Summary of Contents for Moxie MXRTG03-812-CB
- Page 1 MOXIE 8' X 12' ™ Rectangular Outdoor Trampoline Set with Premium Fiberglass Safety Enclosure Assembly, Installation, Maintenance, Care and user instructions FOR MODELS: USER MXRTG03-812-CB MXRTG03-812-OG MANUAL...
- Page 2 By Machrus Call us 1-888-965-3331 020-3150-0484 Email us support@machrus.com support@machrus.co.uk Check out our website www.machrus.com THANK YOU FOR PURCHASING THIS MACHRUS TRAMPOLINE ® Simply follow the assembly and safety in ructions in this manual and you will soon be arting your Machrus ®...
- Page 3 GENERAL INSTRUCTIONS Included in this manual are instructions for: Proper assembly, care and maintenance of product, safety tips, warnings, and proper use; in order to ensure a secure and fun use of the trampoline. All users and supervisors must read and familiarize themselves with all these instructions and all other information in this manual.
- Page 4 Never set up the trampoline in rainy, windy or stormy conditions, especially lightening conditions. It is recommended that the trampoline be Do not alter the product; use it only as described in this manual. Care and Maintenance Always inspect the trampoline before each use. Check for damage, wear or defective parts, as they can impair the overall safety of the trampoline.
- Page 5 Do not perform somersaults on the trampoline as this will increase the chances of landing on your head or neck, paralysis or even death can result. Children do not recognize the potential dangers of this product, so do not allow your children to play on this product without adult supervision.
- Page 6 Proper Use The maximum weight allowed on the trampoline is 265 lbs. Overloading the trampoline above the recommended user weight will cause damage to the trampoline. No more than one person at a time should be allowed on the trampoline! Avoid unsupervised use of the trampoline.
- Page 7 TRAMPOLINE FRAME PARTS LIST PART DESCRIPTION PART NUMBER ILLUSTRATION QTY. Main Frame CY003-21014-1 Tube B Main Frame CY003-21014-2 Tube A L-Shaped Main CY003-21014-3 Frame tube A L-Shaped Main CY003-21014-4 Frame tube B Vertical Leg CY003-21014-5 Extensions Leg Base CY003-21014-6 Long Upper Enclosure CY003-21014-7 Tube With Foam Short Upper Enclosure...
- Page 8 TRAMPOLINE FRAME PARTS LIST PART DESCRIPTION PART NUMBER ILLUSTRATION QTY. M6*15 Semicircle CY003-21014-19 Hexagon Socket Bolt Phillips Pan Head CY003-21014-20 Tapping Screws Tie Rope CY003-21014-21 Trampoline Mat CY003-21014-22 Enclosure Netting CY003-21014-23 Long Frame Mat CY003-21014-24 Short Frame Mat CY003-21014-25 CY003-21014-26 Washer M8 Plastic Locknut CY003-21014-27...
- Page 9 TRAMPOLINE FRAME ASSEMBLY BEFORE YOU BEGIN: Review all steps before assembly and read all precautions before using the trampoline. At least two adults are required to assemble this trampoline. Protective gloves should be used during assembly to avoid injuries during installation. Goggles should be worn to avoid injuries to the eyes. Step 1 –...
- Page 10 WARNING Make sure that you have plenty of space and a clean dry area suitable for the assembly of this trampoline. IT IS ESSENTIAL THAT THE INTENDED SITE FOR THIS TRAMPOLINE IS COMPLETELY FLAT AND LEVEL. If the ground is uneven this could cause movement in the frame and could cause stress on the joined sections of the frame that could damage the trampoline and/or can cause serious injury.
- Page 11 WARNING DO NOT PLACE HANDS NEAR THE OPENING WHEN CONNECTING THE TUBES. WEAR PROTECTIVE GLOVES TO PROTECT FROM INJURIES DURING ASSEMBLY. Leg Support The hole must face outward...
- Page 12 Step 3 –Top Rail Assembly 3A. Connect Vertical Leg Extensions (part 5) to Leg Base (part 6) as shown below (the assembled parts will be referred to as “Leg Support”). 3B. Align each leg support over a corner of the frame, with bases facing up. Connect one end of each leg to the corresponding sockets in Main Frame Tubes A and B (parts 1 and 2.) HINT: Make sure the larger indented hole on Vertical Leg Extension (part 5) is...
- Page 13 Step 4 –Secure Leg Support to Top Rail Secure Vertical Leg Extension (part 5) to the frame (parts1, 2 & 3) using Phillips Pan Head Tapping Screws (part 20), Spring Lock Washer (part 17) and Hex Key (part 31) as shown below. If the holes do not match up, rotate Vertical Leg Extension back and forth until the holes are aligned.
- Page 14 When attaching the springs, do not place your hands, arms, legs or any other body part close to the connector points (i.e. joints connecting the steel tubes). The connector points can become pinch points as the trampoline springs tighten up. Wear heavy duty working gloves to protect your hands from injuries during installation by the springs and protective goggles to avoid injuries to the eyes.
- Page 15 Step 6 – Spring Assembly Continue to attach springs in the same manner. For even distribution of tension and ease of assembly, the springs must be placed on opposite sides of the mat in an alternating manner.
- Page 16 Step 7 – Spring Assembly Continue to attach the remaining springs in the same manner as the previous step, i.e. the springs must be placed on opposite sides of the mat in an alternating manner to ensure even distribution of tension. IMPORTANT: Once all the springs are properly installed, you must go back to Step 4 and now tighten the screws on all Leg Supports.
- Page 17 FRAME PAD AND POLES ASSEMBLY WARNING Never use the trampoline without the Frame Pad, the Frame Pad reduces the risk of getting injured by hitting the metal frame or springs. Inspect the Frame Pad before each and every use to ensure all exposed metal parts are fully covered by the Frame Pad! Step 8 : 8A.
- Page 19 TRAMPOLINE ENCLOSURE ASSEMBLY WARNING BEFORE YOU BEGIN: • This trampoline must only be used when the enclosure netting is properly assembled. The trampoline netting must be checked thoroughly before each use to ensure there are no tears or damages. Please carefully read all the Important Warnings contained in this manual and all warnings on the product before use.
- Page 20 WARNING DO NOT PLACE HANDS BETWEEN THE POLES DURING ASSEMBLY. MAKE SURE TO WEAR PROTECTIVE GLOVES TO AVOID INJURIES. WARNING Make sure that the accessories(parts 13, 14, 16, 17 & 18) and the Enclosure Tube (parts 7 & 8) are firmly fixed together. Failing to do so may increase the possibility of injury due to the enclosure frame snapping apart during assembly or trampoline use.
- Page 22 WARNING Three adults are recommended for this step. Please ensure the assembled Flat Steel frames are held firmly during assembly to avoid them flexing back and causing injury. 9C. Ensure that the top rail parts all curve upward and outward. Insert the ends of the Enclosure tube (part 8) sides into the tubes of the tubes of the Enclosure Ring Connectors (part 13), at either ends of the short sides of the trampoline.
- Page 23 Step 10 – Tie the Enclosure to the Mat 10A. Secure the trampoline netting to the trampoline frame using the Tie Rope (part 21). Lift up the frame pad and tie one end of the cord to any one of the triangle-rings on the trampoline mat as shown below.
- Page 24 Step 11 - Secure the Frame Pad 11A. Wrap and tie the inner elastic straps on the frame pad around the triangle-rings and the outer straps around the trampoline frame as shown below.
- Page 25 DO NOT USE THE TRAMPOLINE WHEN THE ENCLOSURE IS REMOVED. Do not make changes or add attachments to the trampoline that are not authorized genuine Moxie direct parts. The user must carry out changes to the trampoline (e.g. the addition of an attachment) according to the instructions...
- Page 26 Congratulations you have completed the trampoline assembly! Remember to abide by all the safety rules. Have fun, play safe...
- Page 27 JUMP LIKE A PRO! 1. Standing starting position, feet shoulder-width apart, head straight and eyes on the jumping mat. 2. Swing your arms forwards and up in a circular motion. 3. Bring your feet together in the air, toes pointing down.
- Page 28 Dispose of the packaging PLEASE GIVE US A CALL 1-888-965-3331 EMAIL US AT support@machrus.com...
