3 A4 Total Open (00) Zone 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 Home1/Ready 2/3/4 Total Open (00) [ # ] + [ HOME ] + [ Partition Select ] Press (If Quick Home option is enabled) [ User Code ] + [ 8 ]... -
Page 5: System Disarm
System Disarm LCD/LED Keypad display Ready1 Partition A1 A2 A3 A4 Total Open (00) Zone 1 2 3 4 5 6 7 8 Ready1/2/3/4 9 10 11 12 13 14 15 16 Total Open (00) [ User Code ] + [ 0 ] + [ Partition Select ] Press ☼... -
Page 6: Bypass Zone
Bypass Zone LCD Keypad display Bypass PtSelect? Bypass Z01-08/Z09-16 P1[] P2[] P3[] P4[] – – – – – – – – – – – – – – [ # ] + [ 6 ] Press (If Quick Bypass is enabled) [ User Code ] + [ 6 ] + [Partition Select ] Press ☼... -
Page 7: Review Event Memory
Review Event Memory LCD Keypad display Review PtSelect? Review M000 P1[] P2[] P3[] P4[] Event Memory [ # ] + [ 4 ] Press (If Quick Review is enabled) [ User Code ] + [ 4 ] + [ Partition Select ] Press ☼... - Page 8 Event/LEDs Panic ☼ ☼ Panic restore ☼ ☼ ☼ ☼ Event/LEDs Medical ☼ ☼ ☼ ☼ ☼ ☼ Medical restore Event/LEDs Fire ☼ ☼ Fire restore ☼ ☼ ☼ ☼ Event/LEDs Battery fail ☼ Battery restore ☼ ☼ ☼ Event/LEDs AC fail ☼...
-
Page 9: Walk-Test
Walk-Test LCD Keypad display WTest PtSelect? WalkTest Z01-08/Z09-16 P1[] P2[] P3[] P4[] – – – – – – – – – – – – – -- [ User Code ] + [ 5 ] Press ☼ The Line light will blink to indicate Walk-test mode. Trigger all used zones. - Page 10 Panic Alarm [ PANIC ] for 3s Press [ # ] + [ 1 ] / [ PANIC ] Press ☼ The Line light turns on to indicate system dialler performing CMS reporting. ☼ The Line light blinks to indicate system dialler performing Personal reporting. Medical Alarm [ MEDICAL ] for 3s Press...
-
Page 11: Duress Alarm
Duress Alarm [ User Code with Last Digit + 1 ] + [ 0 ] Press ☼ The Line, Batt, Mains and Armed lights will blink once. ☼ The Armed light will turn off. ☼ The Line light turns on to indicate system dialler performing CMS reporting. Remark: Duress code = Last digit of User code increase by 1 Eg1. -
Page 12: Programming User Codes
Programming User Codes [ Master Code ] + [ 7 ] Press ☼ The Line light blinks to indicate Programming mode. Enter 4-digit address location ☼ The existing code will be displayed by the keypad 4-Digit Address Location User Type Level 0401 Master User / User-1... -
Page 13: Programming User Partition
Programming User Partition [ Master Code ] + [ 7 ] Press ☼ The Line light blinks to indicate Programming mode. Enter 4-digit address location ☼ The default partition will be displayed by the keypad 4-Digit Address Location User Type Default Partition 0451 Master User / User-1... -
Page 14: Programming Telephone Numbers
Programming Telephone Numbers [ Master Code ] + [ 7 ] Press ☼ The Line light blinks to indicate Programming mode. Enter 4-digit address location ☼ The existing telephone number will be displayed by the keypad 4-Digit Address Location Telephone Number Maximum Digits 0611 0612... - Page 15 Programming Timers [ Master Code ] + [ 7 ] Press ☼ The Line light blinks to indicate Programming mode. Enter 4-digit address location ☼ The existing time will be displayed by the keypad lights 4-Digit Default Address Setting Timer Units Value Location...
- Page 16 Rename the Zone [ Master Code ] + [ 7 ] Press ☼ The Line light blinks to indicate Programming mode. Enter 4-digit address location ☼ The existing name will be displayed by the keypad lights 4-Digit Address Location Timer Default Value 0170 Zone 1...
-
Page 17: Restricting Installer Code
Restricting Installer Code [ Master Code ] + [ 7 ] Press ☼ The Line light blinks to indicate Programming mode. [ 0 ] [ 8 ] [ 1 ] [ 7 ] Enter 4-digit address location ☼ The existing value will be displayed by the keypad lights [ 0 ] [ 1 ] [ 3 ] Enter a 3-digit value ♪... -
Page 18: Call-In Beeping Tone Menu
Call-In Beeping Tone Menu Dial the telephone number connected to this system ☼ The Line light on keypad turns on to indicate a Call-in activity ♪ 2 beeps to indicate system received the call and awaiting User code entry. [ User Code ] Enter ♪... -
Page 19: Call-Out Beeping Tone Menu
Call-Out Beeping Tone Menu User pick up call ♪ ♪ ♪ ♪ High and low tones to indicate Emergency / power not present ♪ Number of beeps indicate corresponding triggered zone [ ] Press to enter Main menu [ User Code ] Enter ♪... -
Page 20: Call-In Block Diagram
Call-In Block Diagram L8_UM1016-v1.0... -
Page 21: Call-Out Block Diagram
Call-Out Block Diagram L8_UM1016-v1.0... -
Page 22: Quick Operation Reference
*Address 0170 is Zone 1, Address 0171 to 0185 is for Zone 3 to 16 respectively *This function is for L16 LCD keypad only [ Master Code ] [ 7 ] [ 0817 ] [ 4 Digits Value ] [ ] ... -
Page 23: Disclaimer
Disclaimer To ensure our customer receives the best of our services, we took an exceptional amount of time and effort to ensure the correctness and accuracy of this documentation. However, should you find any information that is in doubt, missing or appear in error, please contact the manufacturer for immediate clarification.
