Summary of Contents for Samlexpower BBM-12100
- Page 1 Battery Owner's Please read this manual BEFORE Manual Back-up installing your inverter BBM-12100...
-
Page 2: Table Of Contents
OWNER'S MANUAL | Index SECTION 1 Safety Instructions ..............3 SECTION 2 Description ................3 SECTION 3 Operation ................4 SECTION 4 Installation ................6 SECTION 5 Specifications ............... 7 SECTION 6 Warranty ................8 Disclaimer of Liability UNLESS SPECIFICALLY AGREED TO IN WRITING, SAMLEX AMERICA INC.: 1. -
Page 3: Safety Instructions
SECTION 1 | Safety Instructions 1.1 PRECAUTIONS WHEN WORKING WITH BATTERIES • Batteries contain very corrosive diluted sulphuric acid as electrolyte. Precautions should be taken to prevent contact with skin, eyes or clothing. • Batteries generate hydrogen and oxygen during charging resulting in evolution of explosive gas mixture. -
Page 4: Operation
SECTION 3 | Operation 3.1 PRINCIPLE OF OPERATION BATTERY POSITIVE INPUT BATTERY NEGATIVE NEGATIVE POWER RADIO SUPPLY INPUT LOAD POSITIVE NEGATIVE LOAD POSITIVE D1,D2 SCHOTTKY DIODE, 32CTQ030 BY INTERNATIONAL RECTIFER R1,R2 POWER RESISTOR 1R2 (1.2 OHM), 25 WATTS Fig. 3.1: Schematic Diagram Please refer to the schematic diagram at Fig. - Page 5 SECTION 3 | Operation As long as the power supply is operating normally, it will supply the load as well as charge the battery through resistors R1 and R2, each 1Ohm, 35W ( R1 and R2 are connected in parallel and will provide a net series resistance of 0.5 Ohm). NOTE: Please note that as the power supply is required to feed the load as well as charge the battery, the current rating of the power supply should be at least 20% more than the sum of the maximum load current and the maximum charging current.
-
Page 6: Installation
1) Switch off the power supply. 2) Connect the positive and negative output of the power supply to the input terminals of the BBM-12100 marked “INPUT POSITIVE” and “INPUT NEGATIVE” respectively 4) Connect the DC load to the terminals marked “LOAD POSITIVE” and “LOAD NEGATIVE”... -
Page 7: Specifications
SECTION 5 | Specifications MODEL NO. BBM-12100 INPUT 14 VDC for 12V Battery INPUT VOLTAGE 27.6 VDC for 24 Battery Maximum 100A INPUT CURRENT OUTPUT 0.4V Less than the Input Power Suppy Voltage 13.6 VDC for an Input Voltage of 14 VDC CHARGE VOLTAGE 27.2 VDC for an Input Voltage of 27.6 VDC... -
Page 8: Warranty
Warranty 2 YEAR LIMITED WARRANTY The BBM-12100, manufactured by Samlex America, Inc. (the “Warrantor“) is warranted to be free from defects in workmanship and materials under normal use and service. The warranty period is 2 years for the United States and Canada, and is in effect from the date of purchase by the user (the “Purchaser“). - Page 9 NOTES SAMLEX AMERICA INC. | 9...
- Page 10 NOTES 10 | SAMLEX AMERICA INC.
- Page 11 NOTES SAMLEX AMERICA INC. | 11...
- Page 12 Ph: 1 800 561 5885 Fax: 1 888 814 5210 Local Numbers Ph: 604 525 3836 Fax: 604 525 5221 Website www.samlexamerica.com USA Shipping Warehouses Kent, WA Plymouth, MI Canadian Shipping Warehouse Richmond, BC Email purchase orders to orders@samlexamerica.com 11001-BBM-12100-0322...
