Potter SignaLink WSS Instructions Manual page 8

Dimensions
WR - Wireless Repeater & WRX-R - Wireless Receiver
Fig 4
3.54 in
90 mm
WTX-M - Transmitter
Fig 5
1/2" NPT CONDUIT CONNECTION
NUT
1.80 in
45.72 mm
Potter Electric Signal Company, LLC
UV AND IMPACT RESISTANT POLYCARBONATE UL94-5VA, NEMA 4, (IP 66) RATED ENCLOSURE
4.72 in
120 mm
LIQUID TIGHT BREAK-THRU PLUG,REMOVE IF NEEDED TO INSTALL
1/2" CONDUIT. .130-.450" [3.3-11.4mm] CABLE DIAMETER
O-RING
4.00 in
101.60 mm
• St. Louis, MO
5401587 - REV B • 6/21
SignaLink
Wireless Supervisory System
2.38 in
60.50 mm
UV RESISTANT POLYCARBONATE
UL94-5VA, NEMA 4, (IP 66) RATED ENCLOSURE
1.65 in
41.91 mm
• Phone: 800-325-3936
™
Bridge
1.67 in
42.29 mm
• www.pottersignal.com
PAGE 8 OF 10
