Summary of Contents for UNEEK SWING OPTIX
- Page 1 INS TALL GUIDE SWING OPTIX ® for EYEXO Users P O W E R F O R E V E R Y G O L F E R...
- Page 2 LICENSE AND ACTIVATION P A G E LIGHTING ENVIRONMENT P A G E SWING OPTIX CONFIGURATION P A G E S W I N G O P T I X I N S T A L L G U I D E...
-
Page 3: Included Items
0.1 INCLUDED ITEMS USB 3.0 CABLE (2) CAMERA (2) The following items are included in the package. Please make sure they are all present and accounted for. CAMERA LENSE (2) ACCESSORIES (2 sets NOTE: If any part is missing, please contact support. S W I N G O P T I X I N S T A L L G U I D E... -
Page 4: Camera Installation
0.2 CAMERA INSTALLATION STEP ONE STEP TWO STEP ONE Please find the camera, bracket, and the 4 screws that came with the package. STEP TWO Screw in the 4 screws through the bracket onto the camera. STEP THREE Attach the camera with the bracket to the tri pod stand. The camera will need to be rotated 90 degrees as shown in the photo. - Page 5 0.2 CAMERA INSTALLATION Impact screen Swing 6feet Camera 1 sensor 5feet Swing Camera 2...
-
Page 6: Software Install
0.3 SOFTWARE INSTALL STEP ONE STEP ONE The MVS camera driver gets automatically installed when you go through the first time setup of the View software. The View setup file is in the USB flash drive that came with the unit. STEP TWO In the next window, make sure the “Destination Folder”... - Page 7 0.4 MVS DRIVER STEP ONE STEP TWO STEP ONE Once the MVS Driver setup window appears, click the “Start Setup” button to proceed. STEP TWO In the options window, confirm “C\:Program Files (x86)/MVS” is shown in the “Directory” and the other options are all checked. Then click the “Next”...
-
Page 8: License And Activation
0.5 LICENSE AND ACTIVATION STEP ONE STEP ONE You will need to click the “Browse” button and search for the QED_30000XXXX license key file (you will receive the license key file along with tracking number after purchase). STEP TWO Once the license file has been found, click open and then click the “Activation”... - Page 9 0.6 LIGHTING ENVIRONMENT Besides your normal background room lighting, additional lighting is required to optimize the Swing Optix. It is recommended to add a minimum of 8 15W or higher, non flickering LED light bulbs on a track rail with fixtures. This will help with exposure and eliminating blurring of the club.
- Page 10 3000K Note: The LED bulbs on this list have been tested with Uneekor Swing Optix cameras under a 15’ x 10’ enclosure using Uneekor QED and EYE XO hardware. These bulbs demonstrated minimal flickering during operation to not impeed Swing Optix cameras performance. If you’re still experiencing for further assistance.
- Page 11 STEP FOUR Inside the “Swing” tab, click on the “Settings” button on the top right of the screen. Next, click on the “Optix” tab to open the Swing Optix cameras. STEP FOUR You can make adjustments to the camera’s Exposure, Gamma, Brightness, and Contrast in this menu.
- Page 12 POWER FOR EVERY GOLFER Uneekor, Inc. 26249 Enterprise Court Lake Forest, CA 92630 Tel: 1-949-328-7790 sales@uneekor.com support@uneekor.com Uneekor © 2021 All Rights Reserved...
